Tera D5100Y USB Wired 1D 2D QR Barcode Scanner User Manual

1. Introduktion

This manual provides detailed instructions for the proper use and maintenance of your Tera D5100Y USB Wired 1D 2D QR Barcode Scanner. Designed for efficiency and durability, this scanner offers fast and precise scanning for a wide range of barcode symbologies. Please read this manual thoroughly before operating the device to ensure optimal performance and longevity.

Image: The Tera D5100Y USB Wired 1D 2D QR Barcode Scanner, featuring its ergonomic design and USB cable.

2. Pakkens indhold

Når du åbner pakken, skal du kontrollere, at alle nedenstående varer er til stede og i god stand:

• Tera D5100Y Barcode Scanner (x1)
• USB-kabel (integreret)
• Brugervejledning (x1)

Image: A visual representation of the Tera D5100Y scanner, its USB cable, and the included user manual, as found in the product box.

3. Nøglefunktioner

• Ergonomisk design: The scanner features a curved, extended, and thickened handle, specifically designed for comfortable grip during prolonged use. The smooth, flat trigger enhances user experience.

Image: A hand comfortably holding the Tera D5100Y scanner, illustrating its ergonomic shape and trigger placement for ease of use.
• Forbedret holdbarhed: Equipped with an orange anti-shock silicone protective cover, the scanner is designed to withstand drops from up to 6.56 feet (2 meters). Its IP54 rating provides protection against dust and splashing water.


Image: The Tera D5100Y scanner shown in a simulated drop scenario, emphasizing its robust, shock-resistant construction.

• Plug and Play-tilslutning: The Tera D5100Y is a wired 2D barcode scanner that connects via a standard USB cable. No driver or software installation is required, allowing for immediate use upon connection.


Image: The Tera D5100Y scanner connected to a laptop via its USB cable, demonstrating its simple plug-and-play setup.

• Bred kompatibilitet: Compatible with Windows, Mac OS, Linux, iOS, and Android operating systems. It works seamlessly with common software applications such as Word, Excel, and Novell.
• Multi-sprog support: Supports approximately 25 languages, including English, Spanish, German, French, Italian, and Japanese. The factory default language is English. Ensure the scanner's language setting matches your computer's keyboard language for correct output.

Image: The Tera D5100Y scanner with flags of various countries, indicating its support for multiple languages.
• Versatile Scanning Capabilities: Decodes both printed and digital 1D, 2D, and QR barcode symbologies. This includes UPC-A, EAN-13, Code 128, QR Code, Data Matrix, PDF417, Aztec code, and Maxicode.


Image: The Tera D5100Y scanner actively scanning a QR code on a laptop screen, demonstrating its capability to read both digital and printed 1D/2D/QR codes.

4. Opsætning

1. Tilslut scanneren: Plug the USB cable of the Tera D5100Y scanner into an available USB port on your computer (Desktop or Laptop).
2. Systemgenkendelse: Your operating system (Windows, Mac OS, Linux, etc.) will automatically detect and install the necessary drivers. This process typically takes a few seconds.
3. Klar til brug: Once the system recognizes the device, the scanner is ready for immediate use. No additional software installation is required.

5. Betjeningsvejledning

5.1 Grundlæggende scanning

1. Ensure the scanner is connected to your computer.
2. Open an application where you want the scanned data to appear (e.g., Notepad, Word, Excel, a POS system).
3. Ret scannerens vindue mod den stregkode, du vil scanne.
4. Press and hold the trigger button. A red aiming line will appear.
5. Align the aiming line across the entire barcode. Once successfully scanned, the scanner will emit a beep (if enabled) and the data will appear in your active application.

5.2 Lydindstillinger

The scanner's beep sound can be adjusted. Refer to the full user manual (PDF) for specific configuration barcodes to turn the sound on or off.

Image: A visual guide illustrating how to enable or disable the scanner's beep sound, enhancing user control over auditory feedback.

5.3 Sprogindstillinger

To ensure correct character output, the scanner's language setting must match your computer's keyboard language. The default language is English. Consult the full user manual (PDF) for instructions on changing the scanner's language by scanning specific configuration barcodes.

Image: A graphic depicting a globe surrounded by various national flags, symbolizing the scanner's extensive multi-language support.

5.4 Data Editing (Prefix/Suffix)

The scanner supports adding prefixes or suffixes to scanned data, and hiding certain characters. These advanced settings are configured by scanning specific barcodes found in the comprehensive user manual (PDF).

Billede: Eksamples of barcodes with added prefixes, illustrating the scanner's capability to customize data output.

5.5 Upload Modes

The Tera D5100Y scanner supports two primary upload modes:

• Øjeblikkelig upload-tilstand: Scanned data is immediately transmitted to the connected device.
• Opbevaringstilstand: Scanned data is stored internally in the scanner's memory and can be uploaded later in a batch.

Configuration barcodes for switching between these modes are available in the full user manual (PDF).

Image: A diagram illustrating the two data upload modes: Instant Upload, where data is sent immediately, and Storage Mode, where data is saved for later batch transfer.

6. Vedligeholdelse

• Rensning: Brug en blød, tør klud til at rengøre scannerens yderside. Brug en fnugfri klud, der er let tørret af scanningsvinduet.ampened with a mild, non-abrasive cleaner. Avoid harsh chemicals or abrasive materials.
• Opbevaring: Opbevar scanneren et køligt, tørt sted væk fra direkte sollys og ekstreme temperaturer.
• Kabelpleje: Undgå at bøje eller vride USB-kablet for meget for at forhindre indvendig skade.

7. Fejlfinding

If you encounter issues with your Tera D5100Y scanner, please refer to the following common problems and solutions:

• Scanneren svarer ikke:
  • Ensure the USB cable is securely connected to both the scanner and the computer.
  • Try plugging the scanner into a different USB port.
  • Genstart din computer.
• Unable to Scan Barcodes:
  • Ensure the barcode is clean, undamaged, and clearly visible.
  • Juster afstanden og vinklen mellem scanneren og stregkoden.
  • Verify that the scanner is configured for the correct barcode symbology (refer to the PDF manual for configuration barcodes).
  • Check the scanner's decoding ability for challenging barcodes.


Image: A display of various barcode conditions, such as reflective, blurry, cracked, distorted, obscured, and colorful, demonstrating the scanner's advanced decoding capabilities.

• Incorrect Characters or Output:
  • Ensure the scanner's language setting matches your computer's keyboard language.
  • Verify that the cursor is in an active input field in your application.
  • If experiencing random character issues (e.g., lower case becoming upper case, numbers becoming symbols), this might indicate a firmware issue or an incorrect HID keyboard mode setting. Refer to the full PDF manual for factory reset options or alternative USB-COM mode configurations.
• No Beep Sound:
  • Check the sound settings as described in Section 5.2 or the PDF manual to ensure the beep is enabled.

For advanced troubleshooting or specific configuration settings, please refer to the comprehensive Tera D5100Y User Manual (PDF).

8. Specifikationer

9. Garanti og support

Tera products are manufactured to high-quality standards and are backed by a manufacturer's warranty. For specific warranty details, terms, and conditions, please refer to the documentation included with your product or visit the official Tera webwebsted.

For further assistance, technical support, or to download the complete user manual, please visit the official Tera support resources. The full user manual contains detailed configuration barcodes and advanced settings not covered in this condensed guide.

You can access the official PDF user manual here: Tera D5100Y User Manual (PDF)

10. Sikkerhedsoplysninger

• Do not expose the scanner to extreme temperatures, humidity, or corrosive substances.
• Avoid direct eye exposure to the scanner's light source.
• Do not attempt to disassemble or modify the scanner. This will void the warranty and could cause damage or injury.
• Hold enheden væk fra stærke magnetiske felter.
