LinkedSparx LS-S420-2A

LinkedSparx LS-S420-2A 420LED 110 fods app-styrede flerfarvede lyskæder brugermanual

1. Introduktion

This manual provides essential instructions for the safe and effective use of your LinkedSparx LS-S420-2A 420LED 110ft App-Controlled Multicolor String Lights. Please read this guide thoroughly before installation and operation to ensure optimal performance and longevity of your product.

2. Pakkens indhold

  • 1 x LED String Lights with Controller
  • 1 x strømadapter
  • 1 x brugermanual
LinkedSparx 420LED String Lights product box, controller, power adapter, and coiled string lights.
Figure 1: Contents of the LinkedSparx String Lights package, including the coiled lights, controller, and power adapter.

3. Sikkerhedsoplysninger

  • Dette produkt er kun designet til indendørs brug.
  • Do not expose the lights or power adapter to water or moisture.
  • Sørg for, at strømadapteren er tilsluttet en kompatibel stikkontakt.
  • Do not attempt to modify or repair the product. Contact customer support if assistance is needed.
  • Opbevares utilgængeligt for børn og kæledyr.
  • Unplug the lights from the power source when not in use or before cleaning.

4. Opsætning

  1. Pak lysene ud: Carefully remove the LED string lights, controller, and power adapter from the packaging.
  2. Tilslut strøm: Connect the LED string lights to the controller, and then connect the controller to the power adapter. Plug the power adapter into a standard electrical outlet.
  3. Installer appen: Download and install the free 'LinkedSparx' App on your mobile device. The app is available on both the App Store and Google Play.
  4. Aktiver Bluetooth: Ensure Bluetooth is enabled on your mobile device. The lights connect directly via Bluetooth without requiring manual pairing.
  5. Placer lysene: Arrange the 110ft (33.5m) string lights as desired for your indoor decoration.
Technical diagram illustrating the dimensions of the 110ft LinkedSparx LED String Lights, including lead wire and LED spacing.
Figure 2: Diagram showing the total length (121.4ft/37m), lighted length (110ft/33.5m), lead wire (8.2ft/2.5m), LED spacing (0.26ft/8cm), and 30V adapter output voltage.
Video 1: A demonstration of unpacking and setting up the LinkedSparx LED String Lights, showing the ease of installation and initial power-on.

5. Betjeningsvejledning

5.1 App kontrol

The LinkedSparx App provides full control over your string lights. Once the app is installed and Bluetooth is active, open the app to automatically detect and connect to your lights. No manual pairing is required.

  • Select Effects: Choose from 10 dynamic lighting effects and 5 music modes.
  • Tilpas farver: Access RGB 16 million colors to edit and create custom color schemes.
  • Juster indstillinger: Modify brightness and speed of effects.
  • Strømstyring: Switch the lights on or off directly from the app.
  • Flere sæt: Control multiple sets of LinkedSparx lights simultaneously through the app after a one-on-one pairing procedure.
LinkedSparx app interface on a smartphone demonstrating app control without pairing.
Figure 3: The LinkedSparx app interface, highlighting the 'No Pairing Needed' feature for easy connection.
LinkedSparx app displaying various lighting effects for string lights on a Christmas tree and table.
Figure 4: The app's effects gallery, allowing users to select and play various lighting patterns on their string lights.
LinkedSparx app features including 16 million colors, brightness/speed adjustment, and timer function.
Figure 5: App features for customization, including 16 million RGB colors, brightness and speed adjustments, and a timer function.
Video 2: En videovisningasing the smart features of LinkedSparx LED Christmas Lights, including various app-controlled effects and customization options.

5.2 Music Sync Modes

The built-in microphone on the controller allows your lights to synchronize with music. There are 5 music modes available, and the microphone sensitivity can be adjusted to 3 levels via the app. No additional music dongle is required.

Christmas tree with lights syncing to music, showing speakers and musical notes.
Figure 6: Illustration of the music sync feature, where lights dance to the rhythm of music detected by the built-in microphone.
Video 3: A demonstration of the 5 music modes available with the LinkedSparx LED String Lights, showing how they react to sound.

5.3 Timer funktion

Utilize the app to set a timer for your lights. You can schedule specific on/off times, allowing for automated operation daily or on selected days.

Multiple lighting effects and music modes of LinkedSparx LED String Lights on Christmas trees and a dining table.
Figure 7: Various lighting effects and music modes, including options for setting timers, displayed in a festive setting.

6. Vedligeholdelse

  • Rensning: Gently wipe the lights with a soft, dry cloth. Do not use liquid cleaners or immerse in water.
  • Opbevaring: When not in use, store the lights in their original packaging or a protective container in a cool, dry place. Avoid tangling the wires.
  • Inspektion: Periodically inspect the lights and power adapter for any signs of damage. Discontinue use if any damage is found.

7. Fejlfinding

ProblemMulig årsagLøsning
Lysene tænder ikke.No power, loose connection, app issue.Check power adapter connection. Ensure outlet is functional. Verify app is connected and lights are switched on in the app.
Appen kan ikke oprette forbindelse til lysene.Bluetooth off, lights out of range, app glitch.Ensure Bluetooth is enabled on your device. Move closer to the lights (within 10 meters). Restart the app or your phone.
Music sync not working effectively.Microphone sensitivity, ambient noise.Adjust microphone sensitivity in the app. Ensure the controller's microphone is not obstructed and is close to the music source.
Lights display incorrect colors/effects.App-indstillinger.Verify the selected effect and color settings within the LinkedSparx app.

8. Specifikationer

FeatureDetalje
MærkeLinkedSparx
ModelnummerLS-S420-2A
Antal lysdioder420
Varelængde110 fod (33.5 meter)
FarveMulticolor + White (RGB 16 Million Colors)
Indendørs/Udendørs brugIndendørs
Særlige funktionerColor change, adjustable brightness/speed, timer, music sync
LyskildetypeLED
StrømkildeDC
Voltage30 volt
Wattage30 watt
KontrolmetodeApp-kontrol (Bluetooth)
MaterialePlast
Varens vægt2.34 pund

9. Garanti og support

LinkedSparx products are designed for quality and reliability. For warranty information or technical support, please refer to the contact details provided on the product packaging or visit the official LinkedSparx webwebsted. Gem din købskvittering for garantikrav.
