Brugsanvisning til Waterdrop King Tank-serien WD-TK-S 2.25G tyngdekraftsdrevet vandfiltersystem i rustfrit stål

1. Introduktion

This manual provides comprehensive instructions for the assembly, operation, and maintenance of your Waterdrop King Tank Series WD-TK-S 2.25G Gravity-Fed Stainless Steel Water Filter System. Please read these instructions carefully before use to ensure proper function and longevity of your product.

Figure 1: Waterdrop King Tank Series WD-TK-S Water Filter System.

2. Vigtige sikkerhedsoplysninger

• Use only with potable water. Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
• Sørg for, at alle forbindelser er sikre for at forhindre lækager.
• Do not expose the system to freezing temperatures. Freezing can damage the filters and housing.
• Keep the system clean and free from contaminants.
• Replace filters according to the recommended schedule to maintain optimal performance.
• The system is gravity-fed and requires no electricity.

3. Delliste

Før montering skal det kontrolleres, at alle komponenter er til stede og ubeskadigede.

• Låg med knap
• Upper Chamber (2.25 Gallon capacity)
• Lower Chamber (2.25 Gallon capacity)
• Black Carbon Filters (2 included)
• Sight Glass Spigot
• Stå
• Wrench (for spigot/filter installation)
• Priming Washer

Figure 2: Components of the Waterdrop King Tank Series WD-TK-S.

4. Opsætning og installation

Follow these steps to assemble your Waterdrop King Tank Series water filter system.

4.1. Lid Knob Assembly

1. Insert the knob screw and washer through the lid.
2. Fasten it securely with the knob.

4.2. Spigot Assembly

1. Unscrew the hex nut from the spigot.
2. Insert the spigot through the hole on the side of the lower chamber.
3. Tighten it securely and ensure the spigot is in an upright position. Use the provided wrench if necessary.

4.3. Filter Flushing

Before installing, flush the black carbon filters:

1. Hold the filter base in your hand.
2. Screw down the wing nut, keeping the flat side upward.
3. Screw it until the height of the priming washer can be attached.
4. Press the priming washer onto the spigot and align it with the water outlet.
5. Turn on the cold water outlet to flush the filter for 60 seconds.

4.4. Filters Installation

After flushing, install the filters into the upper chamber:

1. Remove the wing nut and filter washer from the black carbon filter's threaded rod.
2. Insert the black carbon filter's threaded rod into the holes in the upper chamber, ensuring the filter enters into the same chamber.
3. Gently thread the black carbon filter washer and wing nut onto the threaded rod, just below the upper chamber.
4. Tighten securely manually with your hand.

4.5. Slutsamling

1. Place the upper chamber onto the lower chamber, ensuring the filters are properly seated.
2. Place the entire water filter system onto the provided stand.
3. Læg låget på toppen af ​​det øverste kammer.

4.6. Installationsvideoguide

For a visual guide on the installation process, please refer to the official Waterdrop installation video:

5. Betjening

Using your Waterdrop King Tank Series water filter system is straightforward:

1. Filling the Upper Chamber: Pour potable water into the upper chamber. The water will gravity-feed through the filters into the lower chamber.
2. Initial Discard: For the first fill, once the lower chamber is full, discard the filtered water. This helps remove any manufacturing dust or loose carbon particles.
3. Dispensering af vand: Use the spigot on the lower chamber to dispense filtered water. The visible water level spigot allows you to monitor the water level in real-time.
4. Genopfyldning: Refill the upper chamber as needed. Avoid overfilling the upper chamber if the lower chamber is already full to prevent overflow.

Figure 3: Innovative Water Level Spigot Design for easy monitoring.

6. Vedligeholdelse

Regular maintenance ensures the best performance and longevity of your water filter system.

6.1. Udskiftning af filter

• The two black carbon filters have a lifespan of up to 6,000 gallons of water.
• Replace filters when water flow significantly slows down or after the recommended gallon capacity is reached, whichever comes first.
• To replace, follow the "Filters Installation" steps in reverse to remove old filters, then flush and install new ones.

6.2. Rengøring af systemet

• Clean the stainless steel chambers periodically with mild soap and water. Rinse thoroughly.
• Brug ikke slibende rengøringsmidler eller skuresvampe, da disse kan beskadige den rustfri ståloverflade.
• Ensure the spigot is also cleaned to prevent mineral buildup.

7. Fejlfinding

8. Specifikationer

Figure 4: NSF/ANSI Certifications for Waterdrop King Tank Series.

Figur 5: 5-Stage Fine Filtration for improved taste and reduction of contaminants.

8.1. Filtration Effectiveness Demonstration

Observe the effectiveness of the black carbon filters in removing impurities through a dye test:

9. Garanti og support

For warranty information, product support, or to purchase replacement filters, please visit the official Waterdrop webwebstedet eller kontakt kundeservice. Gem din købskvittering til garantikrav.

Kontaktoplysninger: Refer to the product packaging or official Waterdrop webhjemmeside for de mest opdaterede kontaktoplysninger.
