1. Introduktion
Thank you for choosing the SoBuy KMB24-Wx2 Children's Armchair Set. This manual provides essential information for the safe assembly, operation, and maintenance of your new children's chairs. Please read these instructions carefully before assembly and retain them for future reference.
Image 1.1: The SoBuy KMB24-Wx2 Children's Armchair Set. This image displays the complete set of two SoBuy KMB24-Wx2 children's armchairs, showcasing their design with white seats and backrests, and natural birch wood frames.
2. Sikkerhedsoplysninger
To ensure the safety of your child and the longevity of the product, please observe the following:
- Voksenopsyn: Always supervise children when they are using the chairs.
- Vægtgrænse: Do not exceed the maximum load capacity of 75 kg (165 lbs) per chair.
- Korrekt samling: Ensure all parts are correctly assembled and fasteners are tightened securely before use. Periodically check all connections.
- Stabil overflade: Place the chairs on a flat, stable surface to prevent tipping.
- Undgå klatring: Instruct children not to climb on the chairs or armrests.
- Hold dig væk fra varme: Do not place the chairs near heat sources or open flames.
- Ingen ændringer: Do not modify the product in any way, as this may compromise its safety and void the warranty.
3. Pakkens indhold
Før monteringen påbegyndes, skal du kontrollere, at alle komponenter er til stede og ubeskadigede. Hvis der mangler eller er beskadigede dele, bedes du kontakte kundesupport.
- 2 x Chair Backrests (White)
- 2 x Chair Seats (White)
- 4 x Chair Legs (Birch Wood)
- 4 x Armrests (Birch Wood)
- 2 x Base Frames (Birch Wood)
- Hardware Pack (Screws, bolts, Allen key)
- Assembly Instructions (Illustrated)
4. Monteringsvejledning
Assembly typically requires one adult. Follow the numbered steps and refer to the illustrations provided in your package. An Allen key is usually included.
- Udpak komponenter: Carefully remove all parts from the packaging and lay them out on a soft, clean surface to prevent scratches. Identify all components against the package contents list.
- Attach Base Frame: Secure the two birch wood base frames to the underside of each white seat using the provided screws. Ensure they are aligned correctly.
- Installer ben: Attach the four birch wood legs to the base frame of each chair. The legs have pre-drilled holes for seat height adjustment. For initial assembly, choose the desired height level and align the holes. Secure with bolts and nuts. Do not fully tighten yet.
- Fastgør ryglæn: Connect the white backrest to the rear of the seat and the upper part of the rear legs. Use the appropriate screws and ensure the curved part faces upwards for ergonomic support.
- Fastgør armlæn: Secure the birch wood armrests to the sides of the backrest and the front legs. Ensure they are firmly attached.
- Endelig stramning: Once all components are in place, carefully tighten all screws and bolts using the Allen key. Do not overtighten.
- Stabilitetstjek: Gently shake the assembled chair to ensure it is stable and all connections are secure.
Image 4.1: Armchair with Dimensions. A single SoBuy KMB24-Wx2 children's armchair is shown with its overall dimensions indicated: 40cm in width, 32cm in depth, and 53cm in height. This helps in understanding the chair's footprint and assembly orientation.
Billede 4.2: Side View with Adjustment Holes. This image provides a side view of the armchair, highlighting the pre-drilled holes on the chair legs. These holes are crucial for adjusting the seat height during assembly and later use.
5. Operating Instructions: Adjustable Seat Height
The SoBuy KMB24-Wx2 armchairs feature an adjustable seat height to accommodate your child as they grow. The seat height can be set at 23cm, 27cm, 31cm, or 35cm from the floor.
- Empty the Chair: Ensure no one is sitting on the chair before attempting to adjust the height.
- Løsn fastgørelseselementerne: Using the provided Allen key, carefully loosen the bolts that secure the seat to the legs. You do not need to remove them completely, just enough to allow movement.
- Juster højden: Gently lift or lower the seat to align with the desired set of holes on the chair legs. Ensure all four legs are aligned to the same height setting.
- Sikre fastgørelsesanordninger: Once the seat is at the desired height, re-tighten all bolts firmly.
- Bekræft stabilitet: Check that the chair is stable and all connections are secure after adjustment.
Image 5.1: Seat and Armrest Detail. A detailed view of the armchair's seat and one armrest, illustrating the smooth, rounded edges and the connection points for adjustment.
6. Vedligeholdelse og pleje
Regular maintenance will help preserve the appearance and functionality of your SoBuy children's armchairs.
- Rensning: Tør overflader af med en blød, damp cloth. For stubborn marks, use a mild soap solution, then wipe dry immediately. Avoid abrasive cleaners or harsh chemicals.
- Inspektion: Kontrollér regelmæssigt alle skruer og bolte for at sikre, at de forbliver stramme. Spænd dem igen om nødvendigt.
- Undgå direkte sollys: Prolonged exposure to direct sunlight may cause the wood to fade or dry out.
- Fugtkontrol: Maintain a stable room temperature and humidity to prevent wood warping or cracking.
7. Fejlfinding
If you encounter any issues with your SoBuy KMB24-Wx2 armchairs, please refer to the table below for common problems and solutions.
| Problem | Mulig årsag | Løsning |
|---|---|---|
| Stolen er vaklende | Løse fastgørelseselementer; ujævnt gulv. | Check and tighten all screws and bolts. Ensure the chair is on a flat surface. |
| Vanskeligheder med at justere sædehøjden | Bolts not sufficiently loosened; misalignment of holes. | Ensure bolts are loose enough. Align all four legs to the same height setting simultaneously. |
| Ridser på overflader | Rough handling; sharp objects. | Use furniture polish or touch-up paint for minor scratches. Prevent future damage by avoiding sharp objects. |
8. Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | Så Køb |
| Modelnummer | KMB24-Wx2 |
| Farve | Hvid |
| Materiale | Birketræ |
| Produktmål (L x B x H) | 40 x 32 x 53 cm (15.7 x 12.6 x 20.9 tommer) |
| Justerbar sædehøjde | 23cm, 27cm, 31cm, 35cm (9.1, 10.6, 12.2, 13.8 inches) |
| Varens vægt | 6.69 kg (14.75 lbs) per chair |
| Maksimal belastningskapacitet | 75 kg (165 lbs) |
| Speciel funktion | Stabil konstruktion |
| Antal enheder | 2.0 I alt |
9. Garanti og support
SoBuy products are designed for quality and durability. For information regarding product warranty, returns, or specific assembly assistance, please refer to the purchase platform or contact SoBuy customer service directly.
- Monteringshjælp: All SoBuy furniture includes numbered parts and illustrated instructions for straightforward assembly.
- Returnerer: If you are not satisfied with the product or if there is an issue, you may be eligible for a free return. Please consult the retailer's return policy.
- Contact SoBuy: For further inquiries or support, please visit the official SoBuy store or contact their customer service department.
