Indledning
This manual provides essential instructions for the safe and efficient operation, maintenance, and troubleshooting of your Shop-Vac 2.5 Gallon 2.0 Peak HP Wet/Dry Vacuum and Cordless Handheld Vacuum. Please read this manual thoroughly before using the product and retain it for future reference.
Figur 1: Shop-Vac 2.5 Gallon Wet/Dry Vacuum and Cordless Handheld Vacuum with included accessories.
Produktegenskaber
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Bærbart design: Features a top handle for easy lifting and transport.
- Vægmonteret: Designed for convenient wall storage, saving floor space.
- Kraftig ydeevne: Equipped with a 2.0 Peak HP motor, suitable for home, garage, workshop, and vehicle cleaning tasks.
- 3-i-1 funktionalitet: Offers strong wet suction, dry suction, and a powerful blowing function (55 CFM air blower).
- Udvidet rækkevidde: Includes a 21-foot hose and a 20-foot power cord, providing a total cleaning reach of 41 feet.
- Fjernbetjeningshåndtag: Allows convenient power control (on/off) directly from the hose handle.
- Inkluderet tilbehør: Comes with 14 attachments for various cleaning applications.
Shop-Vac Cordless Handheld Vacuum
- Two-Mode Suction: Features a 100W brushless motor with 7000Pa (Standard) and 13000Pa (Strong) suction modes.
- Kompakt og let: Measures 10"x2.5"x2.2" and weighs only 1.0 pound, ideal for portability.
- Stille drift: Operates at less than 80dB noise level.
- Langvarig kraft: Equipped with a 2,000mAh lithium-ion battery, offering up to 25 minutes on low suction and 13 minutes on high suction.
- Hurtig opladning: Recharges in 3-4 hours via USB.
- Dobbelt filtreringssystem: Includes a stainless steel filter and a HEPA filter, capturing particles down to 0.3 microns.
- Nem tømning: Features a one-release button for the 100ml dust tank.
Figur 2: The Wet/Dry Vacuum demonstrating its versatility in wet, dry, and blowing applications.
Komponenter og dele
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Bærehåndtag: For bærbarhed.
- TÆND/SLUK -kontakt: Styrer strøm til enheden.
- Blæserport: Outlet for blowing function.
- Latches: Secure the motor head to the collection tank.
- Vakuumport: Inlet for suction hose.
- Opsamlingstank: Holds collected debris and liquids.
- Slange: Flexible hose for connecting attachments.
- Strømledning: Til elektrisk tilslutning.
- Wall-Mount Rack: Til praktisk opbevaring.
- Tilbehør: Various nozzles, brushes, and extension wands.
Figur 3: Key components of the Wet/Dry Vacuum.
Shop-Vac Cordless Handheld Vacuum
- Power knap: To turn the unit on/off and switch suction modes.
- Støvbeholder: Transparent tank for collecting debris.
- One-Release Button: For detaching the dust tank.
- Rustfrit stålfilter: Primary filtration layer.
- HEPA-filter: Secondary filtration for fine particles.
- USB opladningsport: Til genopladning af batteriet.
- Indikatorlys: Show battery status and charging.
- Nozzles/Brushes: Included attachments for specific cleaning tasks.
Figur 4: The Cordless Handheld Vacuum and its accessories.
Opsætningsinstruktioner
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Udpakning: Carefully remove all components from the packaging. Ensure all listed parts and accessories are present.
- Filter Installation (Dry Use): For dry vacuuming, ensure the cartridge filter is properly installed over the filter cage and secured with the filter retainer. For wet vacuuming, remove the cartridge filter and install the foam sleeve over the filter cage.
- Slangeforbindelse: Sæt den store ende af slangen ind i vakuumporten på forsiden af tanken, indtil den klikker sikkert på plads.
- Attachment Connection: Attach the desired cleaning accessory (e.g., utility nozzle, crevice tool) to the end of the hose or extension wands.
- Strømtilslutning: Sæt netledningen i en passende jordet stikkontakt.
- Vægmontering (valgfrit): If wall-mounting, follow the instructions provided with the wall-mount rack to securely attach it to a sturdy wall stud. Ensure the unit, hose, and accessories are properly stored on the rack.
Shop-Vac Cordless Handheld Vacuum
- Indledende opkrævning: Before first use, fully charge the handheld vacuum. Connect the USB charging cable to the vacuum's charging port and a USB power source. The indicator lights will show charging status. A full charge takes approximately 3-4 hours.
- Filtersamling: Ensure the stainless steel filter and HEPA filter are correctly seated inside the dust tank.
- Vedhæftet fil: Select and attach the appropriate nozzle or brush for your cleaning task.
Figur 5: USB charging of the Cordless Handheld Vacuum.
Betjeningsvejledning
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Tørstøvsugning:
- Ensure the cartridge filter is installed.
- Turn the ON/OFF switch to the "ON" position (or use the remote control handle).
- Før dysen hen over det tørre affald, der skal opsamles.
- Når du er færdig, skal du dreje kontakten til "OFF" og tage stikket ud af enheden.
- Vådsugning:
- Remove the cartridge filter and install the foam sleeve.
- Drej tænd/sluk-knappen til "TIL"-positionen.
- Guide the nozzle over the liquid spill. The float mechanism will shut off suction when the tank is full.
- When finished, turn the switch to "OFF", unplug, and empty the tank immediately.
- Blæsefunktion:
- Frakobl slangen fra vakuumporten.
- Insert the hose into the blower port located on the motor head.
- Drej tænd/sluk-knappen til "TIL"-positionen.
- Use the air stream to clear debris from surfaces.
- Når du er færdig, skal du dreje kontakten til "OFF" og tage stikket ud af enheden.
- Fjernbetjeningshåndtag: Press the "ON" button on the handle to start the vacuum, and the "OFF" button to stop it. This feature allows control from a distance, especially useful with the long hose.
Shop-Vac Cordless Handheld Vacuum
- Tænd/sluk: Press the power button once to turn on the vacuum in Standard mode (7000Pa). Press again to switch to Strong mode (13000Pa). Press a third time to turn off the vacuum.
- Rensning: Guide the nozzle over the area to be cleaned. The compact size is ideal for tight spaces like car interiors or furniture.
- Batteriindikator: Monitor the indicator lights for battery level. Recharge when the lights indicate low battery.
Figur 6: Handheld Vacuum demonstrating its suction power.
Figur 7: Handheld Vacuum in use for car cleaning.
Opretholdelse
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Tømning af tanken: After each use, especially wet vacuuming, unlatch the motor head and empty the collection tank. Clean the inside of the tank with water and mild detergent if necessary.
- Filter Cleaning (Dry Use):
- Fjern patronfilteret.
- Gently tap the filter to dislodge dust. For heavy dirt, rinse under running water.
- Lad filteret lufttørre helt, før det monteres igen.
- Filter Cleaning (Wet Use):
- Remove the foam sleeve.
- Rinse the foam sleeve under running water.
- Allow it to air dry completely before reinstallation.
- Slange og tilbehør: Clean the hose and accessories as needed with water and mild detergent. Ensure they are dry before storage.
Shop-Vac Cordless Handheld Vacuum
- Tømning af støvbeholderen: Press the one-release button to detach the dust tank. Empty collected debris.
- Filterrensning:
- Remove both the stainless steel filter and the HEPA filter from the dust tank.
- Brush off any loose debris. Both filters can be rinsed under running water.
- Ensure filters are completely dry before reassembling to prevent damage and maintain suction power.
- Batteripleje: For optimal battery life, avoid completely draining the battery frequently. Store the unit in a cool, dry place.
Figur 8: Easy dust tank release for the Handheld Vacuum.
Figur 9: Double filtration system of the Handheld Vacuum.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Wet/Dry Vac: Tænder ikke | Ingen strøm, defekt afbryder, udløst afbryder. | Check power cord connection. Ensure outlet is functional. Reset circuit breaker. |
| Wet/Dry Vac: Lavt sug | Clogged hose/filter, full tank, improper filter installation. | Clear any blockages in hose/attachments. Clean or replace filter. Empty tank. Ensure filter is correctly installed. |
| Wet/Dry Vac: Vand kommer fra udstødningen | Tank is full, foam filter not installed for wet use. | Empty tank. Ensure foam filter is correctly installed for wet vacuuming. |
| Handheld Vac: Tænder ikke | Battery drained, unit not charged. | Charge the handheld vacuum fully. |
| Handheld Vac: Lavt sug | Clogged filters, full dust tank, low battery. | Clean stainless steel and HEPA filters. Empty dust tank. Recharge battery. |
| Handheld Vac: Kort køretid | Battery not fully charged, operating in Strong mode. | Ensure battery is fully charged. Standard mode offers longer runtime. |
Specifikationer
Shop-Vac 2.5 Gallon Wet/Dry Vacuum
- Kapacitet: 2.5 gallons
- Motor: 2.0 Peak HP
- Funktioner: Wet, Dry, Blower
- Slange længde: 21 fod
- Strømkabellængde: 20 fod
- Særlige funktioner: Wall-mountable, Remote Control Handle
Shop-Vac Cordless Handheld Vacuum
- Motor: 100W børsteløs
- Sugekraft: 7000Pa (Standard), 13000Pa (Strong)
- Batteri: 2,000 mAh Lithium-Ion
- Kørselstid: Up to 25 minutes (Standard), 13 minutes (Strong)
- Opladningstid: 3-4 timer (USB)
- Støjniveau: < 80dB
- Støvtankkapacitet: 100ml (approx. 3.4oz)
- Filtrering: Stainless Steel Filter, HEPA Filter
- Dimensioner: 10 cm x 2.5 cm x 2.2 cm
- Vægt: 1.0 pund
Garanti og support
For warranty information, technical support, or to purchase replacement parts and accessories, please refer to the official Shop-Vac webwebstedet eller kontakt deres kundeserviceafdeling. Gem din købskvittering som købsbevis i tilfælde af garantikrav.
Note: Specific warranty terms may vary by region and product. Always consult the official product documentation or manufacturer's webwebsted for den mest nøjagtige og opdaterede information.
