SONOFF B05-BL-A19 Wi-Fi Smart RGB LED Bulb User Manual

1. Introduktion

This manual provides detailed instructions for the installation, operation, and maintenance of your SONOFF B05-BL-A19 Wi-Fi Smart RGB LED Bulb. Please read this manual thoroughly before using the product to ensure proper function and safety.

2. Produktet er slutview

2.1 Hvad er inkluderet

• 1 x SONOFF B05-BL-A19 Wi-Fi Smart RGB LED Bulb
• 1 x brugermanual

2.2 Nøglefunktioner

• APP-parring: Fast pairing via the eWeLink APP.
• Adjustable Schedule/Scene Action: Customize brightness, color temperature, and color within schedules or scenes.
• Standard base: E26/E27 compatibility.
• Energibesparelse: Low annual power consumption (approx. 9.9kWh/year).
• Stemmestyring: Compatible with Alexa and Google Assistant.
• eWeLink-fjernbetjening: Functions as a gateway for eWeLink-Remote control when paired with S-MATE or R5 remote controller (sold separately).
• Rhythm Live: Syncs light colors with music rhythm detected by your smartphone's microphone (up to 10 bulbs in LAN).

Image 1: SONOFF B05-BL-A19 Smart RGB LED Bulb and its eWeLink app interface.

3. Opsætningsvejledning

3.1 Fysisk installation

1. Ensure the power to the light fixture is turned off at the switch before installation.
2. Carefully screw the SONOFF B05-BL-A19 bulb into a standard E26 or E27 light socket.
3. Tænd for strømmen til lampen. Pæren skal lyse.

Image 2: The SONOFF B05-BL-A19 bulb features a standard E26/E27 base for easy installation.

3.2 App Pairing (eWeLink APP)

1. Download the eWeLink APP from the App Store (iOS) or Google Play Store (Android).
2. Registrer dig eller log ind på din eWeLink-konto.
3. Sørg for, at din smartphone er forbundet til et 2.4 GHz Wi-Fi-netværk.
4. Power on the bulb. If it's not already in pairing mode (blinking rapidly), turn it off and on three times consecutively until it blinks rapidly.
5. Open the eWeLink APP, tap the '+' icon in the bottom center, and select 'Add Device'.
6. Follow the on-screen instructions to complete the pairing process. The app will detect the bulb and guide you through connecting it to your Wi-Fi network.

4. Betjeningsvejledning

4.1 App kontrol

Once paired, you can control your SONOFF B05-BL-A19 bulb directly from the eWeLink APP:

• Til/fra: Toggle the power button in the app to turn the bulb on or off.
• Justering af lysstyrke: Slide the brightness bar to adjust the light intensity from 1% to 100%.
• Farvetemperatur: Juster det hvide lys fra varmt (2700K) til koldt (6500K).
• Farvevalg: Choose from a wide spectrum of RGB colors using the color wheel.

Image 3: The eWeLink app allows precise control over the bulb's color and brightness settings.

4.2 Stemmestyring (Alexa og Google Assistant)

Integrate your smart bulb with Amazon Alexa or Google Assistant for convenient voice control:

1. Forbind din eWeLink-konto med din Alexa- eller Google Home-app.
2. Discover new devices in your voice assistant app.
3. Brug stemmekommandoer såsom:
   • "Alexa, tænd lyset i stuen."
   • "Hey Google, set the bedroom light to blue."
   • "Alexa, dæmp køkkenlyset til 50%."

Image 4: Control your smart bulb hands-free using voice commands with Alexa or Google Assistant.

4.3 Adjustable Schedule and Scene Actions

Automate your lighting to suit your daily routine or create specific ambiances:

• Tidsplaner: Set specific times for the bulb to turn on/off, or adjust brightness, color temperature, and color automatically. For example, have the light gradually brighten in the morning.
• Scener: Create custom lighting presets for different activities or moods (e.g., "Movie Night" scene with dim, warm light, or "Reading" scene with bright, cool light).
• Smarte scener: Combine the bulb with other SONOFF devices. For instance, set the light to turn on automatically when a door sensor detects entry.

Image 5: Automated lighting schedules can be set for various times and activities.

4.4 Rhythm Live

Experience dynamic lighting that syncs with your music:

• In the eWeLink APP, navigate to the Rhythm Live feature.
• Your smartphone's microphone will detect ambient music.
• Up to 10 SONOFF smart bulbs in the same local area network (LAN) can change colors in sync with the music's rhythm, creating an immersive audio-visual experience.

Image 6: The Rhythm Live feature synchronizes your smart bulbs with music for an enhanced atmosphere.

4.5 Gruppekontrol

Manage multiple smart bulbs simultaneously for unified lighting control:

• In the eWeLink APP, create a group for your desired bulbs.
• Once grouped, you can turn them all on/off, adjust brightness, change color temperature, or apply scenes to the entire group with a single command.

Image 7: Group control allows managing multiple bulbs simultaneously through the eWeLink app.

5. Vedligeholdelse

5.1 Generel pleje

• Ensure the bulb is powered off before cleaning.
• Tør pæren af ​​med en blød, tør klud. Brug ikke flydende rengøringsmidler eller slibende materialer.
• Avoid exposing the bulb to excessive moisture or extreme temperatures.

5.2 Energy Conservation

The SONOFF B05-BL-A19 is designed for energy efficiency, consuming approximately 9.9 kWh per year under typical usage (based on 3 hours/day at neutral light). Utilizing schedules and dimming features can further reduce energy consumption.

Image 8: The SONOFF B05-BL-A19 is Energy Star certified, promoting energy conservation.

6. Fejlfinding

• Bulb not pairing:
  - Ensure your Wi-Fi network is 2.4GHz. The bulb does not support 5GHz networks.
  - Make sure the bulb is blinking rapidly (pairing mode). If not, power cycle it three times.
  - Check your Wi-Fi signal strength near the bulb.
  - Temporarily disable VPN or firewall settings on your phone during pairing.
• Bulb frequently goes offline:
  - Verify your Wi-Fi router is functioning correctly and has a stable internet connection.
  - The bulb might be too far from the Wi-Fi router. Consider using a Wi-Fi extender.
  - Ensure there are no strong interferences (e.g., other 2.4GHz devices) near the bulb or router.
• Stemmestyring virker ikke:
  - Confirm that your eWeLink account is correctly linked to Alexa or Google Assistant.
  - Ensure the bulb is online in the eWeLink app.
  - Try re-discovering devices in your voice assistant app.
• Colors appear weak or inaccurate:
  - While the bulb offers a wide color range, some specific hues (e.g., certain greens or reds) might appear less saturated compared to others. This is typical for some RGB LED bulbs.
• Bulb does not respond to app commands:
  - Check if your phone has an internet connection.
  - Ensure the bulb is powered on and online in the eWeLink app.
  - Try restarting the eWeLink app or your phone.

7. Specifikationer

Image 9: Technical specifications and dimensions of the SONOFF B05-BL-A19 Smart RGB LED Bulb.

8. Garanti og support

8.1 Garantioplysninger

The SONOFF B05-BL-A19 Wi-Fi Smart RGB LED Bulb comes with a 1 års begrænset garanti fra købsdatoen. Denne garanti dækker fabrikationsfejl og funktionsfejl ved normal brug. Den dækker ikke skader forårsaget af misbrug, ulykker, uautoriserede ændringer eller forkert installation.

8.2 Kundesupport

For teknisk assistance, fejlfinding eller garantikrav, kontakt venligst SONOFFs kundesupport via deres officielle website or the eWeLink APP. Please have your product model number (B05-BL-A19) and proof of purchase ready when contacting support.
