AGPTEK A30X MP3-afspiller brugermanual

1. Introduktion

Thank you for choosing the AGPTEK A30X MP3 Player. This device is designed to provide a versatile and enjoyable audio experience with its full touch screen, Bluetooth 5.3 connectivity, and various multimedia functions. This manual will guide you through the setup, operation, and maintenance of your new MP3 player.

2. Pakkens indhold

Tjek venligst pakken for følgende varer:

• 1 x AGPTEK A30X MP3 Player
• 1 x USB-C opladningskabel
• 1 x par høretelefoner
• 1 x Armband
• 1 x Brugermanual (dette dokument)

Image: Contents of the AGPTEK A30X MP3 Player package.

3. Produktet er slutview

The AGPTEK A30X features a compact design with a 2.4-inch full touch screen for intuitive navigation. It includes physical buttons for essential controls and a clip for portability during activities.

Billede: Forside view of the AGPTEK A30X MP3 Player with its clip.

3.1. Screen and Interface

The 2.4-inch TFT screen offers a clear display for menus, song information, videos, and images. The full touch interface allows for easy interaction with the device's functions.

Image: User interacting with the touch screen of the MP3 player.

3.2. Fysiske knapper

Independent buttons are located on the side of the unit for functions such as switching songs, adjusting volume, and power control. These physical buttons help prevent accidental operations, especially during sports activities.

3.3. Clip Design

The integrated clip allows for secure attachment to clothing or an armband, making it suitable for sports and active use. The device is lightweight, weighing approximately 61g.

Image: The lightweight design of the AGPTEK A30X MP3 Player.

4. Opsætning

4.1. Opladning af enheden

Before first use, fully charge the MP3 player. Use the provided USB-C charging cable to connect the device to a power source (e.g., computer USB port or a 5V-500mA charger).

• Opladningstid: Cirka 2.5 timer for en fuld opladning.
• Batterikapacitet: 500mAh polymer lithium batteri.

Image: Charging indicator and battery life details.

4.2. Tænd/sluk

• For at tænde: Tryk og hold tænd / sluk-knappen nede, indtil skærmen lyser.
• For at slukke: Press and hold the power button until the power-off option appears on the screen, then confirm.

4.3. Indledende opsætning

Upon first power-on, you may be prompted to select your preferred language, set the date, and time. Follow the on-screen instructions.

4.4. Hukommelse og lagring

The device comes with 32GB of built-in storage. It supports external TF (microSD) cards up to 128GB for expanded storage. Insert the TF card into the designated slot.

5. Betjeningsvejledning

The AGPTEK A30X offers various functions accessible through its touch screen interface.

Image: Multifunction user interface of the MP3 player.

5.1. Musikafspilning

Navigate to the 'Music' icon on the main menu. The player supports various audio formats including MP3, WMA, APE, FLAC, WAV, DRM, and ACELP. It features a professional smart digital noise reduction chip for high-quality, lossless audio playback. You can also select from 6 equalizer modes: Rock, Funk, Hip Hop, Jazz, Classic, and Electronic.

• Afspilningskontroller: Use the on-screen controls or physical buttons for play, pause, skip tracks, and volume adjustment.
• Lyrics Synchronization: The device supports displaying synchronized lyrics (LRC format).

5.2. Bluetooth-forbindelse (Bluetooth 5.3)

The A30X features Bluetooth 5.3 for stable and efficient wireless audio transmission. It is compatible with Bluetooth devices from version 2.1 to 5.3.

Image: Illustration of Bluetooth 5.3 technology and its advantages.

1. Gå til menuen 'Bluetooth' fra hovedskærmen.
2. Slå Bluetooth til.
3. The player will scan for available Bluetooth devices.
4. Vælg dine ønskede Bluetooth-hovedtelefoner eller -højttalere fra listen for at parre.

The device also includes a built-in speaker, allowing you to listen to music without headphones. Note that there is no specific on/off setting for the built-in speaker; it activates when headphones are not connected.

Image: People enjoying music, demonstrating the built-in speaker or Bluetooth functionality.

5.3. Videoafspilning

The A30X supports AVI video format. Transfer compatible video files to the device and select the 'Video' icon to browse and play them.

5.4. Foto Viewing

View images in JPG and BMP formats. Select the 'Image' icon to access your photo library.

5.5. E-Book Reader

Read TXT format e-books. Navigate to the 'E-Book' function to open your text files.

5.6. FM Radio

Access the 'FM Radio' function to listen to local radio stations. Ensure earphones are connected as they often act as the antenna.

5.7. Optagelse

The device supports WAV/MP3 recording formats with a recording distance of approximately 3 meters (9.8 feet). Select the 'Record' icon to start recording audio.

5.8. Yderligere funktioner

The AGPTEK A30X also includes:

• Skridttæller: Tracks your steps during physical activity.
• Vækkeur: Indstil alarmer for påmindelser.
• Stopur: For timing events.
• AB Gentag: Repeats a specific section of an audio track.
• Kalender: Viser den aktuelle dato.

6. Vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre enheden. Undgå flydende rengøringsmidler eller slibende materialer.
• Opbevaring: Opbevar afspilleren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
• Batteripleje: For at forlænge batteriets levetid, undgå at aflade batteriet helt ofte. Oplad det regelmæssigt, selvom det ikke er i brug i længere perioder.

7. Fejlfinding

• Enheden tænder ikke: Sørg for, at batteriet er opladet. Tilslut det til en oplader, og prøv igen.
• Ingen lyd: Check volume levels. Ensure headphones are properly connected or Bluetooth is paired correctly. If using the built-in speaker, ensure headphones are disconnected.
• Kan ikke oprette forbindelse via Bluetooth: Ensure Bluetooth is enabled on both the player and the target device. Keep devices within range (approx. 10m). Try unpairing and re-pairing.
• Filespiller ikke: Bekræft, at file format is supported by the player. Ensure files er ikke beskadiget.
• Skærmen reagerer ikke: Prøv at genstarte enheden. Hvis problemet fortsætter, skal du kontakte support.

8. Specifikationer

9. Garanti og support

AGPTEK offers a warranty for this product. If the product experiences any quality problems within one year of purchase, a refund or replacement will be provided unconditionally. For any questions or assistance regarding your AGPTEK A30X MP3 Player, please contact AGPTEK customer support through the platform where you purchased the product.
