Indledning
The ANRAN 3/4G LTE Cellular Security Camera G01 is a wireless outdoor surveillance solution designed for locations without Wi-Fi or electrical power access. It operates on 4G LTE cellular networks and is powered by a high-capacity rechargeable battery and a solar panel, ensuring continuous operation. This camera features 2K HD resolution, 360° pan-tilt-zoom (PTZ) capabilities, advanced PIR human detection, two-way audio, and versatile night vision modes.
This manual provides detailed instructions for setting up, operating, and maintaining your ANRAN G01 camera to ensure optimal performance and longevity.
Figure 1: ANRAN 3/4G LTE Cellular Security Camera G01 with included accessories.
Hvad er der i æsken
Please check the package contents carefully upon unpacking:
- 1X ANRAN G1 PTZ Camera
- 1X Solar Panel
- 1X 100MB SIM Card (Pre-installed)
- 1X 32GB SD Card (Pre-installed)
- 1X Type-C ladekabel
Opsætning
1. Første opladning
Before first use, ensure the camera's internal battery is fully charged. Connect the camera to the solar panel and place the solar panel in direct sunlight for several hours, or use the provided Type-C charging cable to charge via a standard USB power adapter (not included).
Figure 2: The camera is designed for 365 days of non-stop power with its solar panel and 9600mAh battery.
2. Installation af SIM-kort og SD-kort
The camera comes with a pre-installed 100MB SIM card and a 32GB SD card. If you need to replace them or verify installation:
- Locate the card slot on the camera body.
- Åbn forsigtigt beskyttelsesdækslet.
- Insert the 4G LTE SIM card (if not already installed) into the SIM slot with the gold contacts facing down and the notched corner aligned correctly.
- Insert the Micro SD card (if not already installed) into the SD card slot until it clicks into place.
- Close the protective cover firmly to ensure weather resistance.
Figure 3: Location of the SIM and SD card slots. Both are pre-installed.
3. Download af app og oprettelse af konto
Download the official ANRAN app from the App Store (for iOS) or Google Play Store (for Android). Follow the in-app instructions to create a new account and log in.
Figure 4: Download the ANRAN App for remote access and local storage management.
4. Camera Pairing/Activation
Once logged into the app, follow the on-screen prompts to add your new device. Power on the camera. The app will guide you through the pairing process, which typically involves scanning a QR code on the camera or entering its device ID.
5. Montering af kameraet
The ANRAN G01 camera offers flexible installation options:
- Vægbeslag: Use the provided screws and anchors to securely attach the camera bracket to a wall.
- Strap Installation: Utilize mounting straps (not included) to attach the camera to poles or trees.
- Loftmontering: The camera can also be mounted upside down on a ceiling or overhang.
Ensure the solar panel is positioned to receive maximum direct sunlight throughout the day for optimal charging. The camera has an IP65 weather-resistant rating, suitable for outdoor use.
Figure 5: Various installation methods for the ANRAN G01 camera.
Drift
1. Lev View og PTZ-styring
Open the ANRAN app and select your camera to access the live view. Use the on-screen controls to pan (355° horizontally) and tilt (90° vertically) the camera, providing a 360° field of view. The camera also supports 4X digital zoom.
Figure 6: Control the camera's 360° field of view direkte fra din smartphone.
2. Tovejslyd
The camera features a built-in microphone and speaker. In the live view, tap the microphone icon to speak through the camera, and listen to audio from the camera's surroundings.
Figure 7: Engage in two-way communication using the ANRAN app.
3. Bevægelsesdetektion og advarsler
The ANRAN G01 uses a smart PIR (Passive Infrared) motion detection sensor to accurately identify human and animal movement, minimizing false alarms. When motion is detected, the camera can:
- Send real-time alerts and notifications to your phone.
- Trigger a siren warning.
- Activate spotlights for visual deterrence.
Figure 8: Motion detection features including siren and spotlight warnings.
Customizing Motion Detection:
- Følsomhedsjustering: Adjust the detection sensitivity (levels 1-10) in the app settings to suit your environment and reduce frequent interference.
- Custom Alarm Area: Define specific detection zones to focus on critical areas and avoid unnecessary alerts.
- Custom Alert Schedule: Set specific time periods for alerts to be active, improving battery life and reducing interruptions.
Figure 9: Adjust motion detection sensitivity to your needs.
Figure 10: Set custom alert schedules to optimize battery life and reduce unwanted notifications.
4. Nattesynstilstande
The camera offers three night vision modes for clear visibility in low-light conditions:
- Infrarød tilstand: Provides clear black and white images in complete darkness using infrared LEDs.
- Farvetilstand: Utilizes built-in spotlights to provide full-color night vision, capturing more details.
- Alarmtilstand: Automatically switches to color night vision and activates spotlights upon motion detection.
Figure 11: Compare Color Night Vision and Infrared Night Vision capabilities.
Figure 12: Choose from three distinct night vision modes based on your surveillance needs.
5. Optagelse og afspilning
Kameraet optager footage to the pre-installed 32GB SD card. You can access recorded videos and playback directly through the ANRAN app. Cloud storage options may also be available through the app (subscription may be required).
6. Flerbruger View and Device Sharing
You can share access to your camera's live feed and recordings with multiple users through the ANRAN app. This allows family members or trusted individuals to monitor the property simultaneously.
Figure 13: Share camera access with multiple users for collaborative monitoring.
7. Data Plan Information
The camera includes a prepaid 4G LTE SIM card with 100MB of free trial data. After the trial data is consumed, you can renew your data plan through ANRAN. Various data plans are available, starting from $15.99 per month for unlimited data. If you wish to use your own SIM card, please contact ANRAN support to verify compatibility and for potential firmware updates.
Opretholdelse
1. Battery Care and Solar Charging
The camera's 9600mAh battery is designed for long-term operation with the solar panel. To ensure continuous power:
- Periodically check the solar panel for dirt, dust, or obstructions that might reduce charging efficiency.
- Ensure the solar panel is positioned to receive maximum direct sunlight, especially during winter months or in areas with less sunlight.
- If the camera's battery level drops significantly, you can temporarily charge it using the Type-C cable.
Figure 14: The camera's battery and solar power system provide extended operation.
2. Cleaning the Camera and Solar Panel
For at opretholde en klar billedkvalitet og effektiv solopladning:
- Wipe the camera lens and solar panel surface with a soft, damp klud. Undgå slibende rengøringsmidler eller stærke kemikalier.
- Regularly check for spiderwebs or insect nests around the camera, as these can obstruct the view or trigger false alarms.
3. Firmwareopdateringer
ANRAN may release firmware updates to improve camera performance, add new features, or fix bugs. Check the ANRAN app periodically for available updates and follow the in-app instructions to install them. Ensure the camera has sufficient battery power before starting a firmware update.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Camera not connecting to network / Activation issues | No 4G LTE signal; SIM card not properly inserted or activated; Incorrect APN settings; Firmware outdated. | Check 4G LTE signal strength at installation location. Ensure SIM card is correctly inserted and activated with a valid data plan. Contact ANRAN support if using your own SIM card for APN settings and compatibility check. Try restarting the camera. |
| Poor image quality / Distorted zoom | Dirty lens; Low light conditions; Digital zoom limitations. | Clean the camera lens. Ensure adequate lighting for optimal image quality. Digital zoom can cause pixelation; use optical zoom (if available) or physical repositioning for clearer close-ups. |
| Hyppige falske alarmer | High motion detection sensitivity; Unwanted detection zones; Environmental factors (e.g., swaying branches, passing vehicles). | Adjust PIR motion detection sensitivity in the app. Define custom alarm areas to exclude irrelevant zones. Ensure camera is not pointed at areas with constant, non-threatening movement. |
| Batteriet oplades ikke / aflades hurtigt | Insufficient sunlight on solar panel; Solar panel obstructed or dirty; Excessive camera activity; Extreme temperatures. | Relocate solar panel to receive more direct sunlight. Clean the solar panel. Reduce unnecessary live view access or excessive motion recordings. Ensure operating within specified temperature range (-10°C to 50°C). |
| No audio / Poor two-way audio | Microphone/speaker obstructed; App volume settings; Network latency. | Ensure microphone and speaker are clear of obstructions. Check volume settings on your phone and in the app. A stable 4G LTE connection is crucial for clear audio. |
If you encounter issues not listed here or require further assistance, please contact ANRAN customer support.
Specifikationer
| Feature | Specifikation |
|---|---|
| Modelnummer | G01 (US-4G-黑) |
| Forbindelse | 4G LTE Cellular (T-Mobile, AT&T compatible) |
| Strømkilde | Soldrevet, 9600mAh genopladeligt batteri |
| Video opløsning | 2K (3MP CMOS Sensor) |
| Felt af View | 360 Degrees (355° Pan, 90° Tilt) |
| Zoom | 4X digital zoom |
| Nattesyn | IR Night Vision, 2K Color Night Vision (with spotlights) |
| Bevægelsesdetektion | PIR Human Detection, Customizable Sensitivity & Areas |
| Lyd | Tovejssamtale (indbygget mikrofon og højttaler) |
| Opbevaring | 32GB Micro SD Card (Pre-installed), Cloud Storage (Optional) |
| Vejrbestandighed | IP65-klassificeret |
| Driftstemperatur | Typically -10°C to 50°C (14°F to 122°F) |
| Dimensioner (L x B x H) | 7.48 x 7.87 x 2.76 tommer |
| Vægt | 2.61 pund |
Garanti og support
ANRAN products typically come with a limited warranty. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official ANRAN webwebstedet. Behold din købskvittering som købsbevis.
Kundesupport:
For technical assistance, troubleshooting, or any product-related inquiries, please contact ANRAN customer support through the following channels:
- Officiel Webwebsted: Visit the ANRAN official webwebsted med ofte stillede spørgsmål, supportressourcer og kontaktoplysninger.
- Support i appen: The ANRAN app may offer a direct support or feedback option.
- E-mail support: Refer to your product packaging or the ANRAN webwebsted for kundesupportens e-mailadresse.
When contacting support, please have your product model number (G01 or US-4G-黑) and purchase details ready.
