Yaheetech Metal Bed Frame 90 x 190 cm

1. Introduktion

Thank you for choosing the Yaheetech Metal Bed Frame. This manual provides essential information for the safe assembly, proper use, and effective maintenance of your new bed frame. Please read these instructions carefully before beginning assembly and retain them for future reference.

Figure 1: Yaheetech Metal Bed Frame (90 x 190 cm, Black)

2. Sikkerhedsoplysninger

• Saml altid sengerammen på en blød, ren overflade for at forhindre skader på produktet eller dit gulv.
• Sørg for, at alle dele er til stede og ubeskadigede før montering. Fortsæt ikke monteringen, hvis der mangler eller er beskadigede dele.
• Spænd alle skruer og bolte forsvarligt, men overspænd ikke for at undgå at gevindene bliver beskadiget.
• Regularly check all fasteners to ensure they remain tight. Loose fasteners can compromise stability.
• Lad ikke børn klatre på sengerammen under montering eller brug.
• The maximum weight capacity for this bed frame is 180 kg (397 lbs). Do not exceed this limit.
• Use only the recommended mattress size (90 x 190 cm) to ensure proper fit and safety.

3. Pakkens indhold

Kontroller venligst, at alle komponenterne nedenfor er inkluderet i din pakke. Hvis der mangler dele, bedes du kontakte kundesupport.

• Hovedgærde- og fodgærdesektioner
• Sideskinner
• Metallameller (12 stk.)
• Støtteben (6 stk.)
• Assembly Hardware (screws, bolts, L-shaped plates, Allen key)

Figur 2: Eksploderet view and dimensions of the bed frame components.

4. Opsætnings- og monteringsvejledning

Follow these steps carefully to assemble your Yaheetech Metal Bed Frame.

1. Udpak og identificer dele: Lay out all components on a clean, soft surface. Refer to the parts list to ensure everything is present.
2. Fastgør sidehejs til hovedgærde og fodgærde: Connect the side rails to the headboard and footboard using the provided bolts and L-shaped plates. Ensure all connections are secure.
3. Installer støtteben: Attach the central support legs to the designated points on the side rails or central beam.
4. Indsæt metallameller: Carefully place each metal slat into the designated notches on the side rails. Ensure each slat is fully seated and secured. Some slats may require a firm press to click into place.


   Figure 3: Aligning and securing metal slats.

5. Sikre forbindelser: Use the provided Allen key to tighten all bolts and screws. Ensure all L-shaped plates are firmly fastened for maximum stability.


   Figure 4: Fastening L-shaped plates for structural stability.
6. Endelig kontrol: Once assembled, gently shake the frame to ensure it is stable and all connections are tight.

5. Betjeningsvejledning

5.1 Madrasplacering

Place your 90 x 190 cm mattress directly onto the assembled metal slats. The design of the bed frame, including the slightly recessed slats, helps to prevent the mattress from sliding.

Figure 5: Built-in slats prevent mattress from sliding.

5.2 Opbevaring under sengen

The bed frame offers approximately 32 cm (12.6 inches) of clearance underneath, providing ample space for storage boxes, luggage, or other items. This maximizes storage efficiency in your bedroom.

Figure 6: Under-bed storage space.

6. Vedligeholdelse

• Rensning: Tør metalrammen af ​​med en blød kludamp klud. Undgå slibende rengøringsmidler eller barske kemikalier, der kan beskadige overfladen.
• Fastgørelseskontrol: Periodically (e.g., every 3-6 months) check all bolts and screws and retighten if necessary to maintain stability and prevent squeaking.
• Gulvbeskyttelse: The bed frame is equipped with bottom rubber caps to protect your floor from scratches. Ensure these caps remain in place.


  Figure 7: Features including under-bed storage and headboard design.

7. Fejlfinding

• Knirkende lyde: Squeaking often indicates loose connections. Re-tighten all bolts and screws. Ensure all slats are properly seated.
• Madrasglidende: If the mattress slides, ensure it is correctly positioned within the frame's recessed area. Check that all slats are securely in place.
• Ustabilitet: If the bed frame feels unstable, verify that all components are correctly assembled and all fasteners are fully tightened.

8. Specifikationer

Figur 8: Visuel repræsentation af produktspecifikationer.

9. Garanti og support

For information regarding warranty coverage or to obtain customer support, please refer to the purchase documentation or contact Yaheetech directly through their official website or the retailer where the product was purchased. Please have your model number (YA-00128897) and purchase date available when contacting support.
