1. Vigtige sikkerhedsoplysninger
Læs og forstå alle instruktioner før montering og brug. Manglende overholdelse af disse instruktioner kan resultere i personskade eller beskadigelse af produktet.
- Forsamling: This desk requires assembly. Always follow the provided instructions and use appropriate tools. It is recommended that two people assemble the desk for ease and safety.
- Elektrisk sikkerhed: Be cautious when using the USB charging ports and power outlets to prevent electrical shock. Do not overload the outlets. Ensure all connections are secure.
- LED lys: The LED lights should be used in a well-lit environment to avoid eye strain.
- Stabilitet: This desk is designed for adult use. Always ensure the desk is stable and balanced before use to prevent tip-over hazards. Do not climb or sit on the desk.
- Vægt kapacitet: Do not exceed the maximum weight recommendation of 150 pounds for the desktop.
2. Pakkens indhold
Before beginning assembly, ensure all parts are present and in good condition. Refer to the included parts list in your package for verification.
Billede: Overview of desk components with key dimensions.
3. Opsætning og montering
The assembly process typically takes between 30 minutes to 1 hour with two people. Follow the steps carefully.
3.1. Videovejledning til montering
For a visual guide, please watch the official ODK installation video:
Video: Step-by-step installation guide for the ODK Computer Desk.
3.2. Trinvise monteringsvejledninger
- Forbered komponenter: Unpack all parts and verify against the parts list. Lay them out on a clean, soft surface to prevent scratches.
- Saml skrivebordsrammen: Connect the metal frame components using the provided screws and tools. Ensure all connections are secure but do not overtighten until the entire frame is assembled.
- Vedhæft skrivebord: Carefully place the desktop onto the assembled frame. Secure it with the designated screws.
- Installer skuffer: Expand the fabric drawers and insert them into the designated slots in the desk frame. Attach the drawer handles.
- Installer skærmstativ: Attach the adjustable monitor stand to the desktop. Choose your preferred height setting (3.2", 4.3", or 5.5" from the desktop surface) and secure it with screws.
- Install USB Power Hub: Secure the USB power hub to the designated area on the monitor stand using the provided screws.
- Fastgør LED-strimmel: Adhere the LED light strip to the underside of the monitor stand using the double-sided adhesive. Ensure the power supply connection is positioned correctly. Secure the USB wire with the provided snaps.
- Fastgør krog: Install the versatile hook on either side of the desk using the provided screws.
4. Betjeningsvejledning
4.1. USB Charging Ports & Power Outlets
The desk is equipped with 3 standard power outlets and 2 USB charging ports. Plug the desk's main power cord into a wall outlet. You can then charge your electronic devices directly from the desk.
Image: Integrated USB charging ports and power outlets.
4.2. LED-lys
The LED strip features 10 static colors, 6 brightness grades, and 10 dynamic modes. Use the switching controls to adjust the lighting to your preference. The lights also have a memory function, retaining your last setting.
Image: LED lighting features and control.
4.3. Adjustable Monitor Stand
The monitor stand can be adjusted to three different heights: 3.2 inches, 4.3 inches, and 5.5 inches. This allows for an ergonomic viewing angle suitable for various users and setups. The monitor stand is also removable without leaving screw holes on the desktop.
Image: Adjustable monitor stand height options.
4.4. Opbevaringsskuffer
The desk includes three large-capacity fabric drawers for organizing office or study supplies, keeping them dust-free and easily accessible.
Image: Three fabric storage drawers.
5. Vedligeholdelse
- Rensning: Tør skrivebordets overflader af med en blød,amp klud. Undgå skrappe kemikalier eller slibende rengøringsmidler, der kan beskadige overfladen.
- Tilspændingsskruer: Periodically check all screws and connections to ensure they remain tight. Retighten as necessary to maintain stability.
- Elektriske komponenter: Keep the USB ports and power outlets free from dust and debris. Do not expose electrical components to liquids.
- Skuffepleje: The fabric drawers can be spot cleaned with a mild detergent if needed. Ensure they are completely dry before reinserting.
6. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Skrivebordet er vakkelvornt/ustabilt. | Skruer er løse; ujævnt gulv. | Tighten all assembly screws. Adjust the foot pads on the desk legs to level the desk. |
| USB ports/power outlets not working. | Desk not plugged in; power strip switch off; faulty connection. | Ensure the desk's main power cord is securely plugged into a working wall outlet. Check if the power strip switch (if any) is on. Verify all internal connections of the power hub. |
| LED-lysene tændes ikke. | Power connection loose; remote control battery low; LED strip damaged. | Check the power connection to the LED strip. Ensure the remote control has working batteries. If issues persist, contact customer support. |
| Skufferne glider ikke gnidningsløst. | Obstruction in the drawer slot; drawer not fully expanded. | Remove the drawer and check for any obstructions. Ensure the fabric drawer is fully expanded and correctly inserted into the frame. |
7. Specifikationer
- Mærke: ODK
- Model: 55 tommer computerbord
- Produktdimensioner: 19.7" D x 55" B x 31" H
- Skrivebordsmateriale: Konstrueret træ
- Grundmateriale: Metal
- Farve: Rustic Brown (Note: Other colors may be available for different models)
- Varens vægt: 20 kilo
- Antal skuffer: 3
- Monitor Stand Heights: 3.2", 4.3", 5.5" (Adjustable)
- Strømudtag: 3 AC-udtag (120V/12A)
- USB-porte: 2 USB Charging Ports (5V-2A)
- Strømkabellængde: 4.9 fod
- LED lys: 10 Static Colors, 6 Brightness Grades, 10 Dynamic Modes, Memory Function
- Maksimal vægtanbefaling: 150 pund
- Montering påkrævet: Ja (Anbefales 2 personer)
8. Garanti og kundesupport
ODK is committed to providing high-quality products and excellent customer service. If your ODK desk arrives damaged, has missing parts, or is scratched, please contact our professional customer support team. We aim to help you solve any problems within 24 hours.
For support, besøg venligst ODK Store on Amazon eller se kontaktoplysningerne på din produktemballage.
