1. Introduktion
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Reznor UDXC-30 Natural Gas Unit Heater. Please read this manual thoroughly before attempting to install or operate the unit. Retain this manual for future reference.
Billede 1: Forside view of the Reznor UDXC-30 Natural Gas Unit Heater.
2. Vigtige sikkerhedsoplysninger
Failure to follow these safety instructions could result in property damage, personal injury, or death. Installation and service must be performed by a qualified installer, service agency, or gas supplier.
- Læs alle instruktioner, før du bruger denne varmeovn.
- Opbevar eller brug ikke benzin eller andre brændbare dampe og væsker i nærheden af dette eller noget andet apparat.
- Hvad skal du gøre, hvis du lugter gas:
- Forsøg ikke at tænde noget apparat.
- Rør ikke ved nogen elektrisk kontakt; Brug ikke nogen telefon i din bygning.
- Ring straks til din gasleverandør fra en nabos telefon. Følg gasleverandørens instruktioner.
- Hvis du ikke kan få fat i din gasleverandør, skal du ringe til brandvæsenet.
- Proper ventilation is required. Ensure adequate combustion and ventilation air supply.
- Keep the area around the heater clear and free from combustible materials, gasoline, and other flammable vapors and liquids.
- Do not obstruct the flow of combustion and ventilation air to the heater.
3. Produktfunktioner
The Reznor UDXC-30 unit heater is designed for efficient heating in various indoor environments, including garages, workshops, and commercial spaces. Key features include:
- Varmeeffekt: 30,000 British Thermal Units (BTU).
- Termisk effektivitet: Achieves an 82% thermal efficiency rating.
- Varmeveksler: Features a TCORE2 titanium-stabilized aluminized steel heat exchanger for durability.
- Tænding: Patented single-burner combustion with multi-try direct spark ignition and time lockout.
- Kontrolsystem: Integrated circuit board with a 7-segment display for status indication and troubleshooting.
- Ventilator: Low static propeller fan for quiet forced air operation.
- Montering: Threaded-nut retainers at four suspension points for ceiling or wall mounting (mounting hardware sold separately).
- Ventilation: Compatible with Category 1 double wall B-vent for vertical venting or Category 3 single wall vent pipe for horizontal sidewall venting.
- Tilgængelighed: Hinged access door panel with a quarter-turn latch and external gas connection for ease of maintenance and installation.
- Sikkerhed: Built-in enhanced disconnect switch and ETL Approved.
Image 2: Diagram highlighting standard features such as 82% AFUE efficiency and TCORE2 heat exchanger.
Image 3: Diagram highlighting additional standard features including status-indicating LED and suspension options.
4. Installationsvejledning
Proper installation is critical for the safe and efficient operation of your Reznor UDXC-30 heater. This unit is designed for indoor use only. Consult local codes and a qualified professional for installation.
4.1 Montering
- The unit can be ceiling-mounted or wall-mounted using the four threaded-nut suspension points. Mounting brackets and hardware are sold separately.
- Ensure the mounting structure can safely support the weight of the heater.
- Maintain required clearances from combustible materials as specified in the installation instructions provided with the unit.
4.2 Udluftning
- For vertical venting through a roof, use Category 1 double wall B-vent.
- For horizontal venting through a sidewall, use Category 3 single wall vent pipe.
- All venting must comply with local building codes and manufacturer specifications.
Image 4: An installed Reznor UDXC-30 unit heater in a garage setting, demonstrating ceiling mounting and venting.
5. Betjeningsvejledning
The Reznor UDXC-30 heater features an integrated circuit board with a display and status-indicating LED for user feedback and control.
5.1 Første opstart
- Ensure all gas and electrical connections are secure and properly installed.
- Tænd for gasforsyningen til enheden.
- Tænd for strømmen til enheden.
- Set your thermostat to the desired temperature. The unit will initiate its ignition sequence.
5.2 Normal drift
The heater will cycle on and off as needed to maintain the set temperature. The integrated circuit board and LED will provide status updates. Refer to the detailed operational guide included with your unit for specific sequences and error codes.
6. Vedligeholdelse
Regular maintenance ensures the longevity and efficient operation of your Reznor UDXC-30 heater. Always disconnect power and gas supply before performing any maintenance.
- Årlig inspektion: Have a qualified service technician inspect the unit annually, including the heat exchanger, burner, ignition system, and venting.
- Rensning: Keep the area around the heater clean and free of dust and debris. Periodically clean the fan blades and motor to ensure proper airflow.
- Udluftningssystem: Inspect the vent pipe for any obstructions, leaks, or corrosion.
- Gasforbindelser: Check gas connections for leaks using a soap solution (never an open flame).
Billede 5: Bagside view of the Reznor UDXC-30 unit heater, showing the fan and external connections, relevant for maintenance checks.
7. Fejlfinding
The integrated circuit board with its 7-segment display and status-indicating LED provides diagnostic information. Refer to the specific error codes and troubleshooting steps outlined in the comprehensive installation and operation manual provided with your unit.
- Ingen varme: Check power supply, gas supply, and thermostat settings. Consult the display for error codes.
- Intermitterende drift: Could indicate a sensor issue or a safety lockout. Note any displayed codes.
- Usædvanlige lyde: Investigate for obstructions in the fan or loose components.
For persistent issues, contact a qualified service technician.
8. Tekniske specifikationer
| Specifikation | Værdi |
|---|---|
| Modelnummer | UDXC-30 |
| Varmeoutput | 30,000 BTU |
| Termisk effektivitet | 82 % |
| Brændstoftype | Naturgas |
| Indendørs/Udendørs brug | Indendørs |
| Produktmål (D x B x H) | 29.75 cm x 27 cm x 13.75 cm |
| Monteringstype | Ceiling Mount / Wall Mount (with separate hardware) |
| Antal hastigheder | 2 |
| Brænder type | Strålende |
Image 6: Diagram illustrating the dimensions of the Reznor UDXC-30 unit heater.
9. Garanti og support
For warranty information, please refer to the documentation included with your purchase or contact the seller directly. For technical support or service inquiries, please reach out to the authorized Reznor service provider or the retailer from whom the unit was purchased.
