THOMSON Sound Bar B206 Brugermanual

Indledning

Tak for købetasing the THOMSON Sound Bar B206. This sound bar is designed to enhance your audio experience for television, music, and gaming, featuring multiple connectivity options and two wireless microphones for karaoke. This manual provides essential information for safe and efficient use of your device. Please read it thoroughly before operation and retain it for future reference.

Sikkerhedsoplysninger

• Udsæt ikke enheden for regn, fugt eller ekstreme temperaturer.
• Ensure proper ventilation around the sound bar to prevent overheating.
• Åbn ikke c'enasing; overlad al service til kvalificeret personale.
• Brug kun den medfølgende strømadapter.
• Hold enheden væk fra stærke magnetiske felter.
• Avoid placing heavy objects on the sound bar.

Pakkens indhold

Bekræft, at alle nedenstående varer er inkluderet i din pakke:

• THOMSON Sound Bar (B206) x 1
• Fjernbetjening x 1
• Trådløs mikrofon x 2
• Strømadapter x 1
• Lydkabel x 1
• Coaxial Cable x 1
• Optical Fiber Cable x 1
• Wall Mounting Kit x 1 (includes padlocks, gel column, screws)
• Brugervejledning x 1

Figur 1: Medfølgende tilbehør

This image displays the complete set of items provided with your THOMSON Sound Bar B206, including the sound bar unit, remote control, two wireless microphones, power adapter, user manual, audio cable, coaxial cable, optical fiber cable, and wall mounting kit components.

Produkt overview

Sound Bar Components

The THOMSON Sound Bar B206 features a sleek design with integrated controls and various input ports for versatile connectivity.

Figure 2: Sound Bar, Microphones, and Remote

This image shows the main sound bar unit, two wireless microphones, and the remote control, providing a complete view of the primary components.

Internal Speaker Design

The sound bar is equipped with four large dual drive units, delivering a maximum output power of 200 Watts for HiFi sound quality, including dual bass and clear mid-range frequencies for a 3D surround sound effect.

Figure 3: Internal Speaker Structure

This diagram illustrates the internal construction of the sound bar's speakers, emphasizing the dual drive units responsible for audio output, alongside the Bluetooth connectivity symbol.

Rear Panel Connections and Remote Control

The rear panel provides various input options, while the remote control offers full command over the sound bar's functions.

Figure 4: Rear Panel Ports and Remote Control

This image details the connectivity options on the sound bar's rear panel, including the power switch, HDMI ARC, power input, subwoofer output, coaxial, optical, and AUX inputs. The accompanying remote control is also shown, indicating various function buttons.

Opsætning

1. Placeringsmuligheder

The THOMSON Sound Bar B206 can be placed on a desktop or mounted on a wall. A wall mounting kit is included for convenient installation.

• Desktopplacering: Place the sound bar on a stable, flat surface in front of your TV.
• Vægmontering: Use the provided wall mounting kit (padlocks, gel column, screws) to securely attach the sound bar to a wall below your TV. Ensure the wall material can support the weight of the sound bar.

Figure 5: Placement Options (Wall Mount and Desktop)

This image illustrates the versatility of the sound bar's placement, showing it both mounted on a wall beneath a television and resting on a media console, highlighting the included wall mount kit for an elegant setup.

2. Tilslutning til strøm

1. Connect the power adapter to the "24V/2A Power Supply" port on the sound bar's rear panel.
2. Sæt strømadapteren i en stikkontakt.

3. Lydforbindelser

Choose one of the following methods to connect the sound bar to your audio source (e.g., TV, smartphone, tablet, laptop):

• HDMI ARC:

  Connect an HDMI cable (not included) from the HDMI ARC port on your TV to the HDMI port on the sound bar. Ensure your TV's HDMI ARC function is enabled in its settings.

• Optisk:

  Connect the provided optical fiber cable from your TV's optical output to the "Optical" port on the sound bar. Select "Optical" as the input source on the sound bar.

• AUX (3.5 mm lydstik):

  Connect the provided audio cable from your device's headphone jack or audio output to the "AUX IN" port on the sound bar. Select "AUX" as the input source.
• Koaksial:

  Connect the provided coaxial cable from your TV's coaxial output to the "Coaxial" port on the sound bar. Select "Coaxial" as the input source.

• USB:

  Indsæt et USB-drev, der indeholder lyd files into the "USB" port. The sound bar will automatically switch to USB mode and begin playback.

• Bluetooth:

  Refer to the "Bluetooth Pairing" section under Operating Instructions for detailed steps.

Betjeningsvejledning

1. Tænd/sluk

Tryk på Sluk/tænd button on the sound bar's rear panel or the Magt knappen på fjernbetjeningen for at tænde eller slukke enheden.

2. Valg af inputkilde

Tryk på MODE button on the remote control to cycle through available input sources: HDMI ARC, Optical, AUX, Coaxial, USB, and Bluetooth. The LED display on the sound bar will indicate the currently selected mode.

3. Lydstyrkekontrol

Brug Volumen + og Volumen - buttons on the remote control or the physical controls on the right side of the sound bar to adjust the volume. The sound bar supports 8 levels of bass and treble adjustment.

4. EQ-tilstande

The sound bar offers 5 Equalizer (EQ) modes to optimize audio for different content types. Press the EQ button on the remote control to switch between modes:

• Filmtilstand: Forbedrer filmiske lydeffekter og dialog.
• Musiktilstand: Optimerer lyd til musikafspilning.
• Nyhedstilstand: Clarifies spoken dialogue for news and talk shows.
• Additional modes may be available for specific audio profiles.

Figure 6: EQ Modes

This image illustrates the three primary equalizer modes (News, Movie, Music) available on the sound bar, demonstrating how each mode is tailored for different audio experiences.

5. Bluetooth-parring

1. Turn on the sound bar and select Bluetooth mode using the MODE button on the remote. The LED display will show "BT" and flash, indicating pairing mode.
2. Aktiver Bluetooth på din enhed (smartphone, tablet osv.) og søg efter tilgængelige enheder.
3. Select "THOMSON B206" from the list. Once connected, the sound bar's LED display will stop flashing.

6. Trådløse mikrofoner

The sound bar comes with two wireless microphones for karaoke or vocal use.

1. Ensure the microphones have fresh batteries (AAA, not included).
2. Turn on the microphones. They should automatically pair with the sound bar.
3. Brug MIC+ og MIC- buttons on the remote to adjust microphone volume.
4. Brug ECHO+ og EKKO- buttons to adjust the echo effect.

Figure 7: Karaoke Functionality

This image depicts two individuals enjoying a karaoke session, utilizing the THOMSON sound bar and its wireless microphones connected to a large display, showcasing the product's entertainment capabilities.

Fejlfinding

Specifikationer

Opretholdelse

• Rensning: Brug en blød, tør klud til at rengøre overfladen på soundbaren. Brug ikke flydende rengøringsmidler eller slibende materialer.
• Opbevaring: Når soundbaren ikke er i brug i længere perioder, skal den opbevares køligt og tørt, væk fra direkte sollys og ekstreme temperaturer.
• Mikrofonpleje: Remove batteries from the wireless microphones if they will not be used for a long time to prevent leakage.

Garanti og support

THOMSON products are designed and manufactured to the highest quality standards. For warranty information and customer support, please refer to the warranty card included in your package or visit the official THOMSON webwebstedet. Behold din købskvittering som købsbevis.

Overholdelsesoplysninger

This device complies with relevant regulations for electronic equipment. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment.
