Indledning
This manual provides detailed instructions for the installation, operation, and maintenance of your GLOBE Electric Motion Activated Flood Light Security Light. Designed to enhance the security and illumination of your outdoor areas, this light features advanced motion detection and energy-saving capabilities.
The light offers a remarkable 180-degree detection zone with a range of up to 50 feet (15 meters), ensuring comprehensive coverage. Its MOTIONBRIGHT feature provides constant low ambient lighting, transitioning to full brightness when motion is detected. With a powerful 1400 lumen output and a daylight white 4000 Kelvin color temperature, it delivers bright, even illumination. The dual mount system allows for flexible wall or eave installation.
Billede: Forside view of the GLOBE Electric Twin Head Flood Light, showcasing its two adjustable light heads and integrated motion sensor.
Sikkerhedsoplysninger
Please read and understand all instructions before beginning installation. Failure to follow these instructions may result in electric shock, fire, or other hazards that could cause personal injury or property damage.
- Always disconnect power at the circuit breaker before installing, servicing, or cleaning this product.
- Dette produkt skal installeres i overensstemmelse med den gældende installationskode af en person, der er bekendt med produktets konstruktion og drift og de involverede farer.
- Brug kun UL/cUL-godkendte ledningsforbindelser.
- Se ikke direkte ind i LED-lyskilden.
- Sørg for, at alle forbindelser er sikre og korrekt isolerede.
- This fixture is designed for outdoor use and is weather resistant.
Pakkens indhold
Kontroller, at alle komponenter er til stede, før installationen påbegyndes:
- 1 x Motion Activated Flood Light Unit
- Monteringsudstyr (skruer, trådmøtrikker, pakning)
- Instruktionsmanual
Opsætning og installation
Monteringsmuligheder
The flood light offers versatile mounting options to suit your outdoor space. It can be installed as a wall mount or an eave mount. The fixture can be rotated to achieve the desired position for optimal light and motion detection coverage.
Image: Diagram illustrating both wall mount and eave mount installation options, along with adjustable lamp hoveder.
Ledningsinstruktioner
- Sluk for strømmen ved afbryderen, før installationen påbegyndes.
- Fastgør monteringspladen til samledåsen ved hjælp af de medfølgende skruer.
- Connect the house wiring to the fixture wiring: black to black (live), white to white (neutral), and green/bare copper to green (ground). Secure connections with wire nuts.
- Carefully tuck wires into the junction box and secure the fixture to the mounting plate.
- Apply sealant around the fixture base to prevent water intrusion.
- Gendan strømmen ved afbryderen.
Betjeningsvejledning
Bevægelsesdetektion
The integrated motion sensor provides a wide 180-degree detection zone, covering an area of approximately 50 feet (15 meters). This ensures that motion from various angles will activate the light, enhancing security around your property.
Image: Graphic illustrating the 180-degree motion detection zone and 50-foot range of the security light.
MOTIONBRIGHT 2-Level Lighting
The MOTIONBRIGHT feature provides intelligent lighting control. When no motion is detected, the light maintains a constant low ambient illumination. Upon detection of motion, the light automatically switches to full brightness, providing ample light for security and visibility. This feature helps save energy while maintaining a sense of safety.
Image: Split image showing the difference between low ambient light (no motion detected) and full brightness (motion detected) with the MotionBright feature.
Justering af indstillinger
The motion sensor has adjustable settings for 'ON TIME', 'SENS' (sensitivity), and 'MOTIONBRIGHT' operation. These settings are typically found on the underside of the motion sensor unit.
Image: Diagram highlighting various features including swivel arms, black finish, durable weather-resistant plastic construction, photocell, adjustable motion detection settings, and MotionBright 2-level lighting.
- EN GANG: Select how long the light stays on after motion is detected (1 minute, 5 minutes, or 20 minutes). A 'TEST' mode is also available for initial setup.
- SENS (følsomhed): Adjust the motion sensor's sensitivity (High, Medium, Low) to control the detection range.
- MOTIONBRIGHT: Choose the desired MotionBright setting (Day-to-Dusk, 6 Hours, or Off).
Nøglefunktioner
- MOTION ACTIVATED: Detects motion from all angles up to 50 feet (15 meters) with a 180° detection zone. Adjustable shut-off times (1, 5, or 20 minutes).
- MOTIONBRIGHT 2-LEVEL LIGHTING: Provides constant low ambient lighting when no motion is detected and full brightness upon motion detection, optimizing energy use.
- LYSUTGANG: Delivers 1400 lumens with a daylight white 4000 Kelvin color temperature for super-bright illumination and enhanced security.
- DUAL MOUNT: Includes all necessary mounting hardware for quick and easy installation, supporting both wall mount and eave mount configurations.
- VEJR resistent: Constructed from durable materials, this outdoor-rated fixture is designed to withstand light exposure to the elements.
Image: Depiction of the flood light illuminating a driveway at night, highlighting its 1400 lumens brightness.
Image: The flood light installed outdoors during rain, demonstrating its weather-resistant design.
Opretholdelse
To ensure the longevity and optimal performance of your flood light, follow these simple maintenance guidelines:
- Rensning: Rengør armaturet regelmæssigt med en blød, tør klud.amp klud. Brug ikke slibende rengøringsmidler eller opløsningsmidler, da de kan beskadige overfladen eller de elektriske komponenter.
- Inspektion: Regularly inspect the wiring and mounting for any signs of wear, damage, or loose connections. Address any issues promptly.
- lysdioder: The integrated LED lights are designed for long life and do not require replacement.
Fejlfinding
If you experience issues with your flood light, refer to the following common problems and their solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Lyset tændes ikke. | No power, faulty wiring, sensor malfunction. | Check circuit breaker. Verify wiring connections. Ensure sensor is not obstructed. |
| Lyset er tændt konstant. | Sensor in test mode, continuous motion, faulty sensor. | Check sensor settings (not in TEST mode). Ensure no constant motion in detection zone. |
| Lys tændes uden nogen åbenbar grund. | Sensor sensitivity too high, environmental factors (wind, small animals). | Adjust sensor sensitivity to a lower setting. Reposition light to avoid false triggers. |
| Lyse flimrer. | Loose wiring connection, power fluctuations. | Check and tighten all wiring connections. Consult an electrician if power fluctuations persist. |
Specifikationer
| Attribut | Detalje |
|---|---|
| Mærke | GLOBUS |
| Modelnavn | Sikkerhedsbelysning |
| Varenummer | 17000202 |
| Farve | Sort |
| Materiale | Plast |
| Stil | Industriel |
| Lysarmatur Form | Projektørlys |
| Produktdimensioner | 6.89 cm L x 7.67 cm B x 5.31 cm H |
| Indendørs/Udendørs brug | Udendørs |
| Strømkilde | Hardwired |
| Installationstype | Vægmontering |
| Speciel funktion | Vejrbestandig |
| Lyskildetype | LED |
| Voltage | 120 volt |
| Lys farve | Hvid (4000 Kelvin) |
| Wattage | 15 watt |
| Lysstyrke | 1400 lumen |
| Varens vægt | 1.41 pund |
| Vandmodstandsniveau | Vandtæt |
| Montering påkrævet | Ingen |
| UPC | 058219252734 |
Image: Technical drawing showing the top-down and side dimensions of the flood light fixture.
Garanti og support
This GLOBE Electric Flood Light is backed by a 3-year manufacturer's limited warranty. This warranty covers defects in materials and workmanship under normal use.
For warranty claims, technical support, or further assistance, please visit the official GLOBE Electric webwebstedet eller kontakt deres kundeserviceafdeling. Gem din købsbevis for at validere garantien.
