Team Kalorik TKG SKV 1006 Cordless Stick Vacuum Cleaner User Manual

Indledning

Thank you for choosing the Team Kalorik TKG SKV 1006 Cordless Stick Vacuum Cleaner. This appliance is designed for versatile cleaning, functioning as both a powerful stick vacuum and a convenient handheld unit, with an integrated wet cleaning system. Please read this manual thoroughly before first use to ensure safe operation and optimal performance.

Sikkerhedsinstruktioner

Følg altid grundlæggende sikkerhedsforanstaltninger, når du bruger elektriske apparater, for at mindske risikoen for brand, elektrisk stød og personskade.

• Sørg for, at strømadapteren er kompatibel med din lokale strømforsyning.
• Nedsænk ikke motorenheden i vand eller andre væsker.
• Hold hår, løstsiddende tøj, fingre og alle dele af kroppen væk fra åbninger og bevægelige dele.
• Do not vacuum liquids, hot ashes, sharp objects, or flammable/combustible materials.
• Brug kun den opladeradapter, der følger med apparatet.
• Opbevar apparatet indendørs på et tørt sted.
• Dette apparat er kun til husholdningsbrug.

Produkt overview og komponenter

Familiarize yourself with the parts of your Team Kalorik TKG SKV 1006 vacuum cleaner.

Image: All components of the Team Kalorik TKG SKV 1006 vacuum cleaner. This includes the main motor unit, extension tube, floor brush with LED light, handheld nozzle, charging adapter, and a mop pad for wet cleaning.

1. Hovedmotorenhed: Contains the dustbin, motor, and battery. Functions as the handheld vacuum.
2. Forlængerrør: Connects the main unit to the floor brush for stick vacuum operation.
3. Floor Brush with LED Light: For general floor cleaning, features an integrated LED light to illuminate dust.
4. Handheld Nozzle/Crevice Tool: For precise cleaning in tight spaces.
5. Opladningsadapter: For recharging the appliance's battery.
6. Water Tank (Removable): For the wet cleaning function.
7. Moppepude: Attaches to the floor brush for wet cleaning.
8. Multi-filtration System: Located within the dustbin for efficient dust separation.
9. Drejehåndtag: Ergonomisk designet til komfortabel brug.
10. Opladningsindikatorlys: Viser batteristatus.

Opsætning

Forsamling

To assemble the stick vacuum:

1. Sæt forlængerrøret ind i hovedmotorenheden, indtil det klikker på plads.
2. Fastgør gulvbørsten til den anden ende af forlængerrøret, og sørg for, at den er sikkert fastgjort.
3. For handheld use, attach the handheld nozzle directly to the main motor unit.

Opladning af batteriet

Before first use, fully charge the appliance for approximately 4 hours.

• Connect the charging adapter to the charging port on the main motor unit.
• Sæt adapteren i en stikkontakt.
• The charge indicator light will illuminate during charging and change when fully charged.
• The appliance features an anti-tilt function, but for stable charging, ensure it is placed securely.

Betjeningsvejledning

Image: The Team Kalorik TKG SKV 1006 vacuum cleaner configured for handheld use, demonstrating its compact form.

Tør støvsugning

To begin dry vacuuming:

• Ensure the dustbin is empty and the filters are clean.
• Tryk på tænd/sluk-knappen for at tænde for støvsugeren.
• For stick vacuuming, use the assembled unit with the floor brush. The LED light on the brush will illuminate the cleaning path.
• For handheld vacuuming, detach the main unit and attach the handheld nozzle for targeted cleaning.
• The appliance offers approximately 30 minutes of runtime on a full charge.

Wet Cleaning System

To use the integrated wet cleaning function:

1. Fill the removable water tank with clean water. Do not use harsh chemicals or detergents that could damage the appliance or leave residue.
2. Attach the mop pad securely to the bottom of the floor brush.
3. Ensure the water tank is properly inserted into its designated slot.
4. Operate the vacuum as usual. The wet cleaning system will dispense water onto the mop pad for simultaneous vacuuming and mopping.
5. After use, empty and clean the water tank and mop pad.

Opretholdelse

Regelmæssig vedligeholdelse sikrer optimal ydeevne og forlænger din støvsugers levetid.

Tømning af skraldespanden

• The dustbin has a capacity of 0.5 liters. Empty it regularly, preferably after each use, to maintain suction power.
• Fjern støvbeholderen fra hovedenheden.
• Open the dustbin and dispose of the collected debris.

Rengøring af filtre

• The appliance features a multiple filtration system. Regularly remove and clean the filters.
• Tap filters gently to remove dust or rinse them with cold water if heavily soiled. Ensure filters are completely dry before reinserting.
• Do not use detergents or hot water on filters.

Rengøring af vandtanken og moppepuden

• After wet cleaning, empty any remaining water from the tank and rinse it thoroughly.
• Remove the mop pad and wash it, either by hand or machine, according to its care instructions.

Rengøring af gulvbørsten

• Periodically check the floor brush for tangled hair or debris. Remove any obstructions to ensure smooth operation.

Fejlfinding

Specifikationer

• Model: TKG SKV 1006
• Magt: 90 watt
• Voltage: 230 volt
• Batteri: Li-Ion 2200 mAh
• Opladningstid: Cirka 4 timer
• Kørselstid: Op til 30 minutter
• Skraldespand Kapacitet: 0.5 liter
• Støjniveau: > 68 dB
• Dimensioner (L x B x H): 24 x 19 x 116 cm
• Vægt: 2.55 kilo
• Særlige funktioner: Integrated handheld vacuum, wet cleaning system, multiple filtration, rotary handle, floor brush with LED light, anti-tilt function.

Garanti og support

For warranty information and customer support, please refer to the warranty card included with your purchase or contact your retailer. Keep your proof of purchase for any warranty claims.
