Vaorlo M-F8 Bluetooth 5.2 trådløse øretelefoner brugermanual

1. Introduktion

Thank you for choosing the Vaorlo M-F8 Bluetooth 5.2 Wireless Ear Hook Earphones. These earphones are designed for sports and business use, offering a secure fit, high-fidelity audio, and advanced features like low latency and intelligent noise cancellation. Please read this manual carefully before using the product to ensure proper operation and maintenance.

2. Pakkens indhold

Tjek venligst pakken for følgende varer:

• 1 x Vaorlo M-F8 Wireless Ear Hook Headset
• 1 x opladningskabel (USB)
• 1 x brugermanual
• 1 x opladningsetui

Hvis der mangler eller er beskadigede varer, bedes du kontakte din forhandler.

3. Produktet er slutview

The Vaorlo M-F8 earphones feature an ergonomic ear-hook design for a secure and comfortable fit, especially during physical activity. They incorporate advanced audio technology for clear sound and effective noise reduction.

Figure 3.1: Vaorlo M-F8 Wireless Earphone (White model shown). This image displays the overall design of the earphone, highlighting its ear-hook structure and the main body with a control button and LED indicator.

3.1 Nøglefunktioner

• Bluetooth 5.2: Provides stable and low-latency wireless connection up to 10 meters.
• Ear-hook Design: Ergonomic and anti-falling lug type, ensuring a secure fit during sports and active use.
• IPX4 Vandtæt: Resistant to splashes and sweat, suitable for workouts.
• Intelligent støjreduktion: Optimizes sound clarity for HD calls and reduces ambient noise.
• High-Definition Surround Sound: Equipped with a 13mm high-quality moving coil unit and composite diaphragm for rich bass and clear treble.
• Lang batterilevetid: Up to 20 hours of music/talk time on a single charge.

Figure 3.2: Ergonomic Anti-Falling Lug Type Design. This image illustrates how the ear-hook design conforms to the human auricle, dispersing pressure points for a stable and secure fit, preventing the earphone from falling during movement.

Figure 3.3: High-Definition Surround Sound Quality Components. This diagram shows the internal structure of the earphone, highlighting the 13mm high-quality moving coil unit, composite diaphragm subwoofer for powerful bass, and metal diaphragm high-frequency speaker for delicate treble.

4. Opsætning og parring

4.1 Opladning af øretelefonerne

Before first use, fully charge the earphones. Connect the provided USB charging cable to the charging port on the earphone and to a USB power source (e.g., computer, wall adapter). The LED indicator will show charging status and turn off or change color when fully charged.

• Charging time: Approximately 60 minutes.
• Sørg for, at opladningsporten er tør før opladning for at forhindre beskadigelse.

4.2 Tænd/sluk

• Tænd: Press and hold the multi-function button for approximately 3 seconds until the LED indicator flashes.
• Sluk: Tryk og hold multifunktionsknappen nede i cirka 5 sekunder, indtil LED-indikatoren slukker.

4.3 Bluetooth -parring

To pair the earphones with your device for the first time:

1. Sørg for, at høretelefonerne er slukkede.
2. Press and hold the multi-function button for about 5-7 seconds until the LED indicator flashes red and blue alternately, indicating pairing mode.
3. On your smartphone or Bluetooth-enabled device, enable Bluetooth.
4. Søg efter available devices and select "M-F8" from the list.
5. Når der er oprettet forbindelse, vil LED-indikatoren typisk blinke blåt langsomt eller slukke, og du vil høre en bekræftelsestone.
6. The earphones will automatically reconnect to the last paired device when powered on, if Bluetooth is enabled on the device.

5. Betjeningsvejledning

5.1 Musikafspilning

• Afspil/pause: Tryk kort én gang på multifunktionsknappen.
• Næste sang: Dobbelttryk på multifunktionsknappen.
• Forrige sang: Tryk tre gange på multifunktionsknappen.

5.2 Opkaldshåndtering

• Besvar/afslut opkald: Short press the multi-function button once during an incoming call or active call.
• Afvis opkald: Press and hold the multi-function button for approximately 2 seconds during an incoming call.

5.3 Stemmeassistent

• Aktiver stemmeassistent: Press and hold the multi-function button for approximately 1 second (or as per device specific instruction) to activate your device's voice assistant (e.g., Siri, Google Assistant).

5.4 Støjreduktion

The M-F8 earphones feature intelligent noise cancellation for improved call clarity and an immersive listening experience. This technology actively reduces ambient noise.

Figure 5.1: Intelligent Noise Reduction for HD Calls. This image shows the earphone being worn, illustrating the concept of deep noise reduction technology that optimizes sound clarity during calls.

Figure 5.2: Noise Reduction Performance Comparison. This graph visually represents the effect of noise reduction, showing a significant decrease in ambient noise levels after the noise reduction feature is applied.

6. Vedligeholdelse og pleje

• Rensning: Use a soft, dry, lint-free cloth to clean the earphones. Do not use abrasive cleaners, alcohol, or chemical solvents.
• Vandtæthed: The earphones are IPX4 waterproof, meaning they are resistant to splashing water and sweat. Do not submerge them in water or expose them to heavy rain. Ensure the charging port is dry before charging.
• Opbevaring: Store the earphones in a cool, dry place, away from extreme temperatures and direct sunlight. When not in use for extended periods, charge them periodically to maintain battery health.
• Undgå påvirkninger: Do not drop, hit, or apply excessive force to the earphones, as this may damage internal components.

7. Fejlfinding

8. Specifikationer

9. Garanti og support

This product is manufactured by Generic. For warranty information and technical support, please refer to the documentation provided at the point of purchase or contact your retailer. Please retain your proof of purchase for any warranty claims.

For further assistance, please visit the manufacturer's or retailer's support webwebsted.
