Indledning
The WHILL Model F Power Chair is designed to offer unparalleled convenience and performance, providing a perfect mobility solution for adults and the elderly. Its innovative foldable design, smart technology integration, and remote control capabilities via a dedicated app enhance user independence and ease of travel. This manual provides comprehensive instructions for the safe and effective operation, maintenance, and troubleshooting of your WHILL Model F Power Chair.
Figure 1: The WHILL Model F Power Chair, showcasing its sleek black finish and compact structure.
Nøglefunktioner
- Foldable & Lightweight: The WHILL Model F folds in less than 3 seconds and weighs less than 53 lbs when the battery is removed, making it highly portable.
- Høj ydeevne: Offers a 12.4-mile range per charge (Lithium-ion battery), a 250lb user weight capacity, and a top speed of 3.7 mph.
- Fjernbetjening: Utilize the WHILL app to remotely drive and control the Model F.
- Powerful & Maneuverable: Capable of climbing over obstacles up to 1.4 inches high with its dual powerful motors. Features a tight 30.7-inch turning radius for navigating narrow spaces.
- Justerbar: The controller and armrest height, controller side (right or left), arm height, and arm width (18-20 inches between armrests) are all adjustable for personalized comfort.
Figure 2: Step-by-step illustration of the WHILL Model F's quick folding mechanism.
Figure 3: Demonstrating the portability and easy storage of the Model F for various travel scenarios.
Opsætning
Unfolding the Power Chair
- Place the folded chair on a flat, stable surface.
- Grasp the main frame and gently pull upwards until the chair begins to unfold.
- Continue unfolding until the seat and backrest lock into their upright positions. Ensure all locking mechanisms are securely engaged.
- Adjust the armrests and controller to your preferred height and side (left or right).
Batteriinstallation og første opladning
The WHILL Model F uses a Lithium-ion battery. For optimal performance and longevity, fully charge the battery before first use.
- Locate the battery compartment, typically under the seat or at the rear of the chair.
- Insert the battery pack firmly until it clicks into place.
- Connect the charger to the charging port on the chair and then to a standard electrical outlet.
- The charging indicator light will show the charging status. Disconnect the charger once the battery is fully charged.
Betjeningsvejledning
Grundlæggende betjening
- Tænd/sluk: Press and hold the power button on the controller until the indicator lights illuminate/extinguish.
- Kørsel: Use the joystick on the controller to steer and control speed. Push forward to move forward, pull back to reverse, and move left/right to turn.
- Hastighedstilpasning: The controller allows for adjustment of speed settings. Refer to the controller's specific markings for speed levels.
- Manøvrering: The 30.7-inch turning radius allows for tight turns in confined spaces like hallways and elevators.
- Forhindringsfrihed: The dual motor drive system enables the chair to climb over obstacles up to 1.4 inches high. Approach obstacles slowly and directly.
- Vandtæthed: The design incorporates water-resistant features, making it suitable for use in light rain or over puddles. Avoid submerging the chair or exposing it to heavy downpours.
Using the WHILL App for Remote Control
The WHILL app allows for remote driving, locking/unlocking, and managing speed settings. Download the official WHILL app from your device's app store.
- Sørg for, at din smartphones Bluetooth er aktiveret.
- Open the WHILL app and follow the on-screen instructions to pair with your Model F.
- Once connected, you can use the app interface to control the chair's movement and adjust settings.
Video 1: Official demonstration of the WHILL Model F's features, including folding, maneuverability, and remote control capabilities.
Figure 4: The Model F allows users to explore their surroundings with greater mobility and independence.
Opretholdelse
Almen pleje
- Hold stolen ren ved at tørre den af med adamp klud. Undgå skrappe kemikalier eller slibende rengøringsmidler.
- Kontrollér regelmæssigt alle møtrikker, bolte og fastgørelseselementer for at sikre, at de er stramme.
- Inspect tires for wear and tear.
Batteripleje
- Oplad batteriet regelmæssigt, selvom stolen ikke er i hyppig brug, for at opretholde batteriets tilstand.
- Opbevar batteriet et køligt og tørt sted, når det ikke er i brug i længere perioder.
- Undgå at aflade batteriet helt før genopladning.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Stolen tænder ikke. | Batteriet er ikke opladet eller ikke korrekt installeret. | Ensure battery is fully charged and securely seated in its compartment. Check power button connection. |
| Chair moves erratically or not at all. | Joystick malfunction, loose connection, or motor issue. | Check joystick for obstructions. Power cycle the chair. If problem persists, contact customer support. |
| Difficulty transferring to/from the chair. | Armrests not designed to fully move out of the way for side transfers. | Plan transfers carefully. If side transfer is necessary, ensure adequate space and consider using assistive devices or assistance from another person. The armrests are adjustable in height and width, but do not fully swing away. |
| Problemer med app-forbindelse. | Bluetooth interference or app not updated. | Ensure Bluetooth is on and close to the chair. Restart the app and chair. Check for app updates. |
Specifikationer
| Attribut | Detalje |
|---|---|
| Mærke | VIL |
| Modelnavn | Model F (Fi) |
| Farve | Sort |
| Produktmål (L x B x H) | 36.8 x 21.9 x 31.6 tommer |
| Varens vægt | 58.9 pounds (less than 53 lbs with battery removed) |
| Vægt kapacitet | 250 lbs |
| Tophastighed | 3.7 mph |
| Rækkevidde pr. opladning | 12.4 miles |
| Batteritype | 1 lithium-ion batteri (medfølger) |
| Hindringsrydning | Op til 1.4 tommer |
| Venderadius | 30.7 tommer |
| Sammenfoldelig | Ja |
| Inkluderede komponenter | Storage Basket, Remote |
Figure 5: Visual summary of the WHILL Model F's performance specifications.
Sikkerhedsoplysninger
This product has a weight capacity of up to 250 lbs. Improper use or exceeding this limit may result in injury. Ensure the product is fully assembled and adjusted according to the instructions, and always follow the manufacturer's guidelines for safe operation, especially when using folding or adjustable features.
- Always read and understand the entire user manual before operating the power chair.
- Do not operate the chair under the influence of alcohol or medication that may impair your judgment.
- Avoid steep inclines or declines that exceed the chair's specified capabilities.
- Hold hænder og tøj væk fra bevægelige dele.
- Always use caution when operating near traffic or pedestrians.
Garanti og support
For detailed warranty information, please refer to the warranty card included with your product packaging or visit the official WHILL website. For technical support, spare parts, or service inquiries, please contact WHILL customer support directly.
You can find more information and contact details on the official WHILL store page: WHILL Official Store
