Indledning
Thank you for choosing the Inventor Portable Air Conditioner Magic 5-1. This versatile appliance is designed to provide optimal climate control for your living space, offering five distinct functions: cooling, heating, fan, dehumidifier, and auto mode. With its powerful 12,000 BTU capacity, digital display, and remote control, the Magic 5-1 ensures comfort and convenience throughout the year. This manual provides essential information for safe operation, installation, maintenance, and troubleshooting to help you get the most out of your unit.
Figure 1: Inventor Portable Air Conditioner Magic 5-1 and Accessories
This image displays the main unit of the Inventor Portable Air Conditioner Magic 5-1, a sleek white appliance, alongside its essential accessories. These include the flexible exhaust hose, various components of the window installation kit, and the compact remote control, all necessary for setup and operation.
Opsætning og installation
Proper setup is crucial for the efficient and safe operation of your portable air conditioner. Please follow these steps carefully.
1. Udpakning og placering
- Tag forsigtigt enheden og alt tilbehør ud af emballagen. Gem emballagen til senere opbevaring eller transport.
- Place the unit on a firm, level surface in the room where it will be used. Ensure there is at least 30 cm (12 inches) of clear space around the air inlets and outlets for proper airflow.
- The unit is equipped with omni-directional casters for easy movement.
Figure 2: Easy Mobility with Casters
This image illustrates the ease of moving the portable air conditioner. A young child is shown effortlessly pushing the unit, highlighting its omni-directional casters that allow for convenient relocation within your home.
2. Montering af vinduessæt
The included flexible window kit is designed for standard slider or double-hung windows to exhaust hot air outside.
- Assemble the window slider kit components according to your window type. The exhaust hose can be stretched up to 1.6 meters in length.
- Fastgør udstødningsslangen til enhedens udstødningsport og derefter til vinduesskyderadapteren.
- Insert the window slider into the window opening and secure it. Ensure a tight seal to prevent outside air from entering.
- Connect the window slider adapter to the opening in the window kit.
Figure 3: Window Kit Components
This image displays all the individual components of the window installation kit provided with the portable air conditioner. It includes the expandable exhaust hose, the adjustable window sealing plate, and various connectors and adapters required for a secure and efficient setup.
Figure 4: Window Kit Installation Steps
This diagram illustrates the two primary steps for installing the window kit. The top panel shows how to attach the window slider to the window opening, while the bottom panel demonstrates inserting the exhaust hose adapter into the designated hole on the window slider for a complete seal.
Betjeningsvejledning
Your Inventor Magic 5-1 offers multiple functions for year-round comfort. Familiarize yourself with the control panel and remote control for optimal use.
Kontrolpanel og fjernbetjening
The unit features a digital display that shows the current temperature in either Celsius or Fahrenheit. The multi-functional control panel on the unit, along with the included remote control, allows you to easily set the timer, adjust temperature, and switch between modes.
Figure 5: Unit Features and Dimensions
This image highlights key features of the portable air conditioner, including Auto Swing for even air distribution, Auto Restart to resume previous settings after a power outage, compatibility with a Window Kit, and a Tank Fullness Indicator. The unit's dimensions (WxDxH) of 46.7 x 39.7 x 76.5 cm are also clearly displayed.
Driftstilstande
The Magic 5-1 integrates five convenient modes:
- Køletilstand: Chills your room effectively during hot weather conditions.
- Opvarmningstilstand: Provides warmth to your room during cold winter months.
- Ventilatortilstand: Delivers either a gentle or powerful air stream without temperature modification.
- Tørretilstand (affugter): Dehumidifies the air, helping to maintain room humidity between 40% and 60%.
- Automatisk tilstand: Automatically selects the appropriate operating mode based on the ambient temperature.
Figure 6: All-Weather Performance and 5 Modes
This image showcases the portable air conditioner's capability for excellent performance in both cooling and heating modes, making it an all-weather solution. Below the unit, icons clearly represent its five operating modes: Auto, Cool, Dry, Fan, and Heat.
Yderligere funktioner
- Temperaturområde: The unit operates within a temperature range of 17°C (62°F) to 30°C (86°F).
- Sove mode: Activate Sleep Mode for quiet operation and energy savings, creating ideal conditions for rest. The noise level in sleep mode is approximately 52 dB(A).
- Automatisk genstart: In case of a power interruption, the unit will automatically restart with the previously set mode once power is restored.
- Følg mig-funktionen: This feature allows the remote control to act as a thermostat, sensing the temperature at its location and adjusting the unit's operation to maintain your desired comfort level wherever you are in the room.
Figure 7: Sleep Mode for Quiet Comfort
This image depicts a young girl sleeping soundly on a sofa, emphasizing the quiet operation of the air conditioner in Sleep Mode. Icons for silent operation and a crescent moon symbolize this feature, with a clear indication of a low noise level at 52 dB(A), promoting undisturbed rest.
Figure 8: Follow Me Function and Coverage
This image illustrates the "Follow Me" function, where a woman is shown relaxing with the remote control, which acts as a mobile thermostat. The graphic highlights the unit's temperature range (17°C to 30°C) and its ability to cool or heat areas up to 370 square feet, ensuring comfort wherever the remote is located.
Opretholdelse
Regelmæssig vedligeholdelse sikrer dit klimaanlægs levetid og effektive ydeevne.
Rengøring af luftfilter
The unit includes a removable and reusable air filter designed to protect against dust and pet hair. For optimal performance and to ensure clean, cool air, it is recommended to clean the filter every two weeks.
- Sluk for enheden, og tag stikket ud før rengøring.
- Locate and remove the air filter. Refer to your unit's specific design for filter access.
- Rengør filteret med en støvsuger for at fjerne støv, eller vask det forsigtigt med lunkent vand og et mildt rengøringsmiddel.
- Lad filteret lufttørre helt, før det sættes i enheden igen. Udsæt det ikke for direkte sollys.
Vandafløb
During dehumidifying or heating operations, water may accumulate in the internal tank. The unit has a tank fullness indicator. When the tank is full, the unit may stop operating until drained. Use the provided tubing for continuous drainage if desired, especially during prolonged dehumidifier or heating use.
- Locate the drainage port at the back of the unit.
- Place a suitable container under the drainage port.
- Fjern aftapningsproppen, så vandet kan løbe ud.
- Replace the drain plug securely once the tank is empty.
Figur 9: Bagside View and Drainage Port
This image provides a detailed rear view of the Inventor Portable Air Conditioner. It clearly shows the large circular exhaust port for the hose, the power cord connection, and the smaller drainage outlet, which is used for emptying condensed water from the unit.
Fejlfinding
If you encounter issues with your unit, please consult the following common problems and solutions before contacting support.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Enheden tænder ikke. | Ingen strøm, netledning frakoblet, afbryder udløst. | Sørg for, at enheden er tilsluttet en fungerende stikkontakt. Kontroller afbryderen. |
| Enheden kører, men køler/varmer ikke. | Air filter clogged, window kit not properly sealed, room too large, door/window open. | Clean air filter. Ensure window kit is sealed. Close doors/windows. Verify room size is within unit's capacity. |
| Enheden er støjende. | Enheden står ikke på en plan overflade, ventilatorhastigheden er for høj, de indvendige komponenter vibrerer. | Place unit on a flat, stable surface. Reduce fan speed. If noise persists, contact support. |
| Vandlækage. | Drain plug not secured, drainage hose kinked or blocked, internal tank full. | Ensure drain plug is tightly closed. Check drainage hose for kinks/blockages. Drain the internal tank. |
Specifikationer
Detailed technical specifications for the Inventor Portable Air Conditioner Magic 5-1 (Model M3GHP290-12BS).
| Feature | Detalje |
|---|---|
| Mærke | Opfinder |
| Model | M3GHP290-12BS |
| Produktdimensioner (BxDxH) | 39.7 x 46.7 x 76.5 cm |
| Varens vægt | 34.4 kg |
| Kølekraft | 12,000 BTU/t |
| Energieffektivitet (køling) | Klasse A |
| Energieffektivitet (opvarmning) | Klasse A + |
| Årligt energiforbrug | 1000 watt |
| Støjniveau | 64 dB (Standard), 52 dB(A) (Sleep Mode) |
| Installationstype | Window (Portable) |
| Farve | Hvid |
| Voltage | 240.0 V |
| Wattage | 1350.0 W |
| Kølevæsketype | R290 (Climate-friendly) |
| Inkluderede komponenter | Window Kit, Remote Controller |
Figure 10: Product Fiche
This image displays the official Product Fiche, a table detailing the energy and performance specifications for the Inventor Magic portable air conditioner, specifically models M3GHP290-12 and M3GHP290-12BS. It includes data such as Energy Class, EER, Design Load, Electricity Consumption, Sound Pressure Level, Refrigerant Type, and GWP.
Garanti og support
Inventor is committed to providing high-quality products and excellent customer service.
Garantioplysninger
Your Inventor Portable Air Conditioner Magic 5-1 comes with a 2 års garanti, hvilket sikrer ro i sindet med hensyn til dens kvalitet og ydeevne.
Kundesupport
As air cooling experts, Inventor maintains multiple communication channels to support our customers. Should you have any questions, require assistance, or need to address any concerns, please do not hesitate to contact our dedicated customer support team. We strive to offer an impeccable after-sales service tailored to your needs.
For further information or assistance, please visit the official Inventor Store on Amazon or refer to the contact details provided with your product documentation.
Figure 11: Dedicated Customer Support
This image features a friendly customer service representative with a headset, symbolizing Inventor's commitment to customer support. Accompanying icons for phone, email, and location services indicate the various channels available for customers to reach out for assistance and inquiries.
