1. Introduktion
The Fenix HM61R v2.0 is a versatile, high-performance rechargeable headlamp designed for various applications, including outdoor recreation, industrial use, and general tasks. It features dual white and red LEDs, a magnetic charging system, and a detachable L-shape design for use as a right-angle flashlight. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Fenix HM61R v2.0 headlamp.
Figure 1: Fenix HM61R v2.0 Headlamp with headband attached.
2. Pakkens indhold
Kontroller venligst, at alle varer er til stede i din pakke:
- Fenix HM61R v2.0 headlamp (with battery pre-installed)
- Pandebånd
- Magnetisk ladekabel
- Ekstra O-ring
- Brugervejledning (dette dokument)
- Garantikort
Figure 2: Contents included in the Fenix HM61R v2.0 package.
3. Specifikationer
The Fenix HM61R v2.0 headlamp offers the following performance and physical specifications:
| Feature | Hvidt Lys | Rødt Lys | ||||||
|---|---|---|---|---|---|---|---|---|
| Øko | Lav | Med | Høj | Turbo | Lav | Med | Blitz | |
| Udgangslumen | 5 | 50 | 150 | 600 | 1600 | 1 | 5 | 5 |
| Runtime | 300 timer | 35 timer | 12 timer | 3h | 2 timer* | 400 timer | 80 timer | 160 timer |
| Afstand | 30 fod (9 m) | 92 fod (28 m) | 154 fod (47 m) | 318 fod (97 m) | 531 fod (162 m) | – | – | – |
| Intensitet | 20 cd | 190 cd | 557 cd | 2358 cd | 6566 cd | – | – | – |
| Slagmodstand: 2 m | ||||||||
| Waterproof/Dustproof: IP68, dustproof/waterproof underwater to 2m | ||||||||
| Størrelse | Length: 3.98" (101mm) Width: 1.77" (45mm) Height: 1.42" (36mm) | |||||||
| Vægt | 5.36 oz. (152g) including battery and headband | |||||||
| Inkluderet | Fenix ARB-L18-3400 battery, magnetic charging cable, spare O-ring | |||||||
*Turbo-outputtet måles i total driftstid inklusive output ved reducerede niveauer på grund af temperatur eller beskyttelsesmekanisme i designet.
4. Opsætning
4.1. Første opladning
The Fenix HM61R v2.0 comes with a pre-installed Fenix ARB-L18-3400 rechargeable battery. Before first use, it is recommended to fully charge the device.
- Locate the magnetic charging port on the headlamp.
- Connect the magnetic end of the included USB charging cable to the charging port. The cable will snap into place magnetically.
- Connect the USB-A end of the cable to any standard USB power source (e.g., wall adapter, power bank, computer USB port).
- The charging status indicator (located behind the side button) will display red during charging and turn steady green when fully charged.
Figure 3: Magnetic charging of the Fenix HM61R v2.0 headlamp.
You can also charge the headlamp while it is still attached to the headband. Simply rotate the flashlight within its bracket to expose the magnetic charging pad.
4.2. Attaching/Detaching from Headband
The HM61R v2.0 features a quick-release structure, allowing it to be easily removed from the headband for use as a standalone right-angle flashlight or for magnetic mounting.
- To detach: Gently slide the flashlight out of the high-strength PC holder on the headband.
- To attach: Align the flashlight with the holder and slide it back in until it clicks securely into place.
Figure 4: Quick-release structure for detaching the flashlight from the headband.
Video 1: Comprehensive video manual demonstrating setup, features, and operation of the Fenix HM61R v2.0.
5. Betjeningsvejledning
5.1. Power On/Off and Mode Selection (White Light)
- At tænde: Press and hold the side button for 0.5 seconds. The light will turn on in the last used white light mode.
- At slukke: Tryk og hold sideknappen nede i 0.5 sekunder.
- Tilstandscykling: With the white light on, single-click the side button to cycle through Eco → Low → Mid → High → Turbo. The light will memorize the last selected white light mode.
Video 2: Demonstrates the Fenix HM61R v2.0 headlamp's features, including power on/off, mode cycling, and detachability.
5.2. Rødt lys-betjening
- To Activate Red Light: Med hovedetamp off, double-click the side button. The light will turn on in Red Low mode.
- Tilstandscykling: With the red light on, single-click the side button to cycle through Red Low → Red Med → Red Flash.
- At slukke: Tryk og hold sideknappen nede i 0.5 sekunder.
Figure 5: Red light mode for night vision preservation and signaling.
5.3. Electronic Lock/Unlock
To prevent accidental activation during storage or transport, the headlamp features an electronic lock function.
- At låse: Med hovedetamp off, press and hold the side button for 3 seconds. The red LED will flash four times, indicating it is locked.
- Sådan låses op: Med hovedetamp locked, press and hold the side button for 3 seconds. The red LED will flash four times and then turn on in Red Low mode, indicating it is unlocked.
- Lockout-indikation: When locked, any single click of the side button will cause the red LED to flash once to indicate the locked status.
5.4. Detachable Flashlight and Magnetic Base
The HM61R v2.0 can be detached from its headband to function as a compact, right-angle flashlight. Its magnetic tail allows for hands-free attachment to ferromagnetic metal surfaces.
- Afmontering: Refer to Section 4.2 for instructions on detaching the flashlight.
- Magnetisk montering: The magnetic base on the tail of the flashlight allows it to be securely attached to metal surfaces, providing hands-free illumination in various work environments.
Figure 6: Detached flashlight with magnetic base for hands-free use.
Figur 7: Eksamples of hands-free fixation using the magnetic tail and body clip.
6. Vedligeholdelse
- Rensning: Regularly clean the threads and O-rings with a clean cloth. Lubricate the O-rings with silicone grease to maintain waterproof sealing.
- Batteripleje: Opbevar hovedlamp with the battery partially charged (around 50%) if not used for extended periods. Recharge the battery every four months to maintain optimal performance.
- O-ring Replacement: If the O-ring is damaged, replace it with the spare O-ring provided in the package to ensure the IP68 waterproof rating.
- Generel pleje: Avoid disassembling the sealed head of the light as this may damage the light and void the warranty.
7. Fejlfinding
- Lyset tænder ikke:
- Check if the electronic lock is activated (red LED flashes once when button is pressed). Unlock the headlamp som beskrevet i afsnit 5.3.
- Ensure the battery is properly inserted and fully charged.
- Rengør batteriets kontakter og hovedetamp's internal contacts with a cotton swab dipped in rubbing alcohol.
- Opladningsproblemer:
- Ensure the magnetic charging cable is securely connected to both the headlamp og USB-strømkilden.
- Verify the USB power source is functional.
- Check the charging indicator light for proper status (red for charging, green for fully charged).
- Reduced Brightness or Short Runtime:
- Batteriet skal muligvis oplades fuldt.
- The battery may be aging and require replacement.
- Sørg for headlamp is not operating in an extremely hot environment, which can trigger temperature protection and reduce output.
8. Garanti og support
Fenix products are built with high-quality materials and craftsmanship. For detailed warranty information and support, please refer to the included warranty card or visit the official Fenix website. Keep your purchase receipt for warranty service.
For technical assistance or customer service, please contact Fenix support directly through their official channels.
