Albrecht DR 86 Lille Seniorradio Brugermanual

Indledning

This user manual provides comprehensive instructions for the operation and maintenance of your Albrecht DR 86 Small Senior Radio. Please read this manual carefully before using the device to ensure proper function and safety. Keep this manual for future reference.

Sikkerhedsinstruktioner

• Do not expose the radio to water, moisture, or extreme temperatures.
• Undgå at tabe eller udsætte enheden for kraftige stød.
• Do not attempt to disassemble or repair the radio yourself. Refer all servicing to qualified personnel.
• Brug kun den medfølgende strømforsyning til opladning.
• Keep the radio away from heat sources and direct sunlight.
• Sørg for tilstrækkelig ventilation, når apparatet er i brug.

Pakkens indhold

Kontroller venligst, at alle varer er til stede i pakken:

• Albrecht DR 86 Radio
• Integrated 2200 mAh Battery (pre-installed)
• Strømforsyningsenhed
• Brugervejledning (dette dokument)

Produkt overview

Familiarize yourself with the main components and controls of your Albrecht DR 86 radio.

Figur 1: Front view of the Albrecht DR 86 radio, showing the display, speaker grille, and control buttons. Key controls include the power button, menu button, OK button, navigation/volume knob, and dedicated preset buttons (1-5).

Kontrol og visning

• 2.4 tommer LCD-skærm: Shows station information, time, menu options, and battery status. Designed for clear readability with large fonts.
• Tænd/sluk-knap (●): Tænder eller slukker for radioen.
• Menu-knap: Accesses the radio's settings and options.
• OK knap: Bekræfter valg i menuen.
• Navigation/Volume Knob: Rotates to navigate menus or adjust volume. Press to select.
• DAB/FM-knap: Switches between DAB+ and FM radio modes.
• BT knap: Activates Bluetooth mode for music streaming.
• Forudindstillede knapper (1-5): Directly access your stored favorite stations.

Porte og forbindelser

Figur 2: Side view of the Albrecht DR 86 radio, illustrating its compact dimensions and the location of the telescopic antenna and USB-C charging port.

• USB-C opladningsstik: For connecting the power supply to charge the integrated battery.
• Hovedtelefonstik: Til privat lytning (hovedtelefoner medfølger ikke).
• Teleskopantenne: Extend fully for optimal radio reception.

Opsætning

Første opstart og opladning

1. Connect the provided power supply to the USB-C charging socket on the radio and plug it into a wall outlet. The battery icon on the display will indicate charging status.
2. Tryk og hold tænd/sluk-knappen (●) to turn on the radio.
3. Upon first power-on, the radio will automatically perform a station scan for DAB+ and FM stations. This may take a few minutes.

Setting Up Senior Mode

The Senior Mode simplifies operation by limiting functions to only essential controls, preventing accidental changes. Follow these steps to activate it:

1. Sørg for, at radioen har gennemført sin indledende stationsscanning.
2. Tune to your desired DAB+ or FM stations using the standard mode (if not already in Senior Mode).
3. To store a favorite station, tune to the station, then press and hold one of the Preset buttons (1-5) until "Preset Saved" appears on the display. Repeat for up to 5 favorite stations.
4. To enable Senior Mode, navigate through the menu (using the Menu button and Navigation knob) to find the "Senior Mode" option and select "On". Once activated, only the Power button, Volume control, and Preset buttons (1-5) will be active.

Drift

Switching Operating Modes (Senior vs. Standard)

The radio offers two operating modes:

• Senior Mode: Provides simplified operation with only power on/off, volume adjustment, and direct access to 5 preset stations. All other settings are locked to prevent accidental changes.
• Standardtilstand: Offers full functionality, including station search, station list browsing, and access to all settings. This mode is used for initial setup and advanced configurations.

To switch between modes, access the "Senior Mode" option in the system settings menu. Note that Senior Mode can only be disabled from Standard Mode.

DAB+ radiodrift

1. Tryk på DAB/FM -knappen for at vælge DAB+-tilstand.
2. If a station scan has not been performed recently, the radio may initiate one.
3. Rotate the Navigation knob to browse available DAB+ stations. Press the knob or OK for at vælge en station.
4. To save a favorite station, tune to it, then press and hold one of the Preset buttons (1-5).

Betjening af FM-radio

1. Tryk på DAB/FM knappen for at vælge FM-tilstand.
2. Rotate the Navigation knob to manually tune to a frequency.
3. To auto-scan for the next available station, press and hold the Navigation knob briefly.
4. To save a favorite station, tune to it, then press and hold one of the Preset buttons (1-5).

Music Streaming via Bluetooth

Figur 3: The Albrecht DR 86 radio connected via Bluetooth to a smartphone, ready for music streaming.

1. Tryk på BT button on the radio to enter Bluetooth pairing mode. The display will show "Pairing".
2. On your smartphone or tablet, enable Bluetooth and search for available devices. Select "Albrecht DR 86" from the list.
3. Once paired, the radio will indicate a successful connection. You can now stream audio from your device to the radio.
4. Control playback (play/pause, skip tracks) from your connected device. Volume can be adjusted on both the radio and your device.

Opladning og batteri

The Albrecht DR 86 features an integrated 2200 mAh Lithium-Ion battery for portable operation.

• Opladning: Connect the radio to the power supply using the USB-C port. The battery indicator on the display will show charging progress.
• Batterilevetid: A fully charged battery provides approximately 7 hours of playback at 50% volume. Actual battery life may vary depending on volume level and usage.
• Batteripleje: For optimal battery longevity, avoid fully discharging the battery frequently. If storing the radio for an extended period, charge it to about 50% before storage.

Opretholdelse

• Rensning: Use a soft, dry cloth to clean the radio's exterior. Do not use abrasive cleaners, waxes, or solvents.
• Opbevaring: Store the radio in a cool, dry place away from direct sunlight and extreme temperatures when not in use for extended periods.
• Antenne: Handle the telescopic antenna carefully to avoid bending or breaking.

Fejlfinding

Specifikationer

Garanti og support

For warranty information or technical support, please refer to the warranty card included with your product or visit the official Albrecht Audio webDu kan også kontakte din lokale forhandler for at få hjælp.

Bemærk: Produktspecifikationer og funktioner kan ændres uden forudgående varsel.
