Indledning
The TrustFire MC12 is a versatile and powerful LED headlamp designed for various outdoor and indoor activities. It features multiple light modes, a magnetic tail cap, and a detachable pocket clip, making it adaptable for use as a headlamp, handheld flashlight, or work light. Its robust, waterproof design ensures reliable performance in diverse conditions.
Image: The TrustFire MC12 headlamp shown with its headband, magnetic charging cable, and pocket clip.
Pakkens indhold
- TrustFire MC12 Forlygteamp
- Pandebånd
- Genopladeligt batteri (16340)
- Magnetisk USB-opladerkabel
- Pocket Clip
- Brugermanual
- Reserve O-ringe
Image: All items included in the TrustFire MC12 package, including the headlamp, battery, charging cable, headband, and manual.
Opsætning
1. Batteriinstallation
- Skru bagkappen af forlygtenamp.
- Remove the protective plastic disc from the battery's positive terminal (if present).
- Insert the included 16340 rechargeable battery with the positive (+) end facing towards the head of the lamp.
- Skru endehætten godt på igen for at sikre korrekt kontakt og vandtæthed.
2. Opladning af batteriet
The MC12 uses a magnetic USB charging cable for convenient recharging.
- Connect the USB end of the charging cable to a USB power source (e.g., computer, wall adapter).
- Attach the magnetic end of the cable to the charging port on the tail cap of the headlamp.
- The indicator light on the charging cable will show the charging status:
- Rød: Opladning i gang.
- Grøn: Opladning færdig.
- Alternating Red-Green (if not connected to lamp): Cable is ready.
- Frakobl kablet, når opladningen er fuldført.
Important: The charging cable should only be connected to power during the charging process. Disconnect it when not in use to prevent potential short circuits if the magnetic end comes into contact with metal objects.
3. Fastgørelse af pandebåndet
To use the MC12 as a headlamp:
- Skub hovedetamp into the silicone mount on the headband.
- Adjust the elastic straps for a comfortable and secure fit on your head.
Image: The TrustFire MC12 headlamp attached to its adjustable headband, ready for use.
Betjeningsvejledning
Tænd/sluk
- At tænde: Tryk på sidekontakten, og hold den nede i cirka 0.5 sekunder.
- At slukke: Tryk på sidekontakten, og hold den nede i cirka 0.5 sekunder.
Ændring af lysstyrketilstande
Når hovedlamp is on, short press the side switch to cycle through the brightness modes:
Moonlight → Low → Medium → High
Image: Visual representation of the five lighting modes: High, Medium, Low, Moonlight, and Strobe.
Special Modes (Strobe)
- To Activate Strobe: Double-click the side switch rapidly from any mode (on or off).
- To Exit Strobe: Short press the side switch to return to the previously used brightness mode.
Batteriniveauindikator
Når hovedlamp is off, short press the side switch to check the battery level. The indicator light on the switch will illuminate:
- Grøn: Battery is full (70-100%).
- Gul: Battery is medium (30-70%).
- Rød: Battery is low (less than 30%).
- Blinker rødt: Battery is critically low (less than 10%), recharge immediately.
Alsidig brug
The MC12 is designed for multiple applications:
- Headlamp: Use with the included headband for hands-free illumination during camping, jogging, hiking, or repair work. The lamp head can be rotated 180 degrees to direct light precisely where needed.
Image: A person running outdoors at dusk, demonstrating the 180-degree adjustable head of the MC12 headlamp.
- Håndholdt lommelygte: Detach from the headband and use as a compact, powerful flashlight.
- Magnetic Work Light: The flat magnetic tail cap allows the headlamp to be securely attached to ferrous metal surfaces, providing hands-free lighting for tasks like vehicle maintenance or workshop activities.
Image: A mechanic working under a car hood, with the MC12 headlamp magnetically attached to the hood for hands-free illumination.
- Clip-on Light: Use the removable pocket clip to attach the light to clothing, backpacks, or baseball caps for convenient carrying and directional lighting.
Image: A person with the MC12 headlamp clipped to their jacket pocket, demonstrating its use as a portable clip-on light.
Opretholdelse
- Rensning: Tør hovedet afamp med en blød, damp klæde. Brug ikke slibende rengøringsmidler eller opløsningsmidler.
- O-ringe: Undersøg O-ringene regelmæssigt for slitage. Smør dem med silikonefedt for at bevare vandtætheden. Udskift dem, hvis de er beskadiget.
- Batteripleje:
- Recharge the battery regularly, especially if not used for extended periods, to prolong its lifespan.
- Opbevar hovedlamp with a partially charged battery in a cool, dry place if storing for a long time.
- If the battery is critically low (flashing red indicator), recharge it as soon as possible.
- Vandtæthed: The MC12 is IPX8 waterproof, meaning it can be submerged up to 2 meters for 30 minutes. Ensure the tail cap is tightly screwed on before exposing it to water.
Image: Two individuals outdoors in snowy and rainy conditions, demonstrating the IPX8 waterproof capability of the TrustFire MC12 headlamp.
Fejlfinding
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Headlamp tændes ikke. |
|
|
| Lysudgangen er svag eller flimrer. |
|
|
| Headlamp gets warm on High mode. | Normal operation for high lumen output. | This is normal. The lamp has an intelligent temperature control system to prevent overheating. If it becomes too hot, it will automatically reduce brightness. |
| Magnetic charging cable not charging. |
|
|
Specifikationer
| Model | MC12 |
| Mærke | TrustFire |
| Lyskilde | LED |
| Max output | 1000 lumen |
| Dimensioner | 4 x 13 x 18 cm |
| Vægt | 130 gram |
| Vandtæt vurdering | IPX8 (op til 2 meter i 30 minutter) |
| Strømkilde | Battery Powered (16340 rechargeable battery included) |
| Særlige funktioner | Rechargeable, Adjustable Light Modes, Magnetic Tail Cap, Detachable Clip, 180° Adjustable Head, Intelligent Temperature Control System. |
Performance Data (Approximate)
- Høj tilstand: 1000 Lumens / 65 minutes runtime / 105m beam distance
- Medium tilstand: 200 Lumens / 160 minutes runtime / 46m beam distance
- Lav tilstand: 60 Lumens / 520 minutes runtime / 25m beam distance
- Måneskinstilstand: 3 Lumens / 160 hours runtime / 1.5m beam distance
Garanti og support
TrustFire products typically come with a warranty. Please refer to the warranty card included in your package or visit the official TrustFire webwebsted for detaljerede garantioplysninger og vilkår.
For technical support, product inquiries, or warranty claims, please contact TrustFire customer service through their official channels or the retailer where you purchased the product.
Genbrugsoplysninger: Please dispose of batteries and electronic components responsibly according to local regulations. Do not dispose of batteries in household waste.
Bortskaffelse af ødelagt eller beskadiget Lamps: Handle with care and dispose of according to local hazardous waste guidelines.
