SimpliFire Inception 36-tommer elektrisk pejs Wescott Mantel-pakke brugermanual
Model: SF-INC36-FFWMK | Brand: SIMPLIFIRE
1. Produktet er slutview
The SimpliFire Inception 36-Inch Electric Fireplace with Wescott Mantel Package offers a realistic flame experience and efficient heating for your home. This unit features Digital Spark Technology for true-to-life flames, an elegant Folio Front design, and user-friendly controls via app, remote, or voice commands. It provides customizable flame brightness, ember bed, and accent lighting, along with efficient heating controlled by a thermostat and timer.
Figure 1.1: SimpliFire Inception Electric Fireplace with Wescott Mantel and remote control.
Figure 1.2: The SimpliFire Inception Electric Fireplace seamlessly integrated into a modern living space.
Figure 1.3: Available stylish front designs including Folio, Halston, and Chateau Forge, offering various aesthetic options.
2. Vigtige sikkerhedsoplysninger
Read all instructions carefully before installation and operation. Failure to follow these instructions may result in electric shock, fire, or personal injury.
- Ensure the power source matches the electrical requirements of the fireplace.
- Brug ikke pejsen med en beskadiget ledning eller stik.
- Hold brændbare materialer mindst 0.9 meter væk fra pejsens forside.
- Bloker ikke luftåbninger.
- Dette apparat er kun til indendørs brug.
- Proposition 65 Warning: This product can expose you to chemicals including carbon black, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.
3. Opsætning og installation
The SimpliFire Inception electric fireplace offers flexible installation options, including building into a wall or using the optional Wescott Mantel Kit for a built-in look without construction.
3.1. Dimensions and Framing
Accurate measurements are crucial for proper installation. Refer to the diagrams below for unit and framing dimensions.
Figure 3.1: Detailed size and dimensions for the SimpliFire Inception Electric Fireplace, including front, side, and top views, and framing requirements.
Figure 3.2: Dimensions for the Wescott Mantel, designed to provide a built-in appearance.
3.2. Installationsmuligheder
Choose the installation method that best suits your space:
- Optional Wescott Mantel Kit:
- Assemble, paint, and mount mantel to wall.
- Mount Inception unit.
- No need for construction.
- Build into Wall:
- Build out your framing according to dimensions.
- Mount Inception unit.
- Finish wall with desired application.
Figure 3.3: Visual guide to the two primary installation methods for the SimpliFire Inception fireplace.
For detailed installation steps, refer to the dedicated Installation Manual (PDF) available for download.
4. Betjeningsvejledning
The SimpliFire Inception fireplace can be controlled via the IntelliFire App, the included multi-function remote, or on-device controls.
4.1. Kontroller overview
Figur 4.1: Overview of control options, including the IntelliFire App for smart devices and the multi-function remote.
4.2. Multi-Function Remote
The remote control allows you to adjust various settings and features of your fireplace. It also functions as a wireless room sensor in Thermostat mode.
- Tænd/sluk: Tryk på tænd/sluk-knappen for at tænde eller slukke for enheden.
- Flamme lysstyrke: Juster flammernes intensitet.
- Ember-seng: Customize the glow of the ember bed.
- Accentbelysning: Control additional lighting features.
- Varmeapparat: Aktiver eller deaktiver varmefunktionen.
- Termostat: Set your desired room temperature. The remote acts as a sensor.
- Timer: Indstil en timer til automatisk slukning.
- Lydeffekter: Enable or disable background sound effects.
Figure 4.2: A user interacting with the fireplace using the remote control, demonstrating the ease of adjusting settings.
4.3. IntelliFire App & Voice Control
The Inception fireplace is Wi-Fi ready and compatible with the IntelliFire App, allowing control from your smart device. It also supports voice commands via Amazon Alexa and Google Assistant.
- Download the IntelliFire App from your device's app store.
- Follow the in-app instructions to connect your fireplace to your Wi-Fi network.
- Once connected, you can monitor and control all fireplace functions remotely.
- Enable the SimpliFire skill/action in your Amazon Alexa or Google Assistant app to use voice commands.
4.4. Officiel produktvideo
Watch this official video for a visual demonstration of the SimpliFire Inception Electric Fireplace features and operation.
Video 4.1: En officiel overview of the SimpliFire Inception Electric Fireplace, showcasing its digital display technology, convenient controls, and thoughtful design.
5. Vedligeholdelse og pleje
Regular maintenance ensures the longevity and optimal performance of your SimpliFire Inception electric fireplace.
- Rensning:
- Afbryd altid strømmen før rengøring.
- Brug en blød, damp klud til at rengøre de udvendige overflader. Brug ikke slibende rengøringsmidler eller spray.
- Gently wipe the glass panel with a soft cloth. For stubborn marks, use a mild glass cleaner and then wipe dry.
- Ventilation: Ensure that the air intake and exhaust vents are clear of any obstructions to prevent overheating.
- Log Set and Ember Bed: The log set and ember bed are designed for durability and do not require regular cleaning. If dust accumulates, gently brush it off with a soft brush.
- Opbevaring: Hvis pejsen opbevares i længere tid, skal den afbrydes fra strømmen og opbevares et tørt og støvfrit sted.
6. Fejlfinding
If you encounter issues with your SimpliFire Inception fireplace, refer to the common problems and solutions below.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Pejsen tænder ikke. | No power, remote batteries dead, main power switch off. | Check power outlet, replace remote batteries, ensure main power switch is on. |
| Flammerne er hverken synlige eller svage. | Flame brightness setting is low, LED lights malfunction. | Increase flame brightness via remote/app. Contact support if LEDs are faulty. |
| Varmeapparatet producerer ikke varme. | Thermostat setting too low, heater off, air vents blocked. | Increase thermostat setting, ensure heater is on, clear any obstructions from vents. |
| Fjernbetjeningen reagerer ikke. | Batteries dead, remote out of range, interference. | Replace batteries, move closer to the fireplace, remove sources of interference. |
If the problem persists after attempting these solutions, please contact SimpliFire customer support.
7. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | FORENKLE |
| Modelnavn | Inception Electric Fireplace with Folio Front and Wescott Mantel Kit |
| Varemodelnummer | SF-INC36-FFWMK |
| Produktdimensioner | 14.5" D x 61.88" B x 49.63" H |
| Varens vægt | 140.5 pund |
| Strømkilde | Elektrisk med ledning |
| Varmeoutput | 5000 britiske termiske enheder |
| Materiale | Metal |
| Finish Type | Malet |
| Installationstype | Hardwired |
| Inkluderede komponenter | Wi-Fi Module, Log Set, Multi-Function Remote |
| Ventilationstype | Vent fri |
| UPC | 197250006859 |
8. Garantioplysninger
The SimpliFire Inception Electric Fireplace comes with a Limited Warranty. For specific terms, conditions, and duration of the warranty, please refer to the official warranty documentation included with your product or contact SimpliFire customer support.
This warranty typically covers manufacturing defects and material flaws under normal use and service. Keep your proof of purchase for warranty claims.
9. Kundesupport
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact SimpliFire customer support.
- Fabrikant: SimpliFire (Part of Hearth & Home Technologies)
- Online ressourcer: Visit the official SimpliFire website or Amazon Brand Store for additional resources, FAQs, and product information.
- Brugermanual (PDF): A comprehensive user manual in PDF format is available for download her.
- Installationsmanual (PDF): For detailed installation instructions, download the manual her.
