DYLECT Ultra Flow Plus High Pressure Car Washer Pump

1. Introduktion

Thank you for choosing the DYLECT Ultra Flow Plus High Pressure Car Washer Pump. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new pressure washer. Please read this manual thoroughly before first use and keep it for future reference.

The DYLECT Ultra Flow Plus Pressure Washer delivers precision cleaning with unmatched versatility.

2. Sikkerhedsoplysninger

Your safety is paramount. Always adhere to the following safety guidelines when operating the pressure washer:

• Hold en sikker afstand: Keep a safe distance from the cleaning surface to avoid accidental contact with the high-pressure water jet.
• IPX5 Vandtætning: The unit features IPX5 waterproofing, ensuring reliable performance even in wet conditions.
• Automatisk slukning: The pressure washer is equipped with an automatic shut-off feature that stops the motor when the trigger is released, saving energy and enhancing safety.
• Built-in Exhaust System: Ensures proper ventilation and prevents overheating.
• Self-resetting Thermal Protector: Protects the motor from damage due to overheating.
• Sikkerhedslås: Always engage the safety lock on the spray gun when not actively spraying to prevent accidental starts.

The pressure washer incorporates advanced safety features for secure and stress-free operation.

3. Pakkens indhold

Carefully unpack your DYLECT Ultra Flow Plus Pressure Washer and ensure all items are present:

• 1 x 1.4KW High Pressure Washer Unit
• 1 x sprøjtepistol
• 1 x 5M PVC Outlet Hose
• 1 x 5M Power Cable with Plug
• 1 x vandfilter
• 1 x Needle (for nozzle cleaning)
• 1 x Quick Connector
• 1 x 2M Inlet Hose
• 1 x forlængerstang
• 1 x Soap Bottle (400 ml)
• 1 x Tap Connector

The complete set of the DYLECT Ultra Flow Plus Pressure Washer and its accessories.

Detaljeret view of the versatile accessories included for comprehensive cleaning.

4. Opsætning

Follow these steps for quick and easy setup of your pressure washer:

1. Tilslut indløbsslangen: Securely connect the inlet hose to your water source (e.g., tap). Ensure a tight fit to prevent leaks.
2. Attach the Outlet Hose: Connect the 5-meter PVC outlet hose between the pressure washer unit and the spray gun.
3. Add Desired Nozzle/Attachment: Select the appropriate nozzle or attachment (e.g., extension rod, adjustable nozzle, soap bottle) and securely attach it to the spray gun.
4. Plug In and Start: Plug the power cable into a suitable electrical outlet. Ensure the circuit is ready before turning on the unit.

Visual guide for the quick and easy setup process.

5. Betjeningsvejledning

The DYLECT Ultra Flow Plus is designed for user-friendly operation and versatile cleaning tasks.

Generel drift:

• Ensure all connections are secure and the water supply is turned on before powering the unit.
• Turn on the pressure washer. The motor will start when the spray gun trigger is pressed and stop when released (automatic shut-off).
• Always hold the spray gun firmly with both hands when operating due to the high pressure.

Adjustable Nozzle for Seamless Cleaning:

The adjustable nozzle allows you to switch between different spray patterns for various cleaning needs:

• Low Speed Foam Spray: Ideal for applying detergent or foam for pre-soaking vehicles or surfaces.
• Medium Speed Regular Spray: Suitable for general cleaning tasks on cars, bikes, and other surfaces.
• Jet Speed Precise Spray: Provides a concentrated, high-pressure stream for stubborn dirt, grime, and tough stains on concrete, stone, or heavily soiled areas.

The adjustable nozzle provides versatile spray patterns for different cleaning requirements.

Alsidig brug:

This pressure washer is an indispensable tool for a wide range of cleaning applications:

• Køretøjer: Cars, bikes, motorcycles, and other automobiles.
• Udendørs udstyr: Lawn mowers, garden tools, and grills.
• Overflader: Patios, pathways, driveways, fences, stone and brick walls, and swimming pools.

The DYLECT Ultra Flow Plus is versatile for cleaning patios, pathways, cars, and driveways.

6. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer din højtryksrensers lange levetid og optimale ydeevne:

• Rengøring af dyser: Use the provided needle to clear any blockages in the nozzle after each use.
• Afløbsvand: After each use, disconnect the water supply and run the pump for a few seconds to drain any remaining water. This prevents freezing in cold weather.
• Rent vandfilter: Kontroller og rengør vandindløbsfilteret regelmæssigt for at forhindre snavs i at trænge ind i pumpen.
• Korrekt opbevaring: Store the pressure washer in a dry, frost-free environment. Coil hoses neatly and store accessories securely.
• Inspicer slanger og forbindelser: Periodically check hoses for kinks, cuts, or wear, and ensure all connections are tight.

7. Fejlfinding

Se tabellen nedenfor for almindelige problemer og løsninger på disse:

8. Specifikationer

Key technical specifications for the DYLECT Ultra Flow Plus Pressure Washer:

Engineered for peak performance with a robust copper winding motor and high-pressure pump.

9. Garanti og support

Garantioplysninger: The DYLECT Ultra Flow Plus Pressure Washer comes with a 12+3 month warranty from the date of purchase. This warranty covers manufacturing, material, or assembly flaws.

Kundesupport: For any queries, technical assistance, or warranty claims, please contact Dylect customer support:

• Gratis nummer: 18002586618
• E-mail: care@dylect.in

Register your product to unlock an additional 3 months of warranty coverage.
