1. Introduktion
This manual provides essential information for the safe and effective use of ELBA AIRCOMP-D ISO VG 150 Synthetic Air Compressor Oil. The ELBA AIRCOMP-D Series is formulated from highly refined hydrocracked base stocks and a unique additive technology, SYNTHOLATE, designed to inhibit varnish and carbon formation, ensuring superior thermal and oxidative stability. This product is engineered to extend equipment life and reduce operational costs compared to conventional mineral oils.
Image 1.1: ELBA AIRCOMP-D 1 Gallon container, showcasing product labeling and safety information.
Image 1.2: ELBA AIRCOMP-D oil available in different container sizes, highlighting its 'Made in USA' origin.
2. Sikkerhedsoplysninger
Always read and understand the Safety Data Sheet (SDS) for this product before use. Observe all local, state, and federal regulations regarding handling, storage, and disposal of lubricants.
2.1. Førstehjælpsforanstaltninger
- Indtagelse: Clean mouth with water and drink afterwards plenty of water. Do not induce vomiting. Consult a physician if symptoms persist.
- Øjenkontakt: Immediately flush eyes with plenty of water for at least 15 minutes, removing any contact lenses and continuing flushing. Consult a physician if irritation persists.
- Hudkontakt: Wash off immediately with soap and plenty of water. Remove and wash contaminated clothing before reuse. Consult a physician if irritation persists.
- Indånding: Move to fresh air in case of accidental inhalation of fumes from overheating or misting. Consult a physician if symptoms persist.
2.2. Forsigtighed
- Generelle foranstaltninger: Keep containers tightly closed in a dry, cool, and well-ventilated place. Keep product away from sunlight.
- Opbevaring og håndtering: Store in original container. Keep containers tightly closed in a dry, cool, and well-ventilated place. Keep product away from sunlight.
- Bortskaffelse: Dispose of in accordance with all applicable local, state, and D.O.T. regulations. Consult SDS for more information.
3. Produktfordele
ELBA AIRCOMP-D ISO VG 150 Synthetic Air Compressor Oil offers several advantages for air compressor systems:
- Reduced Lubricant Consumption: Extended drain intervals and lower vapor pressures contribute to reduced lubricant consumption.
- Reduceret vedligeholdelse: SYNTHOLATE technology minimizes carbon and varnish formation, extending valve life and increasing the time between overhauls.
- Eliminates Recompression: SYNTHOLATE maintains clean valves, preventing the primary cause of recompression.
- Reduceret strømforbrug: The elimination of recompression and a reduced coefficient of friction lead to lower power consumption per unit of compression.
- Forbedret sikkerhed: Higher flash points provide an enhanced margin of safety in air compression applications.
Image 3.1: Visual representation of key benefits including reduced lubricant consumption, elimination of recompression, improved safety, and reduced power consumption.
4. Anvendelse og brug
ELBA AIRCOMP-D ISO VG 150 is specifically designed for use in various types of air compressors requiring an ISO VG 150 synthetic lubricant. Always refer to your compressor manufacturer's manual for specific lubricant requirements and change intervals.
4.1. Generelle retningslinjer
- Ensure the compressor system is clean and free from contaminants before introducing new oil.
- Drain old oil completely according to manufacturer's instructions.
- Fill the compressor reservoir with ELBA AIRCOMP-D ISO VG 150 to the recommended level.
- Monitor oil levels regularly and top up as needed.
- Adhere to the recommended oil change schedule to maximize performance and extend equipment life.
Image 4.1: A visual guide emphasizing the importance of selecting the correct oil for air compressors, featuring multiple compressor units.
Billede 4.2: En intern view of a compressor mechanism, illustrating the components that benefit from proper lubrication.
5. Produktspecifikationer
The following table outlines the typical inspection results and general specifications for ELBA AIRCOMP-D ISO VG 150 oil.
Image 5.1: Detailed inspection results and product characteristics for ELBA AIRCOMP-D oil, including viscosity, pour point, and flash point.
| Attribut | Værdi |
|---|---|
| Mærke | ELBA |
| Modelnummer | ELBACOMP (AIRCOMP-D Series) |
| Materiale | Syntetisk |
| Liquid Volume (1 Gallon Case of 6) | 6 Gallons total |
| Item Weight (1 Gallon Case of 6) | 40 pund |
| Pakkeoplysninger | Flaske |
| Fabrikant | Elbalubes |
| Første ledige dato | 23. december 2020 |
Image 5.2: Promotional banner for ELBA AIRCOMP D Series Air Compressor Oil, featuring a 5-gallon pail.
6. Opbevaring og bortskaffelse
6.1. Opbevaring
Store ELBA AIRCOMP-D oil in its original, tightly sealed containers in a cool, dry, and well-ventilated area. Protect from direct sunlight and extreme temperatures. Keep away from incompatible materials.
6.2. Bortskaffelse
Dispose of used oil and empty containers in accordance with all applicable local, state, and federal environmental regulations. Do not discharge into drains, soil, or watercourses. Consult your local waste management authority for proper disposal methods.
7. Support og kontaktoplysninger
For further assistance, technical inquiries, or to obtain a Safety Data Sheet (SDS), please contact Elbalubes.
- Fabrikant: Elbalubes
- Webwebsted: www.elba-lubes.com
- Telefon: 1631-739-1814
Dette produkt er fra et lille virksomhedsmærke. Din støtte er værdsat.
