1. Introduktion
Thank you for choosing the KONIX 88 Keys Roll Up Piano, Model PD88. This portable electronic keyboard is designed for musicians of all levels, offering a full 88-key range in a compact, flexible format. Its features include a built-in loudspeaker, 128 tones, 128 rhythms, and MIDI output for versatile musical expression and learning. This manual provides essential information for setup, operation, maintenance, and troubleshooting to ensure optimal performance and longevity of your instrument.
2. Pakkens indhold
Please verify that all items listed below are included in your package. If any items are missing or damaged, please contact KONIX customer support.
- KONIX 88 Keys Roll Up Piano (PD88)
- Sustain pedal
- Strømadapter
- Type-C USB-kabel
- Tastaturtaske
- Brugervejledning (dette dokument)
Image: The KONIX PD88 Roll Up Piano and its accessories, including the sustain pedal, USB cable, power adapter, and user manual.
3. Produktet er slutview
3.1 Nøglefunktioner
- 88 Standard Keys: Full-size keyboard for comprehensive musical practice.
- Bærbart design: Made from durable silicone, allowing it to be rolled up for easy storage and transport.
- Rich Sound Options: Features 128 international standard tones and 128 rhythms.
- Demonstrationssange: Includes 14 built-in demo songs for learning and enjoyment.
- MIDI udgang: USB MIDI output for connection to computers and music editing software (e.g., Cakewalk, Sonar, Cubase, Nuendo, VST/VSTi).
- Integreret højttaler: Built-in loudspeaker for direct audio output.
- Genopladeligt batteri: Provides 9-10 hours of continuous use on a single charge.
- Kontrolpanelets funktioner: LED digital display, recording, playback, sustain, vibrato, teaching mode, and chord functions.
Image: The KONIX PD88 in use, illustrating its key features.
3.2 Kontrolpanel og porte
The control panel provides access to all functions and connectivity options. Familiarize yourself with the layout:
- LED digitalt display: Shows current settings (tone, rhythm, volume, etc.).
- Power knap: Tænder/slukker enheden.
- Lydstyrkekontrol: Justerer udgangslydstyrken.
- Tone/Rhythm Selection Buttons: Cycles through available tones and rhythms.
- Demoknap: Plays demonstration songs.
- Record/Play Buttons: For recording and playing back your performances.
- Sustain/Vibrato Buttons: Activates sustain and vibrato effects.
- Teaching/Chord Functions: Engages learning modes.
- USB/MIDI OUT Port: Connects to a computer for MIDI functionality and charging.
- Aux-indgangsport: Til tilslutning af eksterne lydkilder.
- Hovedtelefonstik (3.5 mm): For private practice.
- Mikrofonindgang: Til tilslutning af ekstern mikrofon.
- Sustain pedal input: Til tilslutning af den medfølgende sustainpedal.
Billede: Detaljeret view of the multi-functional jacks on the control panel.
Image: The LED digital display for settings indication.
4. Opsætning
4.1 Indledende opladning
- Before first use, fully charge the roll-up piano.
- Connect the Type-C USB cable to the USB/MIDI OUT port on the piano and the other end to the power adapter.
- Sæt strømadapteren i en almindelig stikkontakt.
- The charging indicator (if available, refer to LED display for battery status) will show charging progress. A full charge typically takes several hours.
4.2 Unrolling and Placement
- Carefully unroll the silicone keyboard on a flat, stable surface. Ensure the keys lie flat without creases or bumps.
- Place the control panel section on a stable part of the surface.
4.3 Tilslutning af tilbehør
- Sustain pedal: Insert the sustain pedal cable into the dedicated Sustain Pedal input on the control panel.
- Hovedtelefoner: For private practice, plug 3.5mm headphones into the Headphone Jack.
- Ekstern mikrofon: Connect a microphone to the Microphone Input if desired.
- MIDI-forbindelse: To use the piano as a MIDI controller, connect the USB/MIDI OUT port to your computer using the Type-C USB cable.
5. Betjeningsvejledning
5.1 Tænd/sluk
Press and hold the Power button on the control panel to turn the piano on or off.
5.2 Justering af lydstyrke
Use the Volume Up (+) and Volume Down (-) buttons on the control panel to adjust the master volume.
5.3 Valg af toner og rytmer
- Tryk på Tone button to enter tone selection mode. Use the number buttons or +/- buttons to select from 128 available tones. The LED display will show the current tone number.
- Tryk på Rytme button to enter rhythm selection mode. Use the number buttons or +/- buttons to select from 128 available rhythms. The LED display will show the current rhythm number.
5.4 Playing Demonstration Songs
Tryk på Demo button to cycle through the 14 built-in demonstration songs. Press it again to stop playback.
5.5 Optagelse og afspilning
- Tryk på REC button to start recording your performance. The REC indicator will light up.
- Play your desired piece.
- Tryk på REC knappen igen for at stoppe optagelsen.
- Tryk på SPIL button to listen to your recorded performance.
5.6 Sustain and Vibrato Functions
- Tryk på Oprethold button to activate the sustain effect. Press again to deactivate.
- Tryk på Vibrato button to activate the vibrato effect. Press again to deactivate.
5.7 Teaching and Chord Functions
Refer to the specific instructions on the control panel or the quick start guide for detailed usage of the teaching and chord functions, as these can vary in implementation.
Image: Close-up of a key being pressed.
6. Vedligeholdelse
- Rensning: Use a soft, dry cloth to wipe the surface of the piano. For stubborn dirt, a slightly damp cloth can be used, but ensure no moisture enters the control panel or ports. Do not use abrasive cleaners or solvents.
- Opbevaring: When not in use, roll up the piano gently and store it in the provided keyboard bag. Avoid folding it sharply or placing heavy objects on top. Store in a cool, dry place away from direct sunlight and extreme temperatures.
- Batteripleje: To prolong battery life, avoid fully discharging the battery frequently. If storing for an extended period, charge the piano to about 50% capacity every few months.
- Håndtering: The silicone keyboard is durable but should be handled with care. Avoid sharp objects that could puncture or tear the material.
Image: The roll-up piano being stored in a backpack.
7. Fejlfinding
If you encounter any issues with your KONIX PD88 Roll Up Piano, please refer to the following common problems and solutions:
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Ingen lyd eller lav lydstyrke. | Piano is off; volume is too low; headphones are connected; battery is low. | Ensure piano is powered on. Increase volume using +/- buttons. Disconnect headphones if using internal speaker. Charge the battery. |
| Keys sound twice or multiple times. | Incorrect key press technique; piano not on a flat surface; sensor sensitivity issue. | Ensure keys are pressed firmly and released cleanly. Place the piano on a completely flat and stable surface. If the issue persists, contact customer support. |
| Keys are sticking or unresponsive. | Debris under keys; physical damage; piano not on a flat surface. | Gently clean around the keys. Ensure the piano is on a flat surface. Avoid placing heavy objects on the keys. |
| Microphone input is too soft. | Microphone volume setting; microphone compatibility. | Check if there's a separate microphone volume control on the piano (if available). Ensure the microphone is fully plugged in. Consider using an external amplifier if higher volume is needed. |
| MIDI connection not working. | Forkert kabel; driverproblemer; softwareindstillinger. | Ensure you are using the correct Type-C USB cable. Check your computer's device manager for driver installation. Verify MIDI input settings in your music software. |
8. Specifikationer
| Feature | Detalje |
|---|---|
| Modelnavn | PD88 |
| Antal nøgler | 88 |
| Toner | 128 International Standard Tones |
| rytmer | 128 International Standard Rhythms |
| Demo sange | 14 |
| Forbindelse | USB (Type-C), MIDI OUT, Aux-in, 3.5mm Headphone Jack, Microphone Input, Sustain Pedal Input |
| Strømkilde | Built-in Rechargeable Battery, USB Power |
| Batterilevetid | Ca. 9-10 timers kontinuerlig brug |
| Materiale | Silicone (Keyboard), Rubber (Body) |
| Varens vægt | 1.43 kilo (3.14 pund) |
| Dimensions (Unrolled) | Approx. 53.7 inches (Length) x 6.4 inches (Width of keys) / 9 inches (Width of control panel) |
| Supported Software (MIDI) | Cakewalk, Sonar, Cubase, Nuendo, VST/VSTi |
| Operating System (MIDI) | Windows XP/Vista/7/8, Mac OSX |
Image: Product dimensions for both unrolled and rolled configurations.
9. Garanti og support
KONIX products are manufactured to high-quality standards. For specific warranty information, please refer to the warranty card included with your product or visit the official KONIX website. If you require technical assistance or have questions not covered in this manual, please contact KONIX customer support through the retailer where you purchased the product or via the contact information provided on the official KONIX webwebsted.
Gem venligst dit købsbevis for garantikrav.
