Peg Perego Viaggio Shuttle Booster Car Seat Instruction Manual

1. Introduktion

This manual provides essential instructions for the proper installation, use, and maintenance of your Peg Perego Viaggio Shuttle Booster Car Seat. Please read this manual thoroughly before using the product and retain it for future reference. Correct usage ensures the safety and comfort of your child.

Billede 1.1: Overview of the Peg Perego Viaggio Shuttle Booster Car Seat, highlighting its suitability for children weighing 40-120 lbs and up to 63 inches tall.

The Viaggio Shuttle is designed to provide a safe and comfortable seating solution for older children who have outgrown their forward-facing car seats but are not yet ready for adult seat belts alone. It features an integrated rigid LATCH system for secure installation and a comfortable seating surface with breathable microfiber fabric.

2. Sikkerhedsoplysninger

ADVARSEL: Manglende overholdelse af disse instruktioner kan resultere i alvorlig skade eller død for dit barn.

• This booster seat is suitable for children weighing between 40 lbs (18 kg) and 120 lbs (54 kg), and with a height up to 63 inches (160 cm).
• Always secure the child with the vehicle's lap and shoulder belt system. The lap belt must fit low across the hips, touching the thighs, and the shoulder belt must fit snugly across the center of the child's shoulder and chest.
• Never use this booster seat with only a lap belt.
• Ensure the booster seat is properly installed and secured in the vehicle, even when unoccupied, to prevent it from becoming a projectile in a crash.
• Do not use this booster seat if it has been involved in a crash, even if there is no visible damage. Replace it immediately.
• Never leave a child unattended in the booster seat.
• Refer to your vehicle owner's manual for specific information regarding child restraint installation and seating positions.

3. Pakkens indhold

Kontroller, at alle komponenter er til stede før installation:

• Peg Perego Viaggio Shuttle Booster Car Seat
• Kopholder
• Adjustable Shoulder Clip (for vehicle seat belt positioning)

Image 3.1: The Peg Perego Viaggio Shuttle Booster Car Seat, shown with the included cup holder attached.

Image 3.2: The detachable cup holder, designed for convenient drink access.

4. Opsætning og installation

The Viaggio Shuttle features an integrated rigid LATCH system for secure attachment to your vehicle's LATCH anchors. If your vehicle does not have LATCH anchors, the system can be retracted, and the booster can be secured using the vehicle's seat belt.

4.1. Identifying LATCH Anchors

Locate the lower LATCH anchors in your vehicle's back seat. These are typically found in the crease between the seat back and the seat cushion, often marked with a symbol or label.

4.2. Installing with Integrated Rigid LATCH

1. Forlæng LATCH-stik: Pull the yellow LATCH connectors out from the front of the booster seat until they click into the extended position.


Image 4.1: The booster seat with its integrated rigid LATCH connectors fully extended, ready for attachment.

2. Attach to Vehicle Anchors: Align the LATCH connectors with your vehicle's lower LATCH anchors. Push the booster seat firmly against the vehicle seat back until both LATCH connectors click securely onto the anchors.
3. Bekræft forbindelsen: Pull on the booster seat to ensure it is tightly secured and does not move more than one inch side-to-side or front-to-back. The exclusive Blind Lock System prevents inadvertent release.

4.3. Installing without LATCH (Seat Belt Only)

If your vehicle does not have LATCH anchors, or if you prefer to use the vehicle's seat belt for installation:

1. Retract LATCH Connectors: Push the yellow LATCH connectors back into the booster seat until they are fully retracted and flush with the booster's base.


Image 4.2: The booster seat with its integrated rigid LATCH connectors retracted, suitable for installation using only the vehicle's seat belt.

2. Position Booster: Place the booster seat firmly on the vehicle seat.
3. Secure Child with Seat Belt: Follow the instructions in Section 5.1 for securing your child with the vehicle's lap and shoulder belt. The vehicle's seat belt will also secure the booster seat when a child is seated in it.

5. Betjeningsvejledning

5.1. Sikring af dit barn

1. Position Barn: Have your child sit squarely on the booster seat, with their back against the vehicle seat back.
2. Route Lap Belt: Guide the vehicle's lap belt across your child's upper thighs, ensuring it sits low on the hips and not across the abdomen.
3. Rute skulderbælte: Guide the vehicle's shoulder belt across your child's chest and shoulder. It should rest snugly across the center of the shoulder, not on the neck or off the shoulder.
4. Use Shoulder Clip (if needed): If the vehicle's shoulder belt does not fit correctly, use the included adjustable shoulder clip to position the belt properly. Attach the clip to the vehicle's shoulder belt and adjust its height to ensure the belt crosses the child's shoulder correctly.
5. Spænde og stram: Insert the seat belt buckle into the vehicle's buckle receiver until it clicks. Pull the shoulder belt upwards to remove any slack from both the lap and shoulder portions of the belt.

Billede 5.1: Side view of the booster seat, illustrating proper positioning of the vehicle's lap and shoulder belt for a child.

5.2. Using the Cup Holder

The included cup holder can be attached to either side of the booster seat for convenient access to drinks. Simply slide the cup holder into the designated slot on the side of the booster until it clicks into place.

6. Vedligeholdelse og rengøring

Regular maintenance and cleaning will prolong the life of your booster seat.

• Stofbetræk: The fabric cover, made from innovative microfiber, is breathable and absorbs moisture. It can be removed for cleaning. Refer to the care label on the fabric for specific washing instructions. Typically, machine wash on a delicate cycle with cold water and mild detergent, then air dry. Do not bleach or tumble dry.
• Plast dele: Tør plastikdele af med adamp klud og mild sæbe. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• LATCH-stik: Keep LATCH connectors clean and free of debris to ensure proper function.
• Inspektion: Periodically inspect the booster seat for any signs of wear, damage, or loose parts. If any damage is found, discontinue use and contact customer support.

7. Fejlfinding

If you encounter issues with your Viaggio Shuttle Booster Car Seat, refer to the following common problems and solutions:

• Booster Seat is Loose After LATCH Installation:
  • Ensure the LATCH connectors are fully extended and securely clicked onto the vehicle's LATCH anchors.
  • Push the booster seat firmly into the vehicle seat back to remove any slack.
  • Verify that the vehicle's LATCH anchors are correctly identified and used.
• Vehicle Seat Belt Does Not Fit Child Correctly:
  • Ensure the child meets the minimum weight and height requirements for the booster seat.
  • Adjust the vehicle's headrest if it interferes with the shoulder belt path.
  • Use the included adjustable shoulder clip to guide the shoulder belt across the center of the child's shoulder.
  • Confirm the lap belt is low on the hips, not on the abdomen.
• Cup Holder Does Not Attach Securely:
  • Ensure the cup holder is aligned correctly with the slot on the booster seat.
  • Skub fast, indtil det klikker på plads.
  • Check for any obstructions in the slot.

If problems persist, contact Peg Perego Customer Support.

8. Specifikationer

Image 8.1: Visual representation of the booster seat's dimensions.

9. Garanti og support

Specific warranty details are not provided in this manual. For information regarding the product warranty, please refer to the warranty card included with your purchase or visit the official Peg Perego website. For customer support, technical assistance, or to order replacement parts, please contact Peg Perego directly through their official channels.

Du kan finde mere information og kontaktoplysninger på Peg Perego Store on Amazon.
