Indledning
This manual provides comprehensive instructions for the iFLYTEK Translator 2.0 easytrans 800. It covers device setup, operation, maintenance, and troubleshooting to ensure optimal performance and user experience. The iFLYTEK Translator 2.0 is designed for seamless communication across language barriers, offering advanced voice and camera translation capabilities.
Pakkens indhold
Bekræft at alle varer er til stede i pakken:
- iFLYTEK Translator 2.0 easytrans 800 Device
- USB opladningskabel
- Hurtig guide
- Instruktionsmanual (dette dokument)
- Lanyard/Strap
Image: The iFLYTEK Translator 2.0 easytrans 800 device, its charging cable, and documentation laid out next to the product box.
Produkt overview
The iFLYTEK Translator 2.0 easytrans 800 features a compact design with a user-friendly interface.
Billede: Forside view of the iFLYTEK Translator 2.0 easytrans 800 showing the screen, navigation buttons, and speaker. Rear view shows the camera lens and SOS button.
Enhedskomponenter:
- Frontpanel: Touchscreen display, navigation buttons (ABC, O, 中文), speaker.
- Bagside: Camera lens, SOS button.
- Sideknapper: Power button, volume controls.
- Porte: USB charging port, 3.5mm headphone jack.
Opsætning
1. Opladning af enheden
Before first use, fully charge the translator. Connect the provided USB cable to the device's charging port and a compatible USB power adapter (not included).
- En fuld opladning tager typisk cirka 2-3 timer.
- Batteriindikatoren på skærmen viser opladningsstatus.
2. Tænd/sluk
- For at tænde: Press and hold the Power button (usually on the side) until the screen illuminates.
- For at slukke: Tryk og hold tænd/sluk-knappen nede, og vælg derefter "Sluk" på skærmen.
3. Initial Language Selection
Upon first power-on, you will be prompted to select the device's interface language. Follow the on-screen instructions.
4. Netværksforbindelse
The iFLYTEK Translator requires an internet connection for optimal translation accuracy. Connect to a Wi-Fi network or utilize the built-in global communication feature.
- Wi-Fi: Navigate to Settings > Wi-Fi, select your network, and enter the password.
- Global Communication: The device includes 2 years of global communication coverage in 98 countries. This feature activates automatically when a Wi-Fi connection is not available.
Betjeningsvejledning
The iFLYTEK Translator 2.0 easytrans 800 offers two primary translation modes: Voice Translation and Camera Translation.
1. Voice Translation (59 Languages)
This mode allows for real-time spoken language translation.
- Select the source and target languages on the device screen.
- Press and hold the designated voice input button (e.g., "ABC" for language A, "中文" for language B).
- Speak clearly into the device's microphone.
- Release the button. The device will process your speech and provide the translation audibly and on-screen.
The device features advanced noise reduction technology and four microphones for high accuracy even in noisy environments, with a response time of approximately 0.5 seconds.
Image: The iFLYTEK Translator 2.0 device screen showing a Japanese phrase and its translation, demonstrating voice translation functionality.
Image: A collection of national flags, symbolizing the extensive language support of the iFLYTEK Translator 2.0 across 171 countries.
Image: A collage showing the iFLYTEK Translator 2.0 being used in different scenarios, including a business meeting and a travel setting, highlighting its versatility.
2. Camera Translation (11 Languages)
This mode translates text captured by the device's camera.
- Select Camera Translation mode from the main menu.
- Point the device's camera at the text you wish to translate (e.g., signs, menus, documents).
- Ensure the text is well-lit and within the camera's frame.
- Tap the capture button on the screen. The device will process the image and display the translated text.
Image: A user holding the iFLYTEK Translator 2.0 to translate text on a map, demonstrating the camera translation feature.
3. Pronunciation Scoring and Accent Check
The device includes an AI-powered feature to help users improve their pronunciation and check accents.
- Access the Pronunciation Scoring feature from the menu.
- Select the language for practice.
- Speak the displayed phrases or words into the microphone.
- The device will provide feedback on your pronunciation and accent.
Image: An adult and a child interacting with the iFLYTEK Translator 2.0, illustrating its use for pronunciation scoring and language learning.
Opretholdelse
- Rensning: Brug en blød, tør klud til at rengøre enheden. Brug ikke flydende rengøringsmidler eller aerosoler.
- Opbevaring: Opbevar enheden et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
- Batteripleje: For at forlænge batteriets levetid bør du undgå at aflade batteriet helt ofte. Oplad enheden regelmæssigt, selvom den ikke er i brug i længere perioder.
- Softwareopdateringer: Søg regelmæssigt efter og installer softwareopdateringer for at sikre optimal ydeevne og adgang til nye funktioner.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Enheden tænder ikke. | Lavt batteri; enheden er frosset. | Charge the device for at least 30 minutes. Perform a force restart by holding the power button for 10-15 seconds. |
| Oversættelsen er unøjagtig eller langsom. | Poor internet connection; unclear speech; incorrect language selection. | Ensure a stable Wi-Fi or cellular connection. Speak clearly and directly into the microphone. Verify that the correct source and target languages are selected. |
| Camera translation not working. | Insufficient lighting; blurry image; text too small. | Ensure adequate lighting. Hold the device steady to avoid blur. Position the device closer to the text if it's too small. |
| Ingen lyd fra højttaleren. | Volume too low; speaker obstructed. | Increase the volume using the side buttons. Check if the speaker is blocked by debris. |
Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | iFLYTEK |
| Modelnummer | EASYTRANS 800 |
| Voice Translation Support | 59 Sprog |
| Camera Translation Support | 11 Sprog |
| Støjreduktionsteknologi | Yes, with 4 microphones |
| Global kommunikation | 2 years coverage in 98 countries |
| Svartid | Cirka 0.5 sekunder |
| Kompatible enheder | Laptop, Personal Computer (for data transfer/updates) |
| Hardware-interface | 802.11 b/g/n (Wi-Fi) |
| Lydformat | WAV |
| Hovedtelefonstik | 3.5 millimeter |
| Batteritype | 1 lithium-ion batteri (medfølger) |
| Varens vægt | 120 gram |
| Skærmstørrelse | 5.8 tommer |
| Batterilevetid | Op til 6 timer |
| Digital optagelsestid | 120 minutter |
Garanti og support
For garantioplysninger og teknisk support henvises til den officielle iFLYTEK webwebstedet eller kontakt deres kundeservice. Gem din købskvittering som købsbevis i tilfælde af garantikrav.
The device includes 2 years of global communication, which is a service feature rather than a warranty.
