SEVERIN MW 7775 3-in-1 Microwave Oven Instruction Manual

1. Introduktion

This manual provides essential information for the safe and efficient operation of your SEVERIN MW 7775 3-in-1 Microwave Oven. This appliance combines microwave, grill, and hot air functions, offering versatile cooking options. Please read these instructions thoroughly before first use and retain them for future reference.

2. Sikkerhedsinstruktioner

Always observe basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, personal injury, or exposure to excessive microwave energy.

• Forsøg ikke at betjene denne ovn med døren åben, da dette kan resultere i skadelig eksponering for mikrobølgeenergi.
• Placer ikke genstande mellem ovnens forside og døren, og lad ikke snavs eller rengøringsrester samle sig på tætningsflader.
• Brug ikke ovnen, hvis den er beskadiget. Det er særligt vigtigt, at ovndøren lukker ordentligt, og at der ikke er skader på: (1) lågen (bøjet), (2) hængsler og låse (brudt eller løsnet), (3) dørtætninger og tætningsflader.
• Ovnen bør ikke justeres eller repareres af andre end kvalificeret servicepersonale.
• Sørg for tilstrækkelig ventilation omkring apparatet. Bloker ikke ventilationsåbningerne.
• Do not heat liquids or other foods in sealed containers, as they are liable to explode.
• Only use utensils suitable for microwave ovens. Metal containers are not suitable for microwave cooking.
• Hold øje med børn, når du bruger apparatet.

3. Produktet er slutview

The SEVERIN MW 7775 features a sleek design with a digital display and intuitive controls. It includes a spacious cooking chamber, a glass turntable, and a grill rack for various cooking needs.

Nøglekomponenter omfatter:

• Kontrolpanel: Digital display, function buttons, and rotary knob for settings.
• Dør: Equipped with a safety lock mechanism.
• Køkkenkammer: Interior space for food preparation.
• Glaspladespiller: Sikrer jævn tilberedning ved at rotere maden.
• Grillstativ: Used for grilling and hot air functions.

4. Opsætning

4.1 Udpakning

Carefully remove all packaging materials from the oven and its accessories. Check for any damage during transit. Do not discard packaging until you are satisfied with the product.

4.2 Placering

Place the oven on a flat, stable, heat-resistant surface. Ensure there is sufficient space for ventilation: at least 20 cm above, 10 cm at the rear, and 5 cm on each side. Do not place the oven near heat sources or in direct sunlight.

4.3 Montering af pladespiller

Before use, assemble the turntable components inside the cooking chamber:

1. Place the rotating ring on the bottom of the oven cavity.
2. Position the glass turntable plate securely on top of the rotating ring. Ensure it sits correctly in the center.

4.4 Strømtilslutning

Plug the power cord into a grounded electrical outlet. The oven is now ready for initial setup and use.

5. Betjeningsvejledning

5.1 Indstilling af uret

Upon first connection, the display will show '0:00'. To set the clock:

1. Tryk på knappen 'Ur'.
2. Use the rotary knob to set the hour. Press 'Clock' again.
3. Use the rotary knob to set the minutes. Press 'Clock' again to confirm.

5.2 Mikrobølgeovnsfunktion

Sådan tilberedes med mikrobølgeovn:

1. Placer maden i en mikrobølgeovnssikker beholder på glasdrejetallerkenen.
2. Press the 'Microwave' button repeatedly to select the desired power level (e.g., P100 for 100% power).
3. Brug drejeknappen til at indstille tilberedningstiden.
4. Tryk på 'Start' for at begynde tilberedningen.

5.3 Grillfunktion

Grillfunktionen er ideel til at brune og sprøde mad.

1. Placer maden på grillristen, som skal placeres på glasdrejetallerkenen.
2. Tryk på 'Grill'-knappen.
3. Brug drejeknappen til at indstille grilltiden.
4. Tryk på 'Start' for at begynde at grille.

5.4 Hot Air Function (Convection)

The hot air function allows for baking and roasting, similar to a conventional oven.

1. Placer maden på grillristen.
2. Press the 'Hot Air' button.
3. Use the rotary knob to select the desired temperature (e.g., 140°C).
4. Press 'Hot Air' again to confirm temperature.
5. Brug drejeknappen til at indstille tilberedningstiden.
6. Press 'Start' to begin. The oven will preheat first if necessary.

5.5 Combination Modes

The oven offers various combination modes (e.g., Microwave + Grill, Microwave + Hot Air, Grill + Hot Air) for optimized cooking results. Refer to the specific combination program codes in the full manual for detailed instructions.

5.6 automatiske programmer

The MW 7775 includes 10 pre-set automatic cooking programs, including a pizza function. These programs simplify cooking for common dishes.

1. Press the 'Auto Menu' button.
2. Use the rotary knob to select the desired program number (e.g., A-1 for pizza).
3. Press 'Start' to begin. The oven will automatically adjust power and time.

5.7 Afrimningsfunktion

The defrost function allows thawing food by weight or time.

• Afrimning efter vægt: Press 'Defrost by Weight', use the rotary knob to enter the food weight, then press 'Start'.
• Afrimning efter tid: Press 'Defrost by Time', use the rotary knob to set the defrosting duration, then press 'Start'.

5.8 Børnelås

For at aktivere børnesikringen skal du trykke på knappen 'Stop/Annuller' og holde den nede i 3 sekunder. Displayet viser et låseikon. Gentag processen for at deaktivere den.

6. Vedligeholdelse og rengøring

Regular cleaning helps maintain the performance and longevity of your oven.

• Ydre: Tør de udvendige overflader af med en blød, damp klæde. Undgå slibende rengøringsmidler.
• Indre: Clean the inside of the oven with a mild detergent and a soft cloth after each use. For stubborn stains, place a bowl of water with lemon juice inside and microwave for a few minutes to loosen residue.
• Dørtætninger: Keep the door seals clean to ensure proper closure.
• Drejeplade og grillrist: The glass turntable and metal grill rack can be removed and washed with warm soapy water or in a dishwasher.
• Always ensure the oven is unplugged before cleaning.

7. Fejlfinding

Hvis du støder på problemer med din ovn, kan du se følgende almindelige problemer og løsninger:

If the problem persists after attempting these solutions, please contact SEVERIN customer support.

8. Specifikationer

Technical details for the SEVERIN MW 7775 3-in-1 Microwave Oven:

9. Garanti og support

For warranty information, product registration, or technical support, please refer to the warranty card included with your purchase or visit the official SEVERIN webwebsted. Gem din købsbevis i tilfælde af garantikrav.
