Akitas S12 Støvsuger med ledning Brugermanual

Indledning

Thank you for choosing the Akitas S12 Corded Vacuum Cleaner. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new vacuum cleaner. Please read this manual thoroughly before first use and keep it for future reference.

Sikkerhedsinstruktioner

Følg altid grundlæggende sikkerhedsforanstaltninger, når du bruger elektriske apparater, for at mindske risikoen for brand, elektrisk stød eller personskade.

• Sørg for, at strømforsyningen voltage stemmer overens med støvsugerens typebetegnelse.
• Brug ikke støvsugeren på våde overflader eller til at opsuge væsker.
• Saml ikke brændende eller rygende genstande op, såsom cigaretter, tændstikker eller varm aske.
• Hold hår, løstsiddende tøj, fingre og alle dele af kroppen væk fra åbninger og bevægelige dele.
• Træk stikket ud af stikkontakten, når det ikke er i brug, og før rengøring eller servicering.
• Må ikke bruges med en beskadiget ledning eller stik. Hvis apparatet ikke fungerer, som det skal, er blevet tabt, beskadiget, efterladt udendørs eller tabt i vand, skal det returneres til et servicecenter.
• Dette apparat er kun til husholdningsbrug.

Produktkomponenter

The Akitas S12 vacuum cleaner comes with several components designed for versatile cleaning.

Image: The Akitas S12 vacuum cleaner shown as a full stick vacuum and as a compact handheld unit.

• Hovedenhed: Contains the motor, dustbin, and handle.
• Teleskoprør: Lightweight aluminum tube for extended reach.
• Floor Brush Head: Patented German Wessel Werk 2-in-1 brush head suitable for carpets and hard floors.
• Sprækkeværktøj: Til smalle rum og hjørner.
• Børstemundstykke: For upholstery and delicate surfaces.
• Vægmonteringsbeslag: Til praktisk opbevaring.

Opsætning og montering

Follow these steps to assemble your Akitas S12 vacuum cleaner:

1. Fastgør teleskoprøret: Insert the telescopic tube into the main unit until it clicks securely into place.
2. Fastgør gulvbørstehovedet: Connect the floor brush head to the other end of the telescopic tube, ensuring it locks firmly.
3. Håndholdt konfiguration: For handheld use, detach the telescopic tube and floor brush head. Attach the crevice tool or brush nozzle directly to the main unit.

Image: Visual representation of the vacuum cleaner in its full stick configuration, handheld mode with brush nozzle, and handheld mode with crevice tool, demonstrating assembly versatility.

Betjeningsvejledning

Operating your Akitas S12 vacuum cleaner is straightforward:

1. Strømtilslutning: Sæt strømkablet i en passende stikkontakt (240 volt).
2. Tænd/sluk: Press the power button located on the main unit handle to turn the vacuum cleaner on or off.
3. Rengøring af overflader:
   • For floors and carpets, use the floor brush head. The Wessel Werk 2-in-1 brush head is designed for optimal performance on both surfaces.
   • For hard-to-reach areas, car interiors, or upholstery, switch to the handheld configuration with the appropriate attachment (crevice tool or brush nozzle).

Image: The Akitas S12 vacuum cleaner demonstrating its versatility, being used as a handheld unit for car interiors and couch cleaning, and with the telescopic tube for high-reach areas like curtains.

Opretholdelse

Regelmæssig vedligeholdelse sikrer optimal ydeevne og forlænger din støvsugers levetid.

Tømning af skraldespanden

The Akitas S12 features a 0.8-liter bagless dustbin. Empty it regularly to maintain suction power.

1. Disconnect the vacuum cleaner from the power outlet.
2. Press the dustbin release button (one-click operation) to detach the dustbin from the main unit.
3. Hold the dustbin over a waste bin and open the bottom flap to release the collected debris.
4. Luk klappen, og sæt støvbeholderen på hovedenheden igen, indtil den klikker.

Image: A hand holding the main unit of the Akitas S12 vacuum cleaner over a waste bin, with the dustbin flap open to show debris being emptied.

Rengøring af HEPA-filteret

The HEPA filter is washable and should be cleaned regularly, especially if suction power decreases.

1. Disconnect the vacuum cleaner from the power outlet.
2. Fjern støvbeholderen som beskrevet ovenfor.
3. Drej og træk HEPA-filterenheden ud af støvbeholderen.
4. Rinse the HEPA filter and its protective mesh under cool running water until the water runs clear. Do not use detergent.
5. Lad filteret lufttørre helt i mindst 24 timer, før det samles igen. Brug ikke en tørretumbler eller direkte varme.
6. Once dry, reinsert the filter assembly into the dustbin and reattach the dustbin to the main unit.

Image: Hands demonstrating the process of rinsing both the pleated HEPA filter and its plastic mesh housing under running water.

Important: All bagless cylinder vacuums require checking for blockage and filter cleaning. Failure to check blockage and filters may result in overheating, power cutoff, or reduced suction power.

Image: A warning sign stating the importance of checking for blockages and cleaning filters in bagless cylinder vacuums to prevent overheating or reduced suction.

Fejlfinding

If you encounter issues with your Akitas S12 vacuum cleaner, refer to the table below for common problems and solutions.

Specifikationer

• Model: S12
• Mærke: Akitas
• Magt: 600 watt
• Sugekraft: 17 KPa
• Voltage: 240 volt
• Skraldespand Kapacitet: 0.8 liter
• Filtersystem: True Cyclone HEPA Filtration (Washable)
• Støjniveau: 68 dB
• Produktdimensioner: 30 x 15 x 95 cm
• Varens vægt: 2.8 kg
• Særlige funktioner: Portable, Lightweight, Washable Filter, HEPA, Patented German Wessel Werk 2-in-1 Brush Head, Aluminium Telescopic Tube, Wall Mount Bracket Inclusive.

Garanti og support

For warranty information and customer support, please refer to the documentation included with your purchase or contact Akitas customer service directly. Specific warranty terms may vary by region and retailer.
