1. Introduktion
Thank you for choosing the Billboard Chroma Clear Wireless Speaker, model BB-S11747. This portable speaker is designed to provide a clear audio experience with the added visual appeal of LED lights. It features Bluetooth wireless connectivity, an integrated FM radio, and an IPX4 water-resistant rating, making it suitable for various environments. This manual provides detailed instructions for the proper use and maintenance of your speaker.
2. Pakkens indhold
Tjek venligst pakken for følgende varer:
- Billboard Chroma Clear Wireless Speaker (BB-S11747)
- Strømkabel
- Brugervejledning (dette dokument)

Image: The Billboard Chroma Clear Wireless Speaker shown in its retail packaging, highlighting the brand and key features.
3. Produktet er slutview
Gør dig bekendt med højttalerens komponenter og betjeningselementer.

Billede: Side view of the speaker, displaying the control panel with power, mode, light, volume up, and volume down buttons, along with the carrying strap.
- Power knap: Tryk og hold nede for at tænde/slukke. Kort tryk for afspil/pause.
- Mode-knap (M): Short press to switch between Bluetooth, FM Radio, and Micro SD modes.
- Lys knap: Kort tryk for at skifte mellem LED-lystilstande.
- Lydstyrke op (+): Short press to increase volume. Long press for next track (in Bluetooth/Micro SD mode) or next station (in FM mode).
- Skrue ned for lyden (-): Short press to decrease volume. Long press for previous track (in Bluetooth/Micro SD mode) or previous station (in FM mode).
- Opladningsport: Til tilslutning af strømkablet.
- Micro SD -kortplads: Til afspilning af musik direkte fra et Micro SD-kort.
- AUX-indgang: For wired audio connection (3.5mm).
4. Opsætning
4.1 Opladning af højttaleren
Oplad højttaleren helt før første brug.
- Connect the provided power cable to the speaker's charging port.
- Tilslut den anden ende af kablet til en kompatibel USB-strømadapter (medfølger ikke) eller en computers USB-port.
- Opladningsindikatorlampen lyser. Den slukker eller skifter farve, når opladningen er færdig.
- En fuld opladning giver cirka 8 timers spilletid.
4.2 Tænd/sluk
- For at tænde: Tryk og hold nede Power knap until you hear an audible prompt or see the LED lights activate.
- For at slukke: Tryk og hold nede Power knap igen, indtil højttaleren slukker.
4.3 Bluetooth -parring
Sådan tilslutter du din højttaler til en Bluetooth-aktiveret enhed:
- Sørg for, at højttaleren er tændt og i Bluetooth-tilstand. Hvis ikke, tryk kort på Tilstandsknap (M) until you hear the Bluetooth pairing prompt. The LED lights may flash to indicate pairing mode.
- Aktiver Bluetooth på din enhed (smartphone, tablet, computer).
- Søg efter available Bluetooth devices. The speaker will appear as "Billboard Chroma Clear" or similar.
- Select the speaker from the list to pair. Once connected, you will hear a confirmation sound.
- Højttaleren vil automatisk forsøge at genoprette forbindelsen til den sidst parrede enhed, når den tændes.
4.4 FM-radiofunktion
To use the integrated FM radio:
- Tænd for højttaleren.
- Tryk kort på Tilstandsknap (M) for at skifte til FM-radiotilstand.
- For at automatisk scanne og gemme tilgængelige stationer skal du trykke på og holde Power knap (Play/Pause button in this context). The speaker will scan and store stations.
- For at skifte mellem gemte stationer skal du trykke længe på Lydstyrke op (+) or Skrue ned (-) knapper.
5. Betjeningsvejledning
5.1 Music Playback (Bluetooth/Micro SD)
- Afspil/pause: Tryk kort på Power knap.
- Lydstyrkekontrol: Kort tryk Lydstyrke op (+) to increase, short press Skrue ned (-) at falde.
- Næste nummer: Langt tryk Lydstyrke op (+).
- Forrige nummer: Langt tryk Skrue ned (-).
5.2 LED-lystilstande
The speaker features dynamic LED lights.
- Tryk kort på Lys knap to cycle through different light patterns and colors.
- Continue pressing to find your preferred light mode or to turn the lights off.

Image: The Billboard Chroma Clear Wireless Speaker illuminated with vibrant, multi-colored LED lights, showcasing its aesthetic feature.
5.3 Håndfri opkald
Når højttaleren er tilsluttet via Bluetooth, kan den bruges til håndfri opkald.
- Besvar opkald: Tryk kort på Power knap when an incoming call rings.
- Afslut opkald: Tryk kort på Power knap under et opkald.
- Afvis opkald: Tryk længe på Power knap when an incoming call rings.
6. Vedligeholdelse
6.1 Rengøring
- Ensure the speaker is turned off and disconnected from any power source before cleaning.
- Tør ydersiden af med en blød, damp cloth. Do not use abrasive cleaners, alcohol, or solvents.
- Avoid getting moisture into any ports or openings.
6.2 Vandtæthed (IPX4)
The speaker has an IPX4 rating, meaning it is resistant to splashing water from any direction.
- Nedsænk ikke højttaleren i vand.
- Sørg for, at alle portdæksler er forsvarligt lukket for at opretholde vandtætheden.
- If the speaker gets wet, wipe it dry thoroughly before charging or using it again.
6.3 Opbevaring
- Opbevar højttaleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
- Hvis batteriet opbevares i længere tid, skal det oplades med jævne mellemrum for at forlænge dets levetid.
7. Fejlfinding
| Problem | Løsning |
|---|---|
| Højttaleren tænder ikke. | Ensure the battery is charged. Connect the speaker to a power source using the provided cable. |
| Kan ikke parres via Bluetooth. |
|
| Ingen lyd eller lav lydstyrke. |
|
| FM-radiomodtagelsen er dårlig. |
|
8. Specifikationer

Image: The Billboard Chroma Clear Wireless Speaker with its approximate dimensions (40cm depth, 20cm width, 30cm height) indicated.
| Feature | Detalje |
|---|---|
| Modelnavn | BB-S11747 |
| Højttaler type | Atmosfærisk |
| Særlige funktioner | Wireless Connectivity, Water Resistant (IPX4), LED Lights, FM Radio |
| Anbefalet brug | Bærbar, Udendørs |
| Farve | Gennemsigtig |
| Dimensioner (dybde x bredde x højde) | 40 cm x 20 cm x 30 cm |
| Vandtæt vurdering | IPX4 (stænksikker) |
| Kontrolmetode | Taktile knapper |
| Trådløs teknologi | Bluetooth |
| Strømkilde | Batteri |
| Gennemsnitlig batterilevetid | 8 timer |
| Understøttede radiobånd | FM |
| Materiale | Plastic or metal casing, synthetic components |
| Lydudgangstilstand | Stereoanlæg |
9. Garanti og support
The Billboard Chroma Clear Wireless Speaker BB-S11747 comes with a limited warranty. Please refer to the warranty card included in your package for specific terms and conditions.
For technical support, troubleshooting assistance, or warranty claims, please contact Billboard customer service through their official webwebstedet eller forhandleren, hvor produktet blev købt.
Online ressourcer: For additional information and FAQs, visit the official Billboard product support page.
