Keychron M3 Mini 4K trådløs optisk mus brugermanual

Indledning

This manual provides comprehensive instructions for the Keychron M3 Mini 4K Wireless Optical Mouse. It covers setup, operation, maintenance, and troubleshooting to ensure optimal performance and user experience. The M3 Mini 4K is an ultra-lightweight (55g) programmable mouse featuring a PixArt 3395 sensor, up to 26,000 DPI, 650 IPS, and a 4000 Hz polling rate for high-speed, precise input across Windows, Mac, and Linux systems.

Opsætningsvejledning

Pakkens indhold

Før du begynder, skal du sørge for, at alle varer er til stede i pakken:

• 1x Keychron M3 Mini 4K trådløs optisk mus
• 1x 4K trådløs modtager
• 1x Type-C til Type-C kabel
• 1x Type-A til Type-C adapter

Image: Standard Version package contents, showing the mouse, 4K wireless receiver, Type-C to Type-C cable, and Type-A to Type-C adapter.

Tilslutningsmuligheder

The Keychron M3 Mini 4K mouse supports three modes of connection: 2.4 GHz Wireless, Bluetooth 5.1, and Wired (via USB-C cable).

2.4 GHz trådløs tilstand

1. Locate the 4K Wireless Receiver.
2. Connect the receiver to your computer's USB port. If your computer only has USB-C ports, use the provided Type-A to Type-C adapter.
3. On the bottom of the mouse, slide the mode switch to the "2.4G" position.
4. Musen skal automatisk oprette forbindelse til modtageren.

Billede: Et nærbillede view of the 4K Wireless Receiver, which supports up to a 4K polling rate in 2.4 GHz mode.

Image: The Keychron M3 Mini 4K mouse shown alongside its dedicated 4K wireless receiver, illustrating the compact design.

Bluetooth 5.1-tilstand

1. On the bottom of the mouse, slide the mode switch to the "BT" position.
2. Åbn Bluetooth-indstillingerne på din computer, og søg efter nye enheder.
3. Select "Keychron M3 Mini 4K" from the list of available devices to pair.

Kablet tilstand

1. Connect the provided Type-C to Type-C cable (or Type-A to Type-C adapter with the cable) from the mouse to your computer's USB port.
2. Musen fungerer som en kablet mus og oplades samtidigt.

Betjeningsvejledning

DPI justering

The M3 Mini 4K features a PixArt 3395 sensor, offering up to 26,000 DPI for precise control. You can adjust the DPI directly on the mouse without software.

• Find DPI-knappen i bunden af ​​musen.
• Press the DPI button to cycle through preset DPI levels.
• The LED indicators on the bottom will show the current DPI setting.

Image: The underside of the mouse, highlighting the PixArt 3395 sensor and the physical buttons for DPI and Report Rate adjustments.

Afstemningshastighedsjustering

The mouse supports an ultra-fast 4K (4000 Hz) polling rate in 2.4 GHz mode, ensuring minimal latency.

• Locate the "Report Rate" button on the bottom of the mouse.
• Press the button to switch among 5 levels of polling rate: 125 Hz, 500 Hz, 1000 Hz, 2000 Hz, and 4000 Hz.
• The corresponding LED indicator will light up to show the selected polling rate.

Image: A diagram illustrating how to switch polling rates using the dedicated button on the mouse, with a table showing LED color indications for different frequencies (125 Hz to 4000 Hz).

Keychron Engine Software

For advanced customization, including key remapping, macros, RGB lighting effects (if applicable), and professional settings for LOD (Lift-Off Distance), polling rate, and DPI, download and install the Keychron Engine software.

• The software is compatible with Windows 11/10 and macOS.
• Besøg den officielle Keychron webwebsted for at downloade den seneste version.
• The software supports onboard memory, allowing your custom settings to be saved directly to the mouse.

Image: A visual representation of the Keychron Engine software interface, demonstrating options for personalization, key modification, shortcuts, macros, and professional settings.

Batterilevetid og opladning

The M3 Mini 4K is equipped with a 600 mAh battery, providing up to 135 hours of continuous working time in 1K Polling Rate mode. To charge the mouse, connect it to your computer using the provided USB-C cable.

Image: Icons illustrating key features: up to 135 hours of battery life (600 mAh), ultra-lightweight at 55g, and the ability to adjust settings without software.

Opretholdelse

Rengøring af musen

To maintain optimal performance and hygiene, regularly clean your Keychron M3 Mini 4K mouse.

• Brug en blød, fnugfri klud lidt damprengøres med vand eller en mild rengøringsopløsning til at tørre musens overflade af.
• Undgå at bruge skrappe kemikalier, slibende rengøringsmidler eller opløsningsmidler.
• Til den optiske sensor skal du bruge en vatpind, der er letampmed isopropylalkohol for forsigtigt at rengøre linsen. Sørg for, at der ikke kommer væske ind i sensoråbningen.
• Clean the scroll wheel and button crevices with a dry brush or compressed air to remove dust and debris.
• Ensure the mouse is powered off and disconnected from any power source before cleaning.

Batteripleje

To prolong the battery life of your mouse:

• Undgå at aflade batteriet helt ofte.
• Opbevar musen et køligt og tørt sted, når den ikke er i brug i længere perioder.
• Brug det medfølgende USB-C-kabel til opladning.

Fejlfinding

Forbindelsesproblemer

• 2.4 GHz trådløst:
  • Ensure the 4K Wireless Receiver is securely plugged into a working USB port.
  • Verify the mouse mode switch is set to "2.4G".
  • Prøv at tilslutte receiveren til en anden USB-port.
  • Sørg for, at der ikke er stærke forstyrrelser (f.eks. andre trådløse enheder) i nærheden.
• Bluetooth:
  • Ensure the mouse mode switch is set to "BT".
  • Make sure Bluetooth is enabled on your computer.
  • Remove the mouse from your computer's paired devices list and attempt to re-pair it.
  • Ensure the mouse battery has sufficient charge.
• wired:
  • Sørg for, at USB-C-kablet er korrekt tilsluttet til både musen og computeren.
  • Prøv at bruge en anden USB-port på din computer.
  • Test med et andet USB-C-kabel, hvis det er tilgængeligt.

DPI/Polling Rate Not Changing

• Ensure you are pressing the correct button (DPI or Report Rate) on the bottom of the mouse.
• Check the LED indicators on the bottom of the mouse to confirm changes.
• If using Keychron Engine software, ensure settings are applied and saved to onboard memory.

Musen reagerer ikke

• Check the battery level. Charge the mouse if the battery is low.
• Ensure the mouse is powered on (mode switch is not in "OFF" position).
• Genstart din computer.
• Try connecting the mouse to a different computer to rule out system-specific issues.

Specifikationer

Garanti og support

For detaljerede garantioplysninger og teknisk support henvises til den officielle Keychron-software. webwebstedet eller kontakt Keychrons kundeservice direkte. Gem din købsbevis til garantikrav.

Keychron Officiel Webwebsted: www.keychron.com
