1. Introduktion
This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your Steelplay Adventure Controller for Nintendo Switch. Please read this manual thoroughly before using the product to ensure optimal performance and longevity.
2. Pakkens indhold
- Steelplay Adventure Controller
- USB opladningskabel
- Brugervejledning (dette dokument)
3. Controllerlayout
Familiarize yourself with the buttons and features of your Steelplay Adventure Controller.
Figur 1: Front view of the Steelplay Adventure Controller. This image displays the controller's ergonomic design, featuring a teal main body, brown grips, and yellow accents on the analog sticks, D-pad, and face buttons. The layout includes two clickable analog sticks, a directional pad, A/B/X/Y action buttons, Home, Capture, Plus, Minus, and Turbo buttons.
- Venstre analoge pind: Til bevægelse og kamerastyring.
- Højre analoge pind: Til kamerastyring eller specifikke handlinger i spillet.
- D-Pad: Retningsbestemt input.
- A/B/X/Y-knapper: Handlingsknapper.
- V/H-knapper: Skulderknapper.
- ZL/ZR-knapper: Udløserknapper.
- HJEM knap: Vender tilbage til Nintendo Switch HOME-menuen.
- CAPTURE Button: Takes screenshots or video clips.
- + (Plus) Button: Start/Pause knap.
- - (Minus) Button: Vælg knap.
- TURBO knap: For setting rapid-fire functionality (refer to operating section).
- LED-indikatorer: Display connection status, player number, and charging status.
4. Opsætning og tilslutning
4.1 Indledende opladning
Before first use, fully charge the controller. Connect the USB charging cable to the controller's charging port and the other end to a USB power source (e.g., Nintendo Switch dock, USB wall adapter, computer USB port). The LED indicators will show charging status and turn off or change color when fully charged.
4.2 Parring med Nintendo Switch
- On your Nintendo Switch HOME Menu, select "Controllers".
- Select "Change Grip/Order".
- On the Steelplay Adventure Controller, press and hold the HJEM knap og den Y-knap simultaneously for a few seconds until the LED indicators start flashing rapidly. This indicates the controller is in pairing mode.
- The Nintendo Switch will detect the controller. Once detected, the LED indicators on the controller will stop flashing and remain solid, indicating a successful connection.
- Press the L+R buttons on the controller as prompted by the Switch screen to finalize the connection.
Once paired, the controller will automatically connect to your Nintendo Switch when powered on and within range.
5. Betjening af controlleren
5.1 Grundlæggende kontroller
The Steelplay Adventure Controller functions similarly to official Nintendo Switch Pro Controllers. Use the analog sticks for movement, D-pad for directional input, and A/B/X/Y buttons for in-game actions. The L/R and ZL/ZR buttons provide additional input options.
5.2 Bevægelseskontrol
The controller supports motion control functionality, allowing for immersive gameplay in compatible titles. Ensure your Nintendo Switch system software is up to date for optimal motion control performance.
5.3 TURBO Funktion
The TURBO function allows a button to be pressed repeatedly as long as it is held down, providing a rapid-fire effect.
- To activate TURBO: Tryk og hold på TURBO knap, then press the desired action button (e.g., A, B, X, Y, L, R, ZL, ZR). The button will now have TURBO functionality.
- To deactivate TURBO: Tryk og hold på TURBO knap again, then press the same action button. The TURBO function for that button will be turned off.
6. Vedligeholdelse
6.1 Rengøring
Brug en blød, tør klud til at rengøre din controller. Til genstridigt snavs, tør letampen the cloth with water and gently wipe the surface. Do not use harsh chemicals, solvents, or abrasive cleaners, as these can damage the controller's finish and internal components.
6.2 Opbevaring
Store the controller in a cool, dry place away from direct sunlight, extreme temperatures, and high humidity. Avoid placing heavy objects on the controller to prevent damage to the buttons or casing.
6.3 Pleje af batterier
The controller contains a built-in Lithium-ion battery. To prolong battery life, avoid fully discharging the battery frequently. If storing the controller for an extended period, charge it to approximately 50% capacity every few months.
7. Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Controller does not connect to Switch. |
|
|
| Input lag or unresponsive buttons. |
|
|
| Controller does not charge. |
|
|
8. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Steelplay |
| Modelnummer | 3760352735322 |
| Forbindelse | Bluetooth (trådløs) |
| Kompatible enheder | Nintendo Switch |
| Farve | Multicolore (Teal, Brown, Yellow) |
| Særlige funktioner | Wireless, Motion Control, TURBO Function |
| Vægt | 185 gram |
| Dimensioner (L x B x H) | 16 x 11.5 x 6.3 centimeter |
| Batteritype | 1 Lithium-ion (built-in) |
9. Garanti og support
The product packaging indicates a 5-year warranty. For specific warranty terms, conditions, and support inquiries, please refer to the official Steelplay webwebstedet eller kontakt deres kundeservice direkte. Gem din købsbevis til garantikrav.
Figur 2: Packaging of the Steelplay Adventure Controller. The box prominently features the controller's design, compatibility with various Nintendo Switch models, Bluetooth logo, and a "5 years warranty" seal. The reverse side provides product information in multiple languages.
