JENSEN JBS-215 Bluetooth Wall-Mountable Music System User Manual

1. Introduktion

The JENSEN JBS-215 is a versatile wall-mountable music system designed to provide audio entertainment through various sources. This system features Bluetooth connectivity for wireless audio streaming, a vertical-loading CD player compatible with MP3 CD and CD-R/RW discs, an FM digital tuner, and a USB port for charging devices. This manual provides detailed instructions for the proper setup, operation, and maintenance of your JBS-215 music system.

2. Sikkerhedsoplysninger

• Læs alle instruktioner, inden du betjener apparatet.
• Gem denne vejledning til fremtidig reference.
• Udsæt ikke dette apparat for regn eller fugt.
• Bloker ikke nogen ventilationsåbninger.
• Sørg for, at netledningen ikke kommer i klemme eller går på.
• Tag stikket ud af apparatet under tordenvejr eller når det ikke bruges i længere perioder.
• Overlad al service til kvalificeret servicepersonale.

3. Pakkens indhold

• JENSEN JBS-215 Music System
• Instruktionsmanual
• Fjernbetjening
• AC Adapter (120-volt)
• Vejledning til vægmontering

4. Produktet er slutview

4.1 Foran View

The image below displays the front of the JBS-215 unit, highlighting its sleek design and integrated speakers. The central display shows the current time or function status.

4.2 Foran View med fjernbetjening

This image shows the JBS-215 music system from the front, accompanied by its remote control. The remote allows for convenient operation of all system functions from a distance.

4.3 Betjening af cd-afspilleren

The image illustrates the vertical-loading CD player in an open state, ready to accept a disc. The CD player supports standard audio CDs, CD-R/RW, and MP3 CD formats.

4.4 USB-opladningsport

Dette top-down view of the JBS-215 shows a smartphone connected to the USB port for charging. The USB port provides 1-amp charging capability for compatible devices.

4.5 Wall-Mounted Installation Example

En eksample of the JBS-215 music system mounted on a wall in a living room setting. This demonstrates the space-saving benefit of its wall-mountable design.

5. Opsætning

5.1 Strømtilslutning

1. Connect the supplied 120-volt AC adapter to the DC IN jack on the back of the unit.
2. Sæt AC-adapteren i en almindelig stikkontakt.

5.2 Vægmontering

The JBS-215 can be mounted on a wall to save space. Refer to the separate wall mounting instructions included in the package for detailed steps and hardware requirements. Ensure the mounting surface is sturdy and capable of supporting the unit's weight.

5.3 Montering af stativ

If not wall-mounting, attach the included stand to the bottom of the unit as per the diagrams in the wall mounting instructions. Place the unit on a stable, flat surface.

6. Betjeningsvejledning

6.1 Generel drift

• Tænd/sluk: Tryk på POWER-knappen for at tænde eller slukke for enheden.
• Lydstyrkekontrol: Use the VOLUME UP/DOWN buttons on the unit or remote to adjust the sound level.
• Valg af tilstand: Press the MODE button to switch between CD, Bluetooth, FM Radio, and AUX input.
• EQ-forudindstillinger: The unit features 5 equalizer presets. Press the EQ button to cycle through different sound profiles.

6.2 CD-afspiller

1. Tryk på MODE-knappen for at vælge CD-tilstand.
2. Tryk på OPEN/CLOSE-knappen for at åbne CD-skuffen.
3. Insert a CD (audio CD, CD-R/RW, or MP3 CD) with the label side facing forward.
4. Press the OPEN/CLOSE button to close the tray. The disc will begin playing automatically.
5. Use the SKIP/SEARCH buttons to navigate tracks and the PLAY/PAUSE button to control playback.

6.3 Bluetooth-forbindelse

1. Press the MODE button to select Bluetooth mode. The display will show "BT" and flash, indicating pairing mode.
2. Enable Bluetooth on your mobile device and search for "JBS-215".
3. Select "JBS-215" to pair. Once connected, the "BT" indicator will stop flashing.
4. You can now stream audio from your device to the JBS-215.

6.4 FM radio

1. Press the MODE button to select FM Radio mode.
2. Press the TUNE UP/DOWN buttons to manually tune to a station.
3. Press and hold the TUNE UP/DOWN buttons for automatic scanning to the next available station.
4. Lagring af forudindstillinger: To store a station, tune to the desired frequency, then press and hold the MEMORY button. Use the SKIP/SEARCH buttons to select a preset number, then press MEMORY again to confirm. The unit supports 20 FM presets.

6.5 USB -opladning

Connect your smartphone or other USB-powered device to the USB port on the unit using a compatible USB cable. The port provides 1-amp charging output.

6.6 Hjælpeindgang

Connect an external audio device (e.g., MP3 player, tablet) to the AUX IN jack on the unit using a 3.5mm audio cable. Press the MODE button to select AUX mode to play audio from the connected device.

6.7 Officiel produktvideo

Se denne officielle video for et visuelt overblikview of the JENSEN JBS-215 Bluetooth Wall Mountable Music System, demonstrating its features and functionality.

7. Vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre enhedens yderside. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
• CD-afspiller: Keep the CD tray clean and free of dust. Avoid touching the lens inside the CD compartment.
• Opbevaring: Hvis enheden opbevares i længere tid, skal den tages ud af stikkontakten og opbevares et køligt og tørt sted.

8. Fejlfinding

9. Specifikationer

• Model: JBS-215
• Strømudgang: 10 watts RMS (2 x 5 watts)
• Forbindelse: Bluetooth
• Lydkilder: Vertical-loading CD player (MP3 CD, CD-R/RW compatible), FM stereo radio (20 presets, PLL tuning), Aux input
• Højttalerdrivere: 3 tommer
• Frekvensrespons: 170 Hz til 20 kHz
• USB-port: 1-amp opladning
• Vise: Multi-function backlit LCD
• Dimensioner (L x B x H): 4.9 x 19.6 x 9.1 tommer
• Varens vægt: 4.94 pund
• Magt: 120 volt AC adapter

10. Garanti og support

For garantioplysninger og kundesupport henvises til garantikortet, der følger med dit produkt, eller besøg den officielle Jensen webwebsted. Gem din købskvittering for garantikrav.
