1. Introduktion
Thank you for choosing the Silonn Commercial Ice Maker Machine. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new ice maker. Please read it thoroughly before initial use and keep it for future reference.
Figure 1: Silonn Commercial Ice Maker Machine (SLIM11)
2. Sikkerhedsoplysninger
DANGER: Risk of Fire or Explosion. Flammable Refrigerant Used.
- Brug ikke mekaniske anordninger til at afrime ismaskinen.
- Punkter ikke kølemiddelslanger.
- Ensure the ice maker is placed upright for 24 hours before plugging it in. This is a crucial step for proper operation and great ice production.
- Always check the dimensions and item weight to ensure it fits your intended space.
- Use only food-grade materials for water and cleaning solutions.
- Hold apparatet væk fra varmekilder og direkte sollys.
3. Produktet er slutview & Hvad er der i æsken
The Silonn Commercial Ice Maker (SLIM11) is designed for efficient ice production, capable of producing up to 100 lbs of ice in 24 hours with a 33 lbs storage capacity. It features an automatic self-cleaning function and an intuitive LCD control panel.
Inkluderede komponenter:
- Commercial Ice Maker (SLIM11)
- Is Scoop
- Vandfilter
- Vandtilførselsslange
- Water Outlet (Drain) Hose
- Brugermanual
Figur 2: Ismaskine og tilbehør
4. Opsætning
4.1 Placering
- Placer ismaskinen på en flad, stabil overflade.
- Sørg for tilstrækkelig ventilation omkring enheden. Bloker ikke luftventilerne.
- Allow the unit to stand upright for 24 hours before plugging it in.
4.2 Vandtilslutning
The ice maker supports direct water line connection for continuous operation.
Figure 3: Water Inlet, Power, and Drain Connections
- Vandindtag: Connect the provided water inlet hose to a potable water supply. Ensure the connection is secure to prevent leaks.
- Vandafløb: Connect the water outlet (drain) hose to a suitable drain. Ensure proper slope for water drainage.
- Magt: Sæt netledningen i en jordet stikkontakt.
4.3 Indledende rengøring
Before first use, perform a self-cleaning cycle as described in the Maintenance section to ensure hygiene.
5. Betjeningsvejledning
The ice maker features an intuitive LCD control panel for easy operation.
Figure 4: LCD Control Panel
5.1 Fremstilling af is
- Sørg for, at vandforsyningen er tilsluttet og tændt.
- Tryk på ON/OFF button to start the ice making process.
- The ice maker can produce ice in approximately 8-15 minutes per cycle.
5.2 Justering af istykkelse
You can adjust the thickness of the ice cubes (thin, medium, or thick) using the control panel.
- Brug +/- buttons to adjust the ice making process and time, which influences ice thickness.
- Thinner ice cubes are produced faster (e.g., 11 minutes), while thicker cubes take longer (e.g., 20 minutes).
Figure 5: Ice Thickness Options
5.3 Timer funktion
The timer allows you to schedule when the ice maker turns on or off.
- Tryk hurtigt på TIMER button to enter the reservation time setting.
- Brug +/- buttons to set the desired time for the unit to turn on or off.
Figure 6: 24-Hour Time Reservation Feature
6. Vedligeholdelse
6.1 Automatisk selvrensning
The ice maker is equipped with a self-cleaning function for convenience.
- Hold REN button for 5 seconds to start the self-cleaning function.
- The machine will automatically perform a cleaning cycle.
6.2 Generel rengøring
- Regularly clean the exterior with a soft, damp klæde.
- For thorough cleaning, disconnect the water hoses and drain any remaining water.
- The ice basket and scoop should be cleaned regularly with warm water and mild detergent.
7. Fejlfinding
If you encounter issues with your Silonn Ice Maker, refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Ismaskinen producerer ikke is. | Ingen vandforsyning eller lav vandstand. | Ensure water inlet is connected and water supply is on. Check for any kinks in the water line. |
| Isterningerne er for tynde eller for tykke. | Incorrect ice thickness setting. | Juster istykkelsen ved hjælp af +/- knapperne på kontrolpanelet. |
| Ice maker displays an error code (e.g., E2). | Specifik intern funktionsfejl. | Refer to the full user manual for specific error code meanings. Often, restarting the machine or performing a self-clean cycle can resolve minor issues. If the problem persists, contact customer support. |
| Ice basket is full, but machine continues to make ice. | Ice sensor malfunction or obstruction. | Clear any ice blocking the sensor. If the issue continues, contact customer support. |
8. Specifikationer
| Feature | Specifikation |
|---|---|
| Mærke | Silonn |
| Modelnavn | Kommerciel Ice Maker |
| Modelnummer | SLIM11 |
| Produktdimensioner | 17.5" D x 16" B x 31" H |
| Varens vægt | 66.9 pund |
| Kapacitet (isproduktion) | 100 Pounds per 24 hours |
| Kapacitet (isopbevaring) | 33 pund |
| Wattage | 200 watt |
| Voltage | 115 volt |
| Kølemiddel | R290a |
| Materiale | Rustfrit stål |
| Installationstype | Frit stående |
| UPC | 810145630051 |
9. Officiel produktvideo
Video 1: Silonn Commercial Ice Maker Machine (100LBS in 24H) - This video provides a visual overview of the ice maker's features and operation, including its ice production capabilities and ease of use.
10. Garanti og support
For warranty information, technical support, or any inquiries regarding your Silonn Commercial Ice Maker, please refer to the contact details provided in your product packaging or visit the official Silonn website. Customer support is available to assist you with any product-related concerns.
