ENGiNDOT MLR01 Golf Afstandsmåler Brugermanual

Indledning

The ENGiNDOT MLR01 Golf Rangefinder is a high-precision laser rangefinder designed for accurate distance, speed, angle, and height measurements. Featuring 7X magnification and a measuring range of 5 to 900 yards, it is suitable for various applications including golf, hunting, and outdoor measurements. This manual provides detailed instructions for proper use and maintenance of your device.

Hvad er der i æsken

Figur 1: Pakkens indhold. The image displays all items included in the ENGiNDOT MLR01 package: the rangefinder unit, a USB charging cable, a protective pouch, a hand strap, a durable carrying case, a cleaning cloth, and the user manual.

• 1 x ENGiNDOT MLR01 Rangefinder
• 1 x USB ladekabel
• 1 x pose
• 1 x håndstrop
• 1 x Durable Carrying Case
• 1 x brugermanual
• 1 x rengøringsklud

Produkt overview

Figure 2: Rangefinder Components. This diagram labels the key parts of the rangefinder, including the power/start button, mode/toggle button, diopter focus ring, monocular, laser projector, laser receptor, USB input, and charge indicator.

The MLR01 rangefinder features a compact design with clearly labeled components for ease of use. Key components include:

• Power On & Start Button: Used to power on the device and initiate measurements.
• Mode/Toggle Button: Used to switch between measurement modes and units.
• Diopter Focus Ring: Adjusts the eyepiece for clear vision.
• Monokulær: De viewlinse.
• Laser Projector & Receptor: Emits and receives the laser for distance measurement.
• USB-indgang: Til opladning af det interne batteri.
• Opladningsindikator: Viser batteristatus.

Opsætning

Opladning af batteriet

Figur 3: USB-opladning. The rangefinder is shown connected to a power bank via its micro USB port for charging.

The MLR01 rangefinder is equipped with a 750mAh rechargeable lithium battery. Before first use, ensure the device is fully charged.

1. Locate the micro USB port on the device.
2. Connect the provided micro USB cable to the rangefinder and to any standard USB charging port (e.g., computer, wall adapter, power bank).
3. The charge indicator will show the charging status. A full charge allows for over 30,000 measurements.

Tænd/sluk

To power on the device, press the Power On/Start button. The display will activate. To power off, press and hold the Power On/Start button, or the device will automatically shut off after a period of inactivity to conserve battery.

Betjeningsvejledning

Justering af okularet

Figure 4: Eyepiece Adjustment. The image highlights the 7X magnification and the rotating eyepiece adjuster for clear vision.

Rotate the diopter focus ring (eyepiece adjuster) until the display and target appear clear and sharp to your eye.

Ændring af måleenheder

To switch between meters (m) and yards (Y), long-press the "MODE" button while the device is powered on. The unit displayed on the screen will change accordingly.

Måletilstande

Figure 5: Measurement Modes. This image illustrates the three primary operating modes: Range Mode for distance and slope, Speed Mode for object velocity, and Flag Locking Mode for golf flagpoles.

The MLR01 offers three distinct measurement modes. Press the "MODE" button once to cycle through them:

1. Range Mode (Mode 1):

   Measures the straight-line distance to a target. This mode also calculates angle, horizontal distance, and vertical height, which is particularly useful for golf with slope compensation.



   Figure 6: Range Mode Display. En eksample of the rangefinder's display showing distance, angle, and speed readings in a golf environment.
2. Speed Mode (Mode 2):

   Measures the speed of a moving object. Aim at the object and press the Power On/Start button to get a speed reading.

3. Flag Locking Mode (Mode 3):

   Designed for golf, this mode helps to lock onto the flagpole, ignoring background objects, and provides the distance to the flag. The device will vibrate slightly when the flag is successfully locked.

Ansøgninger

Figur 7: Alsidige anvendelser. The rangefinder is depicted in use for golfing, hunting, general outdoor measurements, and shooting activities.

The MLR01 rangefinder is versatile and can be used in various professional and recreational settings, including:

• Golf
• Jagt
• Bue og Pil
• Outdoor Measurement
• Skydning

Opretholdelse

Korrekt vedligeholdelse sikrer din afstandsmålers levetid og nøjagtighed.

• Rensning: Use the provided cleaning cloth to gently wipe the lenses and body of the device. Do not use abrasive materials or chemical cleaners.
• Opbevaring: Store the rangefinder in its durable carrying case when not in use to protect it from dust, moisture, and physical damage. Store in a cool, dry place.
• Batteripleje: Genoplad batteriet regelmæssigt, selvom det ikke bruges ofte, for at opretholde batteriets tilstand. Undgå at aflade batteriet helt i længere perioder.
• Vandtæthed: The device has an IP54 water-resistant rating, meaning it is protected from splashing water. Do not submerge the device in water.

Fejlfinding

Specifikationer

Figur 8: Produktmål. The image provides the physical dimensions of the rangefinder for reference.

Garanti og support

The ENGiNDOT MLR01 Golf Rangefinder comes with a 24-month warranty from the date of purchase. This warranty covers manufacturing defects and malfunctions under normal use.

For technical support, warranty claims, or any inquiries regarding your product, please contact ENGiNDOT customer service through the retailer where the product was purchased or visit the official ENGiNDOT webwebsted for kontaktoplysninger.

Vigtig: Do not attempt to disassemble or repair the device yourself, as this will void the warranty and may cause damage or injury.
