Indledning
Welcome to the user manual for your Navitel R250 DUAL NV Dash Cam. This guide provides detailed instructions on how to set up, operate, maintain, and troubleshoot your device. The Navitel R250 DUAL NV is a high-quality dual dash camera system designed to record incidents on the road, featuring Full HD front recording, an additional rear camera, night vision, a G-sensor for impact detection, and a parking mode for enhanced security.
This image displays the main Navitel R250 DUAL NV dash camera unit alongside its accompanying rear camera. Both units are black and compact, designed for discreet installation in a vehicle.
Pakkens indhold
Markér venligst feltet for følgende elementer:
- Navitel R250 Digital Video Recorder (Front Camera)
- Bagkamera
- Forrudebeslag (sugekop)
- Bil oplader
- Video Cable for Rear Camera
- Brugermanual
- Garantikort
- Warranty Voucher
Opsætningsvejledning
1. Installation
Installation af frontkamera
- Rengør forruden, hvor du har til hensigt at montere dashcam'et.
- Attach the suction cup mount to the windshield, ensuring a secure grip.
- Slide the Navitel R250 dash cam onto the mount until it clicks into place.
- Juster kameravinklen for at sikre et klart billede view af vejen forude.
Montering af bagkamera
- Mount the rear camera on the rear window, ensuring it has a clear view.
- Connect the rear camera to the main dash cam unit using the provided video cable. Route the cable discreetly along the vehicle's interior trim.
An illustrative diagram showing a red car on a road, with the front camera positioned at the front of the vehicle and the rear camera at the back, indicating their respective fields of view for comprehensive recording.
Strømtilslutning
- Connect the car charger to the dash cam's USB port.
- Sæt den anden ende af bilopladeren i bilens 12V-stikkontakt (cigarettænder).
- Før strømkablet pænt for at undgå at blokere dit view eller forstyrrer kørslen.
2. Indledende opsætning
Isætning af hukommelseskortet
- Sørg for, at dashcam'et er slukket.
- Insert a compatible microSD card (Class 10 or higher, up to 64GB recommended) into the memory card slot until it clicks.
- For at fjerne det skal du forsigtigt skubbe kortet ind, indtil det springer ud.
First Power On & Date/Time Settings
- Once connected to power, the dash cam will automatically turn on and begin recording.
- Navigate to the system settings menu to set the correct date and time. This is crucial for accurate video timestamps.
The screen of the Navitel R250 DUAL NV dash cam is shown, displaying a live road view with overlayed information such as recording status, microphone status, current time, video resolution (1080FHD), and battery level. A memory card icon is also visible.
Betjeningsvejledning
Grundlæggende betjening
Automatic Start Recording
The device is designed to automatically start recording when the vehicle's ignition is turned on and power is supplied. Recording will stop when the ignition is turned off.
Loop-optagelse
The dash cam records video in continuous loops. When the memory card is full, the oldest unlocked files will be overwritten by new recordings. You can set the loop recording duration in the settings menu.
Nødoptagelse (G-sensor)
The built-in G-sensor (accelerometer) detects sudden impacts or rapid acceleration/deceleration. When triggered, the current video segment is automatically locked and saved to prevent it from being overwritten by loop recording. This ensures critical incident footage er bevaret.
An image highlighting the G-Sensor feature, showing the interior of a car with a focus on the dashboard, implying the sensor's role in detecting impacts and sudden maneuvers.
Parkeringstilstand
With Parking Mode enabled, the dash cam can detect vibrations and automatically start recording even when the car is parked and the engine is off. This feature provides surveillance for your vehicle when you are away.
Nattesyn
Equipped with a GC2053 sensor and 4-layer glass lenses, the Navitel R250 DUAL NV provides high-quality recording and clear images even in low-light conditions, enhancing visibility during nighttime driving.
This image demonstrates the Night Vision capability of the Navitel R250 DUAL NV, showing a clear view of a city highway at night, emphasizing the camera's ability to capture high-quality footage under dårlige lysforhold.
Vidvinkel View
The front camera features a 140-degree wide viewing angle, and the rear camera has a 100-degree angle, ensuring comprehensive coverage of the road and surrounding areas.
A visual representation of the 140-degree wide-angle lens of the Navitel R250 DUAL NV dash cam, showing its expansive field of view over a road and surrounding landscape, ensuring broad coverage.
Menu navigation
Use the buttons on the side of the dash cam to navigate through the menu options. Typically, there are buttons for Menu, Up, Down, OK/Confirm, and Mode. Refer to the on-screen prompts for specific functions.
Opretholdelse
Rensning
- Gently wipe the camera lens with a soft, lint-free cloth to ensure clear recordings.
- Brug ikke hårde kemikalier eller slibende rengøringsmidler.
Firmware opdateringer
Periodically check the official Navitel website for available firmware updates. Updating the firmware can improve performance and add new features. Follow the instructions provided with the firmware update carefully.
Hukommelseskorthåndtering
- It is recommended to format the microSD card regularly (e.g., once a month) using the dash cam's format function. This helps maintain optimal recording performance and prevents data corruption.
- Always back up important video files to a computer before formatting the card.
This image illustrates the Navitel DVR Player software running on a laptop, showing how users can manage recorded files, save video fragments, export tracks, and select recordings from either the main or rear camera.
Fejlfinding
Fælles problemer og løsninger
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Dashcam'et tænder ikke. | No power supply; faulty charger; damaged cable. | Check car charger connection and vehicle's 12V outlet. Try a different USB cable or charger. |
| Optagelsen stopper uventet. | Memory card full or corrupted; slow memory card; overheating. | Format the memory card. Use a high-speed (Class 10 or U1/U3) microSD card. Ensure proper ventilation. |
| Videokvaliteten er dårlig. | Dirty lens; protective film on lens; incorrect resolution settings. | Clean the lens. Remove any protective film. Check video resolution settings in the menu. |
| G-sensoren er for følsom/ikke følsom nok. | G-sensor sensitivity setting is too high/low. | Adjust the G-sensor sensitivity in the settings menu. |
| Rear camera not detected or no image. | Løs kabelforbindelse; defekt bakkamera. | Ensure the rear camera cable is securely connected to both cameras. Check for cable damage. |
Specifikationer
Tekniske specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Navitel |
| Modelnavn | R250 DUAL |
| Farve | Sort |
| Skærmstørrelse | 2 tommer |
| Forbindelsesteknologi | USB |
| Særlige funktioner | Automatic Start, Parking Mode, Impact Sensor (G-Sensor), Sound Recording, Motion Detection |
| Kompatible enheder | Bil |
| Batterisammensætning | Lithium-polymer |
| Videooptagelsesopløsning | 1080p (Front Camera) |
| Forreste kamera Viewi vinkel | 140 grader |
| Bagkamera Viewi vinkel | 100 degrees (approx.) |
| Monteringstype | Sugekopmontering |
Garanti og support
Garantioplysninger
Your Navitel R250 DUAL NV Dash Cam comes with a manufacturer's warranty. Please refer to the included Warranty Card and Warranty Voucher for specific terms, conditions, and duration of the warranty period. Keep your proof of purchase for warranty claims.
Kundesupport
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Navitel customer support. Visit the official Navitel website for contact information and the most up-to-date support resources.
Note: Information regarding software updates and spare parts availability is not explicitly provided at the time of this manual's creation. Please check the manufacturer's official channels for the latest information.
