THOMSON Portable Karaoke PA System User Manual
Model: QY-K600
Mærke: THOMSON
1. Introduktion
Tak for købetasing the THOMSON Portable Karaoke PA System. This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your new device. Please read this manual thoroughly before use to ensure proper functionality and to maximize your enjoyment of the product.
Image: THOMSON QY-K600 Portable Karaoke Set with speaker and two microphones.
2. Pakkens indhold
Kontroller venligst pakkens indhold for at sikre, at alle varer er til stede og i god stand.
Image: Diagram showing the speaker, two microphones, remote control, charging cable, and instruction manual included in the package.
- Portable PA Speaker Unit (x1)
- Trådløse mikrofoner (x2)
- Fjernbetjening (x1)
- USB-C opladningskabel (x1)
- Brugervejledning (x1)
3. Produktet er slutview
3.1 Hovedenhed
Image: The main speaker unit, two wireless microphones, and the remote control.
The main unit features dual 30W high-output drivers for powerful sound. It incorporates advanced DSP digital signal processing technology for balanced frequency response. The unit includes various input ports for versatile connectivity.
Billede: Detaljeret view of the speaker's control buttons (mode, play/pause, volume) and rear ports (USB, DC in, AUX out).
3.2 trådløse mikrofoner
Image: Close-up of a wireless microphone showing the DC 5V charging port, LED display, and power on/off button.
The system includes two wireless microphones with built-in rechargeable batteries. Each microphone features an LED display and a power button for easy operation. They are designed for high-quality sound capture.
3.3 Fjernbetjening
Image: The remote control with buttons for mute, volume, mode, echo, menu, EQ, pair, and reset.
The included remote control allows for convenient operation of the PA system, including volume adjustments, mode selection, EQ presets, and microphone echo/reverb control.
4. Opsætning
4.1 Opladning af enheden
Before first use, fully charge the main speaker unit. Connect the provided USB-C charging cable to the 'DC in' port on the speaker and to a compatible USB power adapter (not included). The charging indicator will show the charging status. A full charge takes approximately 3 hours.
4.2 Charging the Microphones
Each wireless microphone has a built-in rechargeable battery. Connect a USB-C cable (not included) to the charging port on the microphone. The LED display on the microphone will indicate charging status.
4.3 Initial Pairing (Bluetooth)
Follow these steps to pair your device with the speaker via Bluetooth:
- Turn on the speaker unit. Press the 'Mode' button until the Bluetooth indicator (bt) flashes.
- Aktiver Bluetooth på din smartphone, tablet eller pc, og søg efter tilgængelige enheder.
- Select "K600" from the list of devices to connect. Once connected, the Bluetooth indicator will stop flashing.
- To use the microphones, long-press the power button on each microphone until it turns on. They will automatically connect to the speaker.
Image: Visual guide showing how to switch the speaker to Bluetooth mode, connect via a smartphone, install a karaoke app, and power on the microphones.
5. Betjeningsvejledning
5.1 Tænd/sluk
Press and hold the power button on the speaker unit to turn it on or off. For microphones, long-press their respective power buttons.
5.2 Bluetooth-forbindelse
After initial pairing, the speaker will automatically attempt to connect to the last paired device when powered on. If not, manually select "K600" from your device's Bluetooth settings.
5.3 AUX-forbindelse
Connect an audio device (e.g., CD player, TV, game console) to the 'AUX in' port on the speaker using a 3.5mm audio cable (not included). Press the 'Mode' button on the speaker or remote until 'AU' is displayed.
5.4 USB-afspilning
Insert a USB memory stick containing MP3 or WAV audio files into the USB port on the speaker. The speaker will automatically switch to USB mode and begin playback. Use the remote control for track navigation.
Image: Diagram illustrating Bluetooth connection with smartphones/tablets/PCs, and wired connections (AUX) with CD players, game consoles, and TVs.
5.5 Microphone Usage and Effects
Once the microphones are powered on and connected, you can use them for karaoke or speech. Use the 'ECHO+' and 'ECHO-' buttons on the remote control to adjust the echo/reverb effect level. The 'M.VOL+' and 'M.VOL-' buttons control microphone volume.
5.6 EQ-forudindstillinger
The speaker features 5 EQ presets to optimize sound for different music genres. Press the 'EQ' button on the remote control to cycle through the presets: Pop, Rock, Jazz, Classic, and Custom.
5.7 Portability and Applications
Image: A person placing the speaker into a backpack, and another person using the speaker outdoors while relaxing.
The compact and lightweight design makes the system highly portable. It is suitable for a wide range of indoor and outdoor activities, including:
- Home karaoke and entertainment
- Indoor lectures, presentations, and meetings
- Outdoor picnics, camping, and gatherings
- Sports festivals, cherry blossom viewing, and fireworks events
- Street performances, dance practice, and promotional activities
Image: Three panels depicting different usage scenarios: family time with karaoke, a business meeting, and a party.
6. Vedligeholdelse
6.1 Rengøring
Wipe the speaker and microphones with a soft, dry cloth. Do not use abrasive cleaners or solvents, as they may damage the surface. Ensure no liquids enter the ports or openings.
6.2 Opbevaring
When not in use for extended periods, store the unit in a cool, dry place away from direct sunlight and extreme temperatures. It is recommended to fully charge the batteries every 3 months to maintain battery health.
7. Fejlfinding
If you encounter any issues, please refer to the table below for common problems and their solutions.
| Problem | Løsning |
|---|---|
| Ingen strøm | Ensure the unit is charged. Connect the USB-C charging cable and allow it to charge for at least 30 minutes before attempting to power on. |
| Ingen lyd fra højttaleren | Check volume levels on both the speaker and the connected device. Ensure the correct input mode (Bluetooth, AUX, USB) is selected. |
| Mikrofoner virker ikke | Ensure microphones are charged and powered on. Check microphone volume (M.VOL) on the remote. Ensure they are within range of the speaker. |
| Bluetooth-forbindelsen er ustabil | Ensure the speaker and device are within 15m (49 ft) and there are no major obstacles. Try unpairing and re-pairing the device. |
| Fjernbetjeningen reagerer ikke | Ensure there are no obstructions between the remote and the speaker. Check the remote control's battery. |
8. Specifikationer
| Feature | Værdi |
|---|---|
| Modelnummer | QY-K600 |
| Udgangseffekt | 30W |
| Bluetooth version | 5.0 |
| Bluetooth rækkevidde | Op til 15 m (uden forhindringer) |
| Højttalerens batterikapacitet | 2500mAh |
| Musik afspilningstid | Op til 12 timer (ved 50 % volumen) |
| Karaoke Playback Time | Up to 6 hours (with 2 mics simultaneously) |
| Opladningstid | Cirka 3 timer (fuld opladning) |
| Understøttede lydformater (USB) | MP3, WAV |
| Dimensioner (højttaler) | 31.4 x 18.8 x 15.1 cm |
| Vægt | 1.61 kg |
9. Garanti og support
9.1 Kvalitetssikring
THOMSON provides the following quality assurance for this product:
- Initial Defect: Free exchange within 30 days of arrival.
- Standard garanti: 1-year manufacturer repair support.
9.2 Compliance Certification
This product has acquired the following compliance certifications: PSE, JATE, and Bluetooth SIG.
9.3 Kundesupport
For any inquiries or support requests, please contact us through your Amazon account:
Account Service > Order History > Seller Chat
