1. Produktet er slutview
The THOMSON 43-inch QLED Smart Android TV (Model 43QA2S13) offers an immersive viewing experience with its Ultra High Definition (UHD) display and QLED technology. Enjoy vibrant colors and sharp details, four times more precise than Full HD. This smart TV integrates Android TV, providing access to a vast library of applications, intelligent voice control with Google Assistant, and built-in Chromecast for seamless content streaming. Its sleek, frameless design on three sides ensures a captivating visual experience.
Billede 1.1: Front view of the THOMSON 43-inch QLED Smart Android TV, showcasing its vibrant display and slim bezels.
2. Opsætningsvejledning
2.1 Udpakning
Tag forsigtigt tv'et og alt tilbehør ud af emballagen. Gem emballagematerialerne til senere transport eller opbevaring.
2.2 Stand Assembly / Wall Mounting
Your TV comes with two stand feet for tabletop placement.
- Attach the stand feet to the designated slots at the bottom of the TV using the provided screws. Ensure they are securely fastened.
- For wall mounting, use a VESA compatible wall mount (200x200 mm, not included). Refer to the wall mount's instructions for proper installation.
Billede 2.1: Front view of the TV with its two stand feet attached.
Billede 2.2: Side profile af tv'et, hvilket viser dets slanke design.
Billede 2.3: Diagram illustrating the TV's dimensions (102.3 cm width, 59 cm height with stand, 30 cm depth with stand).
2.3 Tilslutning af enheder
Tilslut dine eksterne enheder til tv'et ved hjælp af de relevante porte.
- HDMI (x3): Til tilslutning af Blu-ray-afspillere, spillekonsoller, set-top-bokse osv.
- USB (x2): Til tilslutning af USB-lagerenheder for at afspille medier.
- LAN: Til kablet internetforbindelse.
- Audio Out (Digital Optical): Til tilslutning til soundbars eller hjemmebiografsystemer.
- Satellit (DVB-S2): For satellite antenna connection.
- Antenna (DVB-T2/C):): For terrestrial or cable antenna connection.
- AV-indgang: For connecting older devices with composite video/audio outputs.
- Common Interface (CI+): For inserting a CAM module and smart card for encrypted channels.
Billede 2.4: Bag view of the TV, illustrating the various input and output ports available for connectivity.
2.4 Indledende opsætning
After connecting the power cable and turning on the TV, follow the on-screen instructions for the initial setup:
- Vælg dit foretrukne sprog.
- Opret forbindelse til dit Wi-Fi-netværk, eller brug en kablet LAN-forbindelse.
- Log ind med din Google-konto for at få adgang til Android TV-funktioner og -apps.
- Scan for available TV channels using the built-in triple tuner.
- Accept terms and conditions to complete the setup.
3. Betjening af dit TV
3.1 Fjernbetjening
The ergonomic, backlit remote control provides easy navigation and access to all TV functions.
- Google Assistent-knap: Press to activate voice control and search for content, control smart home devices, or get information.
- Favorites Button: Customize this button to quickly launch your most-used application with a single click.
- The backlight ensures visibility even in dim lighting conditions.
Billede 3.1: A user interacting with the TV using the Google Assistant voice command feature on the remote control.
3.2 Android TV-funktioner
Your THOMSON TV runs on Android TV, offering a rich entertainment experience.
- Appadgang: Browse and download over 400,000 movies and TV shows from various applications available on the Google Play Store (e.g., Netflix, Prime Video, Disney+, YouTube, Spotify, Apple TV).
- Chromecast indbygget: Wirelessly stream movies, music, and videos from compatible devices (smartphones, tablets, computers) directly to your TV.
- Google Assistant: Use voice commands to search for content, control playback, adjust settings, and manage smart home devices.
Billede 3.2: The Android TV home screen, displaying popular streaming service applications and content recommendations.
3.3 Billed- og lydkvalitet
Experience superior visual and audio performance with advanced technologies.
- QLED teknologi: Delivers vibrant and realistic colors through Quantum Dots, enhancing brightness and color accuracy.
- 4K UHD-opløsning: Provides incredibly sharp and detailed images with 3840 x 2160 pixels.
- HDR (High Dynamic Range) with Dolby Vision: Improves contrast, brightness, and color reproduction for a more realistic and immersive picture, especially in scenes with extreme light and shadow.
- Dolby Audio: Creates a dynamic and immersive sound experience.
Billede 3.3: Visual comparison demonstrating the enhanced contrast and color depth provided by Dolby Vision compared to standard dynamic range (SDR).
Billede 3.4: An illustration depicting the immersive, multi-dimensional sound experience created by Dolby Atmos technology.
4. Vedligeholdelse
Korrekt vedligeholdelse sikrer dit TV's levetid og optimale ydeevne.
- Rengøring af skærmen: Tør forsigtigt skærmen af med en blød, fnugfri klud. Brug en skærmrengøringsopløsning, der er specielt designet til elektronik, til genstridige pletter, og påfør den på kluden, ikke direkte på skærmen.
- Rengøring af kabinettet: Use a soft, dry cloth to clean the TV's cabinet. Avoid using abrasive cleaners or solvents.
- Softwareopdateringer: Ensure your TV's software is up-to-date. The TV will typically notify you of available updates. You can also check manually in the settings menu. Regular updates improve performance and security.
- Strømstyring: For optimal performance and to clear temporary data, it is recommended to occasionally power off the TV completely (unplug from the wall) for a few minutes, especially if you notice any slowdowns.
5. Fejlfinding
Hvis du støder på problemer med dit tv, kan du se følgende almindelige problemer og løsninger.
| Problem | Mulig årsag/løsning |
|---|---|
| Ingen strøm |
|
| Intet billede / Sort skærm |
|
| Ingen lyd |
|
| Fjernbetjeningen reagerer ikke |
|
| Problemer med netværksforbindelse |
|
For more complex issues, please refer to the support section or contact customer service.
6. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Thomson |
| Modelnummer | 43QA2S13 |
| Skærmstørrelse | 43 tommer (109 cm) |
| Displayteknologi | QLED |
| Opløsning | 3840 x 2160 pixels (4K UHD) |
| Opdateringshastighed | 60 Hz |
| Operativsystem | Android TV |
| Særlige funktioner | Chromecast built-in, Google Assistant, HDR (Dolby Vision), Dolby Audio |
| Forbindelse | 3x HDMI, 2x USB, Wi-Fi, Bluetooth, LAN, Digital Optical Audio Out, AV In |
| Tuner | DVB-C/S2/T2 (Triple Tuner) |
| Lydkonfiguration | 2.0 |
| Produktmål (L x B x H) | 102.3 x 30 x 166.7 cm (med stativ) |
| Vægt | 6.3 kg |
| VESA vægmonteringsstøtte | 200x200 mm (mount not included) |
6.1 Energieffektivitet
This product has an energy efficiency rating of F.
Billede 6.1: EU Energy Label for the THOMSON 43QA2S13 TV, showing its energy efficiency class F.
For more details, visit the EPREL database: https://eprel.ec.europa.eu/qr/1471757
7. Garanti og support
Your THOMSON 43-inch QLED Smart Android TV comes with a comprehensive 3 års producentgaranti, demonstrating our commitment to quality and reliability.
For technical assistance, troubleshooting beyond this manual, or warranty claims, please contact THOMSON customer support.
- Fabrikant: STRØMVIEW GMBH
- Refer to the official THOMSON website or your purchase documentation for the most up-to-date contact information and support resources in your region.
