Brugermanual til Matbip trådløs controller

1. Produktet er slutview

The Matbip Wireless Controller is designed for an enhanced gaming experience, offering broad compatibility with PS4, PS4 Pro, PS4 Slim, PS3, and PC (Windows 7/8/10 systems). It features advanced wireless technology for stable connections, dual vibration motors, a 6-axis gyro sensor, and customizable macro programming.

Image: Matbip Wireless Controller, white and black design with textured grips.

Image: Diagram illustrating the controller's compatibility with PS4, PS4 Pro, PS4 Slim, and PC Windows systems.

2. Nøglefunktioner

• Dobbelt vibration: Built-in motors provide tactile feedback for an immersive gaming experience.
• 6-akset gyrosensor: Enables intuitive motion control in supported games.
• Turbofunktion: Allows for continuous firing in shooting games by setting a turbo button.
• Makro programmering: Customizable back buttons (M1/M2) can be programmed to map any desired button for personalized gameplay styles.
• Lang batterilevetid: Equipped with a 600mAh rechargeable battery, offering 8-10 hours of gaming time on a 1-2 hour charge.
• Clickable Touchpad: Supports multi-point simultaneous input, sliding touch, and flicking.
• 3.5 mm lydstik: Compatible with CTIA standard headsets for audio and communication (note: product does not have a built-in speaker function).
• LED lysbjælke: Provides visual feedback on connection status and charging.
• Type-C port: Modern USB-C charging port for convenience.

Image: Visual representation of Turbo function, Dual Vibration, and 6-Axis Motion Sensor features.

Image: Illustrates the dual motor vibration and 6-axis motion sensor capabilities, showing controller movement.

3. Controllerlayout

Familiarize yourself with the buttons and features of your Matbip Wireless Controller:

Billede: Forside og bagside view of the controller with labels for Share button, Touchpad, Option button, L1/L2 Triggers, D-Pad, Action buttons, Left stick, Right stick, LED light bar, Home button, Reset button, M1/M2 Programming keys, and Stereo headset jack.

• Del knap: Bruges til at dele spilindhold.
• Valgknap: Access in-game menus and options.
• Touchpad: Interactive surface for various game inputs.
• L1/L2 & R1/R2 udløsere: Shoulder buttons and analog triggers.
• D-Pad: Retningspude til præcis bevægelse.
• Handlingsknapper (Trekant, Cirkel, Kryds, Firkant): Standard PlayStation-handlingsknapper.
• Venstre/højre pinde: Analog joysticks for 360-degree control.
• Hjemknappen: Powers on the controller, accesses system menus.
• LED lysbjælke: Indicates player number, charging status, and other game-specific information.
• M1/M2 Programmeringsnøgler: Tilpassede bagknapper.
• Stereoheadset-stik: 3.5 mm port til tilslutning af hovedtelefoner.
• Nulstil knap: Small pinhole button on the back for resetting the controller.

4. Initial Setup & Connectivity

Connecting to PS4 Console (First Time)

1. Sørg for, at din PS4-konsol er tændt.
2. Connect the controller to the PS4 console using the provided Type-C USB charging cable.
3. Tryk på Hjem-knap on the controller. The LED light bar will flash and then stay lit, indicating a successful connection.
4. Once connected, you can unplug the USB-C cable to use the controller wirelessly.

Image: Step-by-step visual guide showing how to connect the controller to a PS4 console using a USB cable and pressing the Home button.

Connecting to PC (Windows 7/8/10)

To connect the controller wirelessly to a PC:

1. On the controller, simultaneously press and hold the Hjem-knap og den DEL-knap for approximately 5 seconds. The LED light bar will begin to flash rapidly.
2. On your PC, go to Bluetooth settings and add a new Bluetooth device.
3. Select the Matbip controller from the list of available devices to pair.

Note: Up to 4 Matbip controllers can be used simultaneously on each console. If you need to connect a new controller and have reached the limit, you may need to remove an existing device from your console's connected devices list.

Image: Depicts the controller's Bluetooth function, highlighting its wireless capability with a range of up to 10 meters (33 feet).

5. Opladning af controlleren

Controlleren er udstyret med et genopladeligt batteri med høj kapacitet på 600 mAh.

• Opladningstid: Cirka 1-2 timer for fuld opladning.
• Arbejdstid: Provides up to 8-10 hours of uninterrupted gaming.
• Opladningsport: Type-C.

LED Light Bar Status during Charging:

• Under opladning: LED light is orange.
• Når opladningen er afsluttet: LED-lyset er slukket.
• In standby: LED-lys blinker.
• When not connected: LED light is white.

Image: Displays the controller's battery life metrics: 8-10 hours working time, 10m/33ft standby time, and 1-2 hours charging time.

Image: Highlights the controller's built-in 600mAh rechargeable battery, showing charging and working times.

6. Advanced Functions: Turbo and Macro Programming

Turbofunktion

The Turbo function allows for continuous rapid input of a button press, useful in games requiring fast repetitive actions.

• How to Set TURBO: Press the desired function button (e.g., Triangle, Circle, Cross, Square, R1, R2, L1, L2) + the DEL-knap samtidigt.
• How to Cancel TURBO: Press the button with the continuous fire setting + the DEL-knap samtidigt.
• Adjusting Turbo Rate: Hold nede DEL-knap and move the right stick up or down to switch between 6 times/second, 12 times/second, and 18 times/second.

Makro programmering

The M1 and M2 back buttons can be programmed to execute complex sequences or map any standard button, providing a competitive edge.

• The extra multi-function buttons on the back of this controller can be programmed for custom gameplay styles.
• You can map any button you want to set to M1 or M2.

Image: Illustrates the Macro Programming Features with M1 and M2 buttons on the back, showing customization options for up to 16 buttons.

7. Troubleshooting & Reset

Nulstilling af controlleren

If the product is not working properly due to a malfunction, you can perform a reset:

• Locate the small reset hole on the back of the controller (refer to the Controller Layout image).
• Use a thin, pointed object (like a paperclip) to press the reset button inside the hole.
• After resetting, re-pair the controller with your device following the initial setup instructions.

Fælles problemer

• Parringsproblemer: Ensure no other buttons or joysticks on the controller are pressed during the initial pairing process. This can prevent proper connection.
• Afbrydelse: If the controller frequently disconnects, ensure it is fully charged and within the 33ft (10m) Bluetooth range. Interference from other wireless devices can also affect connection stability.
• Inputforsinkelse/manglende respons: Check battery level. If wired, ensure the USB cable is securely connected. For wireless, try re-pairing the controller.

8. Produktspecifikationer

9. Officiel produktvideo

10. Garanti og kundesupport

Matbip specializes in providing customized controllers for game lovers. If you encounter any problems or have questions regarding your Matbip Wireless Controller, please do not hesitate to contact us. We are committed to providing prompt assistance and will reply to your inquiries within 24 hours.

For support, please refer to the contact information provided with your product packaging or visit the official Matbip store on Amazon.
