BYINTEK P19 Mini 3D DLP-projektor brugermanual

1. Introduktion

Thank you for choosing the BYINTEK P19 Mini 3D DLP Projector. This portable device offers a high-quality viewing experience with its advanced DLP technology, Android 9.0 operating system, and built-in battery. This manual provides essential information for setting up, operating, and maintaining your projector to ensure optimal performance and longevity.

The BYINTEK P19 Mini Projector in an operational setting, demonstrating its ability to project clear images for entertainment.

2. Sikkerhedsoplysninger

• Læs alle instruktioner, før du bruger projektoren.
• Bloker ikke ventilationsåbningerne. Sørg for tilstrækkelig luftgennemstrømning omkring projektoren.
• Brug kun den strømadapter, der følger med enheden.
• Avoid direct exposure to the projector lens light, as it can be harmful to the eyes.
• Hold projektoren væk fra vand, fugt og ekstreme temperaturer.
• Forsøg ikke selv at skille projektoren ad eller reparere den. Kontakt kundesupport for at få hjælp.

3. Pakkens indhold

Kontroller venligst pakkens indhold ved udpakning for at sikre, at alle varer er til stede:

• 1 x BYINTEK P19 Projector
• 1 x IR fjernbetjening
• 1 x strømadapter (DC 12V/2A)
• 1 x USB Charging Cable (supports ≥ DC 5V 3A input)
• 1 x brugermanual
• 1 x Opbevaringspose

The standard package includes the P19 projector, a storage bag, user manual, remote control, USB charging cable, and a DC 12V/2A power adapter.

4. Produktet er slutview

4.1 Projektorkomponenter

The BYINTEK P19 Mini Projector, a compact device capable of projecting large images, shown here displaying a high-definition movie.

4.2 Porte og forbindelser

The projector's connectivity options, including USB 3.0, HD-in, DC-in, and Audio-out, supporting connections to devices like PS4, U Disk, GamePad, Mouse, HD DVD/Network HD player, Smartphone/tablet/laptop, Desktop Computer, and external Speakers.

• Fokus: Manual focus adjustment wheel.
• Tastatur: Control buttons on the top panel.
• IR-modtager: Til fjernbetjeningssignaler.
• USB 3.0: Til tilslutning af USB-drev eller andet perifert udstyr.
• DC-in (12V 2A): Strømindgangsport.
• HD-in: HDMI input for external video sources.
• Lydudgang: 3.5mm jack for external speakers or headphones.

5. Nøglefunktioner

• Mini DLP Projector: Advanced DLP technology for clear and vibrant images.
• Indbygget batteri: 7800 mAh rechargeable lithium battery providing 1.5 to 2.5 hours of operation.
• Android 9.0 OS: Integrated smart operating system with pre-installed media apps and Play Store access.
• Trådløs skærm: Supports screen mirroring for smartphones, tablets, and PCs.
• Hi-Fi stereohøjttaler: Dual 3W speakers for integrated audio.
• 6D Keystone-korrektion: Auto/Manual vertical and corner keystone adjustments.
• 3D support: DLP-Link 3D compatibility for immersive viewing.
• Forbindelse: 2.4G/5G dual-band Wi-Fi, USB, and HDMI inputs.
• Opløsning: Native 1280x720, supports up to 4K input.

A summary of the P19's technical features, including RGB 3LED, 7800mAh battery, Android 9.0 OS, 6D Keystone, 2.4G/5G Wi-Fi, 4K Max support, HDR, and MEMC.

6. Opsætning

6.1 Tænd/sluk

1. Connect the power adapter to the DC-in port of the projector and then to a power outlet.
2. Tryk og hold tænd/sluk-knappen på projektoren eller fjernbetjeningen nede for at tænde den.
3. To turn off, press and hold the power button again until the projector shuts down.

6.2 Placering

The BYINTEK P19 is designed for flexible placement, supporting both tabletop and tripod mount configurations. Ensure the projector is placed on a stable surface or securely mounted.

The projector's portability and long battery life make it ideal for outdoor entertainment, as shown by friends watching a movie under the stars.

6.3 Fokusjustering

Rotate the focus adjustment wheel located on the side of the projector until the projected image appears sharp and clear on the screen.

6.4 Keystone-korrektion

The P19 features 6D Keystone correction to adjust image distortion. This includes:

• Auto/Manual Vertical Keystone: Corrects vertical distortion when the projector is tilted up or down.
• Manuel hjørne-keystone: Allows adjustment of each corner of the image independently to achieve a perfect rectangular shape.

Access these settings through the projector's menu system.

The 6D Keystone correction system allows for both manual corner and auto/manual vertical adjustments to achieve a perfectly rectangular image from various projection angles.

Visual representation of the projector's keystone correction, showing how it can rectify distorted images caused by angled projection.

7. Betjeningsvejledning

7.1 Android 9.0 OS Navigation

The BYINTEK P19 runs on Android 9.0 OS, providing a smart TV-like experience. Use the remote control to navigate the interface:

• Retningsknapper: Flyt markør eller valg.
• OK knap: Bekræft valg.
• Tilbage knap: Vend tilbage til den forrige skærm.
• Hjemknappen: Go to the main home screen.

Pre-installed apps include YouTube, Netflix, Prime Video, and Hulu. You can download more applications from the Play Store.

The projector's Android 9.0 OS comes pre-loaded with popular apps and allows access to the Play Store for additional downloads, enhancing its smart capabilities.

7.2 Wireless Display (Screen Mirroring)

The projector supports wireless display functionality, allowing you to mirror content from your smartphone, tablet, or PC. Refer to the projector's on-screen instructions or the EShare app for detailed setup.

7.3 Tilslutning af eksterne enheder

Use the available ports to connect various devices:

• HDMI (HD-in): Connect devices like PCs, PS4, Fire TV Stick, or Blu-ray DVD players.
• USB 3.0: Plug in USB drives for media playback, or connect a mouse/gamepad.
• Lydudgang: Tilslut eksterne højttalere eller hovedtelefoner for forbedret lyd.

7.4 Lydudgang

The P19 is equipped with powerful dual 3W Hi-Fi stereo speakers for a complete audio-visual experience. For private listening or higher fidelity, connect external audio devices via the Audio-out port.

The projector features dual 3W Hi-Fi stereo speakers, providing integrated audio for an enhanced viewoplevelse.

7.5 3D-funktionalitet

The projector supports DLP-Link 3D, allowing you to watch 3D content from compatible sources (e.g., Blu-ray 3D) using active shutter 3D glasses. Ensure your 3D content is in SBS (Side-by-Side) or TNB (Top-and-Bottom) format.

An illustration of the projector's DLP-Link 3D capability, allowing users to experience immersive 3D content from sources like Blu-ray 3D.

8. Vedligeholdelse

• Rengøring af linsen: Brug en blød, fnugfri klud, der er specielt designet til optiske linser. Brug ikke slibende rengøringsmidler eller klude.
• Rengøring af Casing: Tør projektorens yderside af med en blød, tør klud. Ved genstridige mærker kan du bruge en let tør klud.amp en klud kan bruges, efterfulgt af en tør klud.
• Opbevaring: When not in use for extended periods, store the projector in a cool, dry place, preferably in its original packaging or a protective bag, away from dust and direct sunlight.
• Ventilation: Kontrollér regelmæssigt, at ventilationsåbningerne er fri for støv og snavs for at forhindre overophedning.

9. Fejlfinding

• No Image / Dim Image:
  • Sørg for, at projektoren er tændt og tilsluttet korrekt.
  • Adjust the focus wheel for clarity.
  • Kontroller valget af inputkilde.
  • Ensure the room is sufficiently dark for optimal brightness.
• Forvrænget billede:
  • Use the keystone correction settings (vertical and corner) to adjust the image shape.
  • Sørg for, at projektoren er placeret så vinkelret på skærmen som muligt.
• Ingen internetforbindelse:
  • Bekræft, at dit Wi-Fi-netværk er aktivt og fungerer.
  • Check Wi-Fi settings on the projector to ensure it's connected to the correct network.
  • Genstart projektoren og din Wi-Fi-router.
• 3D Playback Issues:
  • Ensure your 3D content is in a compatible format (SBS or TNB).
  • Verify your 3D glasses are charged and properly synced with the projector.
  • Check the 3D settings in the projector's menu.
• Fjernbetjeningen virker ikke:
  • Udskift batterierne i fjernbetjeningen.
  • Sørg for, at der ikke er nogen forhindringer mellem fjernbetjeningen og projektorens IR-modtager.

10. Specifikationer

11. Garanti og support

The BYINTEK P19 Mini 3D DLP Projector comes with a 1 års garanti fra købsdatoen, dækker fabrikationsfejl.

For teknisk support, garantikrav eller eventuelle forespørgsler, kontakt venligst:

• Fabrikant: BYINTEK
• Telefonnummer: +91 8885241706
• E-mail: care@justshop24x7.com

Please have your purchase receipt and product model number (P19) ready when contacting support.
