PIZZELLO 16-inch Dual-Fuel Pizza Oven Instruction Manual

1. Introduktion

Thank you for choosing the PIZZELLO 16-inch Dual-Fuel Pizza Oven. This versatile outdoor oven offers the convenience of propane gas and the authentic flavor of wood-fired cooking. Designed for portability and efficiency, it allows you to create delicious pizzas and other dishes in minutes. Please read this manual thoroughly before assembly, operation, or maintenance to ensure safe and optimal performance.

Image: The PIZZELLO 16-inch Dual-Fuel Pizza Oven, showcasing its compact design and various included accessories like the pizza peel, stone, and gas burner.

2. Sikkerhedsoplysninger

WARNING: For outdoor use only. Do not operate indoors. Read all instructions before using this appliance.

• Always operate the oven on a stable, level, non-combustible surface.
• Keep the oven clear of combustible materials, gasoline, and other flammable liquids and vapors.
• Ensure proper ventilation. Do not block the chimney or oven opening.
• Allow the oven to cool completely before moving or cleaning.
• When using propane, ensure all connections are tight and test for leaks before each use.
• Keep children and pets away from the hot oven.
• Brug varmebestandige handsker ved håndtering af varme komponenter.

3. Hvad er der i æsken

Kontroller, at alle komponenter er til stede og ubeskadigede ved udpakning:

• 16" Propane Pizza Oven Unit
• 16" Pizza Stone (Cordierite)
• Propane Gas Burner with Hose and Regulator
• Wood Burner Tray
• Pizzaskræl i rustfrit stål
• Pizzaskærer
• Pelletsske
• Waterproof Carry Bag

Image: A visual representation of all the accessories included with your PIZZELLO pizza oven, such as the gas burner, wood tray, pizza stone, pizza peel, pizza cutter, pellet scoop, and carry bag.

4. Opsætning og montering

4.1 Unfolding the Legs and Attaching Chimney

Carefully unfold the oven's legs until they lock into place. Insert the chimney into the designated opening on top of the oven and secure it. The oven is designed for easy transport with foldable legs and a detachable chimney.

Image: The PIZZELLO pizza oven fully assembled with its chimney and legs extended, ready for use.

4.2 Installing the Pizza Stone

Slide the cordierite pizza stone into the oven's interior slot. Ensure it sits flat and securely. This stone provides even heat distribution for perfect crusts.

4.3 Choosing Your Fuel Source (Propane or Wood)

Your PIZZELLO oven supports both propane gas and wood pellets/chips. Select the appropriate burner for your cooking preference.

Image: Illustration showing the two fuel options for the PIZZELLO oven: a wood pellet tray and a gas burner, highlighting its dual-fuel capability.

4.3.1 Propane Gas Burner Installation

Attach the propane gas burner to the rear of the oven. Ensure the gas hose is securely connected to both the burner and your propane tank. An AAA battery (not included) is required for the igniter. Insert the battery into the designated compartment on the burner unit.

Image: Detailed steps showing how to install the AAA battery into the gas burner and connect the propane hose.

4.3.2 Wood Burner Tray Installation

If using wood, ensure the propane burner is removed. Insert the wood burner tray into the rear opening. If a baffle is present to prevent ash, it may need to be removed for optimal wood-fired performance (refer to troubleshooting if issues arise).

5. Betjeningsvejledning

5.1 Preheating the Oven

For best results, preheat the oven to 752°F (400°C). This typically takes 25-30 minutes. Monitor the built-in thermometer on top of the oven to ensure it reaches the desired temperature.

Billede: Et nærbillede view of the oven's integrated thermometer, indicating the internal temperature for optimal cooking.

5.2 Cooking with Propane Gas

Once preheated, launch your pizza using the pizza peel. The oven can cook a pizza in approximately 60 seconds. Rotate the pizza frequently (every 30-45 seconds) to ensure even cooking and prevent burning, especially the side closest to the flame.

Image: A person sliding a pizza into the hot PIZZELLO oven using a pizza peel.

5.3 Cooking with Wood Pellets/Chips

Load the wood burner tray with appropriate wood pellets or small wood chips. Ignite the wood. As with gas, preheat the oven to the desired temperature. Add more pellets as needed to maintain heat. Be mindful of smoke when adding fuel and wait for it to subside before inserting food.

Image: A person using the provided pellet scoop to add wood pellets to the oven's wood burner tray.

5.4 Monitoring Cooking Progress

The oven features a small opening to check on your food without fully removing the door. This helps maintain consistent internal temperature.

Billede: Et nærbillede view of the oven's front, highlighting the small opening that allows for easy checking of food without significant heat loss.

5.5 Officiel produktvideo

6. Vedligeholdelse og rengøring

Regular maintenance ensures the longevity and performance of your pizza oven.

• Rengøring af pizzastenen: Allow the stone to cool completely. Scrape off any burnt food residue with a brush or scraper. Do not use soap or harsh detergents, as the porous stone will absorb them.
• Ovn interiør: After each use and once cooled, brush out any ash or debris from the oven interior.
• Ydre: Tør det udvendige af med adamp klud. Undgå slibende rengøringsmidler, der kan beskadige overfladen.
• Opbevaring: When not in use, store the oven in a dry place, ideally using the provided waterproof carry bag.

7. Fejlfinding

7.1 Almindelige problemer og løsninger

• Pizza Stone Cracks: This can occur if a cold stone is placed into a hot oven. Always insert the pizza stone before preheating the oven.
• Gas Burner Not Igniting/Low Flame: Ensure the propane tank is full and connected securely. Check that the O-ring is present and properly seated on the gas hose connection. Verify the igniter battery (AAA) is correctly installed.
• Excessive Soot/Ash with Wood: Ensure the baffle (if present) is removed when using the wood burner. Use dry, appropriate wood pellets/chips.
• Uneven Cooking/Burnt Spots: Rotate the pizza frequently during cooking. Ensure the oven is fully preheated to the target temperature before inserting the pizza.

If you encounter persistent issues not covered here, please contact PIZZELLO customer support.

8. Specifikationer

9. Garanti og support

For warranty information or technical support, please contact PIZZELLO customer service. Refer to the product packaging or the PIZZELLO brand store on Amazon for contact details.

PIZZELLO is committed to providing high-quality products and excellent customer service. If you have any questions or concerns, do not hesitate to reach out.

Online support: Visit the PIZZELLO Store on Amazon
