INKBIRDPLUS Smoking Gun Wood Smoke Infuser - Instruction Manual

Indledning

The INKBIRDPLUS Smoking Gun Wood Smoke Infuser is designed to quickly and easily add natural smoke flavor to various foods and drinks. This manual provides detailed instructions for safe operation, setup, maintenance, and troubleshooting to ensure optimal performance and longevity of your device.

Sikkerhedsoplysninger

• Always operate the smoking gun in a well-ventilated area.
• Opbevares utilgængeligt for børn og kæledyr.
• Do not touch the metal chamber or mesh filter immediately after use, as they will be hot. Allow to cool completely before handling.
• Use only small wood chips specifically designed for smoking guns. Do not use resins, herbs, or other materials that could produce harmful fumes.
• Ensure the unit is stable on a flat surface during operation.
• Nedsænk ikke hovedenheden i vand eller anden væske.
• Fjern batterierne, hvis enheden ikke skal bruges i en længere periode.

Pakkens indhold

Verify that all items listed below are included in your INKBIRDPLUS Smoking Gun kit:

• Smoking Gun Unit
• Flexible Hose (approx. 19.7 inches)
• Disk Lid (for smoking drinks)
• Wood Chips (6 assorted flavors)
• Mesh Filters (replacement screens)
• Rengøringsbørste
• Pincet

Image: All components included in the INKBIRDPLUS Smoking Gun Premium Kit, laid out on a wooden surface.

Opsætning

1. Batteriinstallation

1. Locate the battery compartment on the underside of the smoking gun.
2. Push the battery lock button upward and slide the battery cover forward to remove it.
3. Insert 4 PCS AA batteries, ensuring correct polarity (+/-).
4. Slide the cover back until it clicks into place, aligning the arrow with the lock symbol.

Image: Step-by-step visual guide for installing AA batteries into the smoking gun's battery compartment.

2. Assembling the Smoking Gun

• Attach the flexible hose to the smoke outlet port on the front of the smoking gun. Ensure it is securely fitted.
• If using the disk lid, insert the metal nozzle of the hose into the rubber grommet on the lid.

Betjeningsvejledning

1. Forbered træflis: Place a small amount of wood chips (approximately 1/4 of the bowl) into the top chamber of the smoking gun. Do not overfill.
2. Tænd: Press the power button on the smoking gun to activate the fan.
3. Ignite Chips: Using a lighter or kitchen torch, ignite the wood chips in the chamber. Allow them to smolder, producing smoke.
4. Apply Smoke: Direct the flexible hose towards the food or drink you wish to infuse. For best results, use a covered container, cloche, or sealed bag to trap the smoke.
5. Infusionstid: Smoke for 30 seconds to 2 minutes, depending on the desired intensity of flavor. Less is often more.
6. Sluk: Once sufficient smoke is generated, turn off the smoking gun. Allow the smoke to settle in the container for a few minutes before serving.

Image: Visual instructions demonstrating the process of adding wood chips, activating the device, igniting the chips, and infusing a drink with smoke.

Official Product Video: Operation Demonstration

Opretholdelse

Rengøring af enheden

• Ensure the smoking gun is completely cool before cleaning.
• Unscrew the metal chamber from the main unit.
• Remove the mesh filter from the chamber.
• Use the provided cleaning brush to remove any ash or residue from the chamber and mesh filter.
• The chamber and mesh filter can be washed with warm, soapy water. Rinse thoroughly and dry completely before reassembling.
• Tør hovedenheden af ​​med adamp klæde. Nedsænk ikke hovedenheden i vand.
• Clean the flexible hose by blowing air through it or using a pipe cleaner if necessary.

Billede: Et nærbillede view of the smoking gun's detachable components, illustrating how the chamber and oil cup can be easily removed for cleaning under a faucet.

Opbevaring

Store the smoking gun in a cool, dry place away from direct sunlight and extreme temperatures. Ensure all components are clean and dry before storage.

Fejlfinding

Specifikationer

Garanti og support

For warranty information and customer support, please refer to the product packaging or contact INKBIRDPLUS customer service directly. Keep your purchase receipt for warranty claims.

You can visit the official INKBIRDPLUS store for more information: INKBIRDPLUS Store
