NELKO P110 Portable Bluetooth Thermal Label Printer Instruction Manual

1. Introduktion

The NELKO P110 is a portable Bluetooth thermal label printer designed for various labeling needs in home, office, and small business environments. It connects wirelessly to your Android or iOS smartphone via Bluetooth 4.0, allowing you to create and print custom labels using the dedicated "Qlabel" application. This device utilizes thermal printing technology, eliminating the need for ink or toner cartridges.

2. Hvad er der i æsken

Upon unboxing your NELKO P110 Label Maker, please verify that all components are present:

• NELKO P110 Label Printer
• 1 Roll of Thermal Labels (40x30 mm)
• USB-opladerkabel (Type-C)
• Brugermanual / Quick Start Guide

Image: Contents of the NELKO P110 package, including the label maker and a roll of labels.

3. Opsætning

3.1. Indlæsning af etiketter

1. Slide to open the paper bin cover.
2. Take out the paper holder from inside the printer.
3. Load the label paper roll onto the paper holder, ensuring the printing side faces down.
4. Insert the label paper tab into the buckle of the paper holder.
5. Place the assembled paper holder back into the paper bin.
6. Gently rotate the paper roll to retract any excess paper, leaving approximately 2mm of paper outside the machine.
7. Luk låget til papirbeholderen forsvarligt.

Image: Visual instructions for loading the thermal label roll into the printer.

3.2. Tænd for enheden

Press and hold the power button located on the front of the device until the screen illuminates and displays "Welcome P110".

Image: The NELKO P110 Label Maker powered on, showing the welcome message.

4. App Installation & Bluetooth Connection

4.1. Downloading the "Qlabel" App

The "Qlabel" app is essential for operating your NELKO P110. You can download it using one of the following methods:

• Method 1: Scan QR Code: Use your smartphone's camera to scan the QR code provided in the Quick Start Guide or on the product packaging.
• Method 2: Search App Store: Open your device's app store (Google Play Store for Android or Apple App Store for iOS) and search for "Qlabel".

Image: A smartphone displaying the Qlabel app download page, next to the label maker.

4.2. Tilslutning via Bluetooth

1. Sørg for, at Bluetooth er aktiveret på din smartphone.
2. Open the "Qlabel" app.
3. Navigate to the "Me" section or a similar connection setting within the app.
4. Select "Connect machine" and choose "P110" from the list of available Bluetooth devices.
5. Once connected, a Bluetooth icon will appear on the P110's display.

5. Betjeningsvejledning

5.1. Oprettelse og redigering af etiketter

The "Qlabel" app offers a wide range of customization options:

• Skabeloner: Choose from various pre-designed templates for different categories (e.g., home, office, business, creative).
• Brugerdefineret design: Tap "New" to create a label from scratch.
• Tekst: Add text, customize fonts (20+ available), sizes, and alignment.
• Symboler og ikoner: Incorporate symbols (300+ emojis, 200+ materials) and icons to enhance your labels.
• Stregkoder og QR-koder: Generer og tilføj stregkoder eller QR-koder.
• Other Elements: Add tables, dates, figures, pictures, shapes, and lines.

Image: The Qlabel app interface showcasing multiple custom print templates and design elements.

5.2. Udskrivning af etiketter

1. After designing your label, click the "Preview" button to review det.
2. Click the "Print" button.
3. In the print setup screen, you can adjust the number of copies, print density, and horizontal/vertical offsets.
4. Confirm settings and click "Print" to send the label to the printer.

6. Brugsscenarier

The NELKO P110 Label Maker is versatile and suitable for a wide range of applications:

• Hjemmeorganisation: Label storage bins, pantry items, spice jars, and personal belongings.
• Kontorbrug: Organisere files, folders, cables, and office supplies.
• Små virksomheder: Create product labels, price tags, barcode labels, address labels, and shipping labels.
• Kreative projekter: Design custom labels for gifts, crafts, and special occasions.

Billede: Eksamples of NELKO P110 labels used for organizing items in office, kitchen, and personal care.

7. Vedligeholdelse

To ensure optimal performance and longevity of your NELKO P110 Label Maker, follow these maintenance guidelines:

• Rensning: Tør regelmæssigt printerens yderside af med en blød, tør klud. Undgå at bruge skrappe kemikalier eller slibende materialer.
• Pleje af printhoved: If print quality degrades, gently clean the thermal print head with a cotton swab lightly dampened with isopropyl alcohol. Ensure the printer is off and completely dry before use.
• Opbevaring: Opbevar printeren et køligt og tørt sted, væk fra direkte sollys og ekstreme temperaturer.
• Batteri: Oplad enheden regelmæssigt, selvom den ikke bruges hyppigt, for at opretholde batteriets sundhedstilstand.

8. Fejlfinding

If you encounter issues with your NELKO P110, try the following solutions:

• Printeren opretter ikke forbindelse: Ensure Bluetooth is enabled on your phone and the printer. Restart both devices and try connecting again through the "Qlabel" app.
• Dårlig udskriftskvalitet: Check if the label roll is inserted correctly with the printing side down. Clean the print head as described in the Maintenance section. Adjust the print density settings in the "Qlabel" app.
• Labels Not Feeding Correctly / Printing Offset: Ensure the label roll is properly seated in the paper holder and the paper holder is correctly installed in the bin. Calibrate the paper position if necessary (refer to app settings or quick start guide).
• Enheden tænder ikke: Ensure the battery is charged. Connect the printer to a power source using the provided USB cable.

For further assistance, please refer to the official support resources.

9. Specifikationer

10. Garanti og support

The NELKO P110 Label Maker comes with a limited warranty. For detailed warranty information and support, please visit the official NELKO support page or contact customer service.

Officiel supportside: https://www.nelkoprint.com/pages/support
