Indledning
Thank you for choosing the Bulova Chandler Lighted Mantel Clock, Model B1853. This elegant timepiece combines traditional design with modern features, including an illuminated dial and a harmonic triple chime movement. Crafted with high-quality materials, this clock is designed to be a lasting addition to your home decor. This manual will guide you through the setup, operation, and maintenance of your new clock.
Komponenter overview
Your Bulova Chandler Mantel Clock consists of the following main components:
- Solid Hardwood Case: Tambour shaped with a warm brown walnut finish and "Curly" Burl front veneer.
- Urskive: Cream finish with Arabic numerals, featuring an exclusive automatic backlight.
- Bezel: Raised polished brass finish with a protective convex glass crystal.
- Bevægelse: Quartz movement for accurate timekeeping.
- Dørklokkeenhed: Bulova Harmonic Triple Chime movement with selectable melodies and adjustable volume.
- Batterirum: Located at the back for the clock movement, chime unit, and dial light.
Opsætning
Installation af batteri
The clock requires the following batteries (not included):
- 1 AA battery for the clock movement.
- 2 C batteries for the chime unit.
- 4 AA batteries for the dial light.
- Carefully open the battery compartments located on the back of the clock.
- Isæt de nødvendige batterier, og sørg for at polariteten (+/-) vender korrekt.
- Luk batterirummene forsvarligt.
Indstilling af tid
- Locate the time-setting knob on the back of the clock movement.
- Turn the knob clockwise to advance the hands to the correct time.
- Allow the clock to chime through each hour as you set the time to synchronize the chime with the hour.
Betjeningsvejledning
Klokkeindstillinger
Your clock features a Bulova Harmonic Triple Chime movement, offering a choice of melodies:
- Westminster Chime: Plays a melody every quarter-hour, with a full melody and hour count on the hour.
- Ave Maria Chime: Plays a melody every quarter-hour, with a full melody and hour count on the hour.
- Strike Only: Strikes the hour without a melody.
Refer to the controls on the back of the clock to select your preferred chime and adjust the volume. The clock also includes a night shut-off option for uninterrupted sleep.
Illuminated Dial
The exclusive automatic backlit dial illuminates for easy reading in low light conditions. It offers 2 selectable light settings (100% and 50% brightness) and automatically shuts off in the morning. You can also select light timer options, such as on while dark or auto on and shut off after 6 hours.
Opretholdelse
Rensning
- Tør trækassen af med en blød, tør klud. Undgå at bruge slibende rengøringsmidler eller polermidler, der kan beskadige overfladen.
- Clean the glass crystal with a soft, lint-free cloth and a mild glass cleaner. Spray cleaner onto the cloth, not directly onto the clock.
Udskiftning af batteri
Replace batteries as needed. It is recommended to replace all batteries at the same time to ensure consistent performance. Dispose of old batteries responsibly.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Uret kører ikke | Dead or incorrectly installed AA battery for movement. | Check and replace the AA battery for the clock movement. Ensure correct polarity. |
| Dørklokken virker ikke | Dead or incorrectly installed C batteries for chime. Chime switch set to OFF or Night Shut-off. | Check and replace the C batteries for the chime. Ensure correct polarity. Verify chime switch is set to an active mode (Westminster, Ave Maria, or Strike Only) and not in Night Shut-off during active hours. |
| Dial-lyset virker ikke | Dead or incorrectly installed AA batteries for light. Light timer settings. | Check and replace the 4 AA batteries for the dial light. Ensure correct polarity. Adjust light timer settings as desired. |
| Chime is out of sync with time | Time was set without allowing chimes to complete. | Reset the time by advancing the minute hand past 12 o'clock, allowing the chime to strike the hour. Repeat until the chime matches the displayed time. |
Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Bulova |
| Modelnummer | B1853 |
| Farve | Warm Brown Walnut |
| Display Type | Analog |
| Stil | Traditionel |
| Speciel funktion | Adjustable Volume, Illuminated Dial |
| Produktdimensioner | 17 cm B x 10 cm H |
| Strømkilde | Batteridrevet |
| Materiale | Træ |
| Bevægelsestype | Kvarts |
| Batterier påkrævet | 1 AA, 2 C, 4 AA (not included) |
Garanti og support
Your Bulova Chandler Lighted Mantel Clock comes with a 1 års begrænset producentgaranti. For warranty claims, technical support, or any questions not covered in this manual, please contact Bulova customer service directly. Refer to the product packaging or the official Bulova webhjemmeside for de seneste kontaktoplysninger.
Du kan også besøge Bulova Store on Amazon for yderligere produktinformation og supportressourcer.
