1. Introduktion
Welcome to the Metro Mobility user manual for your new 4-Wheel Foldable Mobility Scooter. This manual provides essential information for the safe operation, maintenance, and troubleshooting of your scooter. Please read it thoroughly before operating the device.
The Metro Mobility scooter is designed to provide reliable and comfortable personal transportation for adults, offering enhanced mobility and independence. It features a robust design, comfortable seating, and user-friendly controls, making it suitable for various daily activities and travel.
2. Vigtige sikkerhedsoplysninger
WARNING: Failure to follow these safety instructions could result in serious injury or damage to the scooter.
- Always read and understand all instructions before operating the scooter.
- Overskrid ikke den maksimale vægtkapacitet på 300 lbs.
- Ensure the scooter is fully assembled and all locking mechanisms are secure before use.
- Operate the scooter on stable, level surfaces. Avoid steep inclines exceeding 10 degrees.
- Use caution when operating near traffic or pedestrians.
- Always use headlights and rear brake lights when operating in low light conditions.
- Hold hænder og fødder væk fra bevægelige dele.
- Brug ikke scooteren under påvirkning af alkohol eller medicin, der forringer dømmekraften.
- Regularly inspect tires, brakes, and battery for proper function.
- Keep children and pets away from the scooter during operation and charging.
3. Produktfunktioner
The Metro Mobility Max Sport Blue scooter is equipped with several features designed for comfort, safety, and convenience:
- Kraftig motor: 300 Watt motor providing a range of up to 10 miles per charge.
- Høj vægtkapacitet: Safely supports up to 300 pounds.
- Holdbare dæk: 9-inch solid tires engineered for safety and durability.
- Komfortable siddepladser: Thickened luxury leather seat and backrest with height adjustment.
- Justerbare armlæn: Padded armrests can be adjusted forward or backward.
- Intuitive kontroller: Ergonomic wraparound handles for one-handed operation, suitable for left-handed users.
- Forbedret synlighed: Equipped with headlights and rear brake lights.
- Nem adskillelse: Quickly disassembles into 4 separate sections for portability.
- Kompakt opbevaring: Heaviest piece (61 lbs) folds to 47 x 22 x 20 inches for easy transport in a car trunk.
- Bekvemmeligheder: Includes a 2-in-1 cup and phone holder.
4. Identifikation af komponenter og dele
Familiarize yourself with the main components of your Metro Mobility scooter:
Figur 4.1: Samlet set view of the Metro Mobility Max Sport Blue scooter, showing its compact design and included basket and flag.
Figur 4.2: Detaljeret view of the intuitive controls on the handlebars, including battery level indicator, speed control, power switch, forward/reverse levers, headlight switch, and horn button.
Figur 4.3: The scooter disassembled into its four main components: seat (20.9 lbs), basket (4.2 lbs), rear section (60.6 lbs), and front section with tiller (16.1 lbs). The total weight is approximately 101.9 lbs.
4.1 Kontrolpanel overview
The control panel on the tiller provides access to all operational functions:
- Batteriniveauindikator: Displays the current charge level of the battery.
- Hastighedsknap: Adjusts the maximum speed of the scooter.
- Afbryderen: Tænder og slukker for scooteren.
- Forward/Reverse Levers: Push to move forward, pull to move in reverse.
- Forlygtekontakt: Aktiverer forlygten.
- Horn knap: Sounds the horn for warning.
5. Opsætning og montering
Your Metro Mobility scooter is designed for easy assembly. Follow these steps to set up your scooter:
- Udpakning: Fjern forsigtigt alle komponenter fra emballagen. Kontroller, at alle dele er til stede i henhold til paklisten.
- Attaching the Rear Section: Place the rear drive section on a flat surface.
- Connecting the Front Section: Align the front tiller section with the rear drive section and securely connect them. Ensure the locking mechanism clicks into place.
- Montering af sædet: Insert the seat post into the receiver on the scooter base. Adjust the seat height to your preference and secure it.
- Attaching Armrests: Slide the armrests into their designated slots on the seat frame.
- Mounting the Basket: Attach the front basket to the tiller post.
- Batteri installation: Ensure the batteries are properly installed and connected. The scooter uses two 12V batteries (included).
- Indledende opkrævning: Before first use, fully charge the scooter's batteries. Refer to the "Charging the Battery" section for details.
Figur 5.1: Visual guide to the four main components for assembly and disassembly.
6. Betjeningsvejledning
6.1 Tjekliste før brug
- Sørg for, at batteriet er fuldt opladet.
- Check tire pressure (if applicable, though product states solid tires).
- Bekræft, at alle forbindelser er sikre.
- Adjust seat and tiller to a comfortable position.
- Ensure clear path ahead.
6.2 Start og kørsel
- Tænd: Insert the key into the ignition and turn it to the "ON" position. The battery indicator will light up.
- Juster hastighed: Use the speed control dial to set your desired maximum speed. Start with a lower speed until you are comfortable.
- Fremadgående bevægelse: Gently press the right-hand lever (or push the forward lever) to move forward. The scooter will accelerate smoothly.
- Omvendt bevægelse: Gently press the left-hand lever (or pull the reverse lever) to move in reverse.
- Styretøj: Use the tiller to steer the scooter. The turning radius is 46 inches.
- Bremsning: Release the forward/reverse lever to engage the electromagnetic brake. The scooter will come to a smooth stop.
- Lys og horn: Use the headlight switch for illumination and the horn button for alerts as needed.
Figur 6.1: Reference the control panel for operating functions.
6.3 Opladning af batteriet
For at sikre optimal batterilevetid og ydeevne skal du følge disse retningslinjer for opladning:
- Only use the charger provided by Metro Mobility.
- Sæt opladeren i ladeporten på scooteren.
- Sæt opladeren i en almindelig stikkontakt.
- Allow the battery to charge fully. The indicator light on the charger will change color (e.g., from red to green) when charging is complete.
- Overoplade ikke batteriet. Tag stikket ud af opladeren, når opladningen er færdig.
- Charge the battery after each use, even if only for a short period, to maintain battery health.
7. Vedligeholdelse og pleje
Regular maintenance will extend the life and performance of your scooter:
- Rensning: Tør scooteren af med reklameamp cloth. Do not use abrasive cleaners or spray water directly onto electrical components.
- Batteripleje:
- Hold batterierne fuldt opladede, når de ikke er i brug.
- Store the scooter in a cool, dry place if not used for extended periods, and charge the battery at least once a month.
- Inspect battery terminals for corrosion and ensure connections are tight.
- Dæk: The scooter uses solid tires, eliminating the need for air pressure checks. Periodically inspect them for wear and tear.
- Elektriske forbindelser: Check all cables and connectors for signs of damage or loose connections.
- Bevægelige dele: Periodically check all nuts, bolts, and fasteners for tightness. Do not lubricate the motor or brake components.
- Opbevaring: When storing the scooter for long periods, ensure the battery is fully charged and disconnect it if possible. Store in a dry, protected area.
8. Fejlfindingsvejledning
This section addresses common issues you might encounter with your scooter. If the problem persists, contact Metro Mobility customer support.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Scooteren tænder ikke. | Battery is low or dead; Power switch is off; Loose battery connection. | Charge the battery; Turn the power switch on; Check battery connections. |
| Scooteren kører langsomt eller mangler kraft. | Low battery charge; Speed setting too low; Overload (exceeding weight capacity). | Recharge battery; Adjust speed dial to higher setting; Reduce load. |
| Bremserne aktiveres ikke korrekt. | Brake lever not fully released; Electrical issue. | Ensure lever is fully released; Contact customer support if issue persists. |
| Scooteren laver usædvanlige lyde. | Loose components; Obstruction in wheels/motor. | Inspect for loose parts and tighten; Remove any obstructions. |
9. Tekniske specifikationer
| Specifikation | Detalje |
|---|---|
| Modelnummer | MAX SPORT BLUE |
| Motorkraft | 300 watt |
| Maks. rækkevidde pr. opladning | Op til 10 miles |
| Vægt kapacitet | 300 lbs |
| Dæk type | 9 tommer massive dæk |
| Venderadius | 46 tommer |
| Klatregrad | 10 grader |
| Produktmål (samlet) | 47.24 x 21.06 x 37.4 tommer |
| Heaviest Piece Weight (Disassembled) | 61 lbs |
| Samlet varevægt | 101 pund |
| Batterier | 2 x 12V (inkluderet) |
| Materiale | Leather (seat) |
Figur 9.1: Detailed dimensions of the Metro Mobility Max Sport Blue scooter, including overall length, width, height, and ground clearance.
10. Garanti og support
Metro Mobility provides a comprehensive guarantee for your product:
- Garanti: 5-year limited guarantee.
- Kundeservice: Professional after-sales service is available.
- Kontakte: For any issues or inquiries regarding your scooter, please contact Metro Mobility USA LLC directly. Refer to your purchase documentation for specific contact details.
Metro Mobility USA is a US-based company specializing in the design and development of disability and mobility vehicles, committed to providing quality products and support.
