Brugermanual til 360 S9 robotstøvsuger og moppe

Vigtige sikkerhedsinstruktioner

Please read this manual carefully before using the 360 S9 Robot Vacuum and Mop and retain it for future reference. Follow all safety precautions to prevent injury or damage.

• Dette apparat kan bruges af børn i alderen 8 år og derover og personer med nedsatte fysiske, sensoriske eller mentale evner eller mangel på erfaring og viden, hvis de har fået opsyn eller instruktion i brugen af ​​apparatet på en sikker måde og forstår de involverede farer. .
• Børn skal være under opsyn for at sikre, at de ikke leger med apparatet.
• Rengøring og brugervedligeholdelse må ikke udføres af børn uden opsyn.
• Only use the original power adapter provided by the manufacturer.
• Brug ikke robotten i omgivelser med åben ild eller skrøbelige genstande.
• Ensure the robot operates on a stable surface and avoid dropping it.
• Hold hår, løstsiddende tøj, fingre og alle dele af kroppen væk fra åbninger og bevægelige dele.

Produkt overview

The 360 S9 Robot Vacuum and Mop is an intelligent cleaning device designed to efficiently vacuum and mop your floors. It features advanced LiDAR navigation, powerful suction, and smart app control for a customized cleaning experience.

Image: The 360 S9 Robot Vacuum and Mop, a white circular device, is shown alongside a smartphone displaying its control application. The robot features a central LiDAR sensor and two control buttons on its top surface.

Pakkens indhold

Bekræft at alle komponenter er til stede i pakken:

• 360 S9 Robot Vacuum and Mop
• Opladningsdock
• Strømadapter
• Hovedbørste
• Sidebørster (2 par)
• Højeffektivt filter
• Vandtank
• Moppeklude (2)
• Rengøringsværktøj
• Brugermanual

Billede: Et overheadbillede view displaying the 360 S9 Robot Vacuum and its various accessories, including the main unit, a rectangular filter, two pairs of side brushes, a main roller brush, and the charging dock.

Opsætning

1. Udpakning og placering

• Fjern al emballage og beskyttelsesfilm fra robotten og opladningsdokken.
• Place the charging dock against a wall on a hard, level surface. Ensure there is at least 0.5 meters (1.6 feet) of clear space on both sides and 1.5 meters (4.9 feet) in front of the dock.
• Tilslut strømadapteren til ladestationen, og sæt den i en stikkontakt.

2. Opladning af robotten

• Place the robot onto the charging dock, ensuring the charging contacts align. The robot will announce that it is charging.
• For first-time use, fully charge the robot before operation (approximately 4-5 hours).

3. Appinstallation og forbindelse

• Download the '360Robot' app from your mobile device's app store (Google Play Store or Apple App Store).
• Open the app and follow the on-screen instructions to create an account and add your 360 S9 robot.
• Ensure your mobile device is connected to a 2.4 GHz Wi-Fi network during the initial setup process, as the robot only supports 2.4 GHz Wi-Fi.
• Once connected, the robot will perform an initial mapping run to create a layout of your home. This map is crucial for advanced features like no-go zones and selective room cleaning.

Image: A hand holds a smartphone displaying the 360 Robot app interface, which shows a floor plan map, cleaning status, and control options for the robot vacuum. The image also highlights compatibility with Amazon Alexa and Google Assistant.

Operation

1. Rengøringstilstande

• Automatisk rengøring: The robot intelligently navigates and cleans your entire home based on the generated map.
• Kantrensning: Robotten rengør langs vægge og møbelkanter.
• Rengøring af pletter: Instruer robotten til at rengøre et specifikt lille område med koncentreret indsats.

2. Støvsugning og mopping

The 360 S9 can vacuum, mop, or perform both functions simultaneously. Attach the water tank and mopping pad for mopping operations.

• 3-Stage Water Adjustment: Control the water flow level (low, medium, high) via the app to suit different floor types and cleaning needs.
• Ensure the water tank is filled with clean water before mopping. Do not use detergents or cleaning solutions not approved by the manufacturer.

Image: A split image illustrating the 360 S9 Robot Vacuum's dual functionality. On the left, the robot vacuums debris into its 0.42L dustbin. On the right, it mops with water from its 0.2L 3-level electric water tank.

3. Smart navigation og kortlægning

The 360 S9 utilizes advanced LiDAR navigation to create precise maps of your home, enabling efficient and systematic cleaning.

• Realtidskortlægning: View the robot's cleaning path and map in real-time on the app.
• No-Go Zones & Virtuelle Mure: Set virtual boundaries in the app to prevent the robot from entering specific areas or crossing certain lines.
• Selektiv rengøring af værelser: Divide your home into rooms on the app and select specific rooms for cleaning, or schedule different rooms for different times.

Image: The 360 S9 Robot Vacuum is depicted in a modern living space, emitting green laser lines to illustrate its advanced LiDAR navigation and high-precision mapping capabilities.

Image: The 360 S9 Robot Vacuum is shown cleaning a living room floor, with a child playing nearby. The image highlights customized cleaning features such as No-go Zones, Scheduled Cleaning, and Selected Room Cleaning, indicated by icons above the scene.

4. Batteristyring

• The robot has a long battery life, providing up to 180 minutes of runtime on a single charge.
• When the battery is low, the robot will automatically return to its charging dock to recharge. Once fully charged, it will resume cleaning from where it left off.

Image: The 360 S9 Robot Vacuum is shown approaching its charging dock, with icons indicating its long battery time (160-180 min runtime, 5200mAh) and self-charging capability.

5. Suction Power

The 360 S9 features 2650Pa powerful suction, capable of effectively cleaning various floor types. It also includes a carpet boost function.

Image: The 360 S9 Robot Vacuum is shown on a carpet, illustrating its 2650Pa powerful suction with a carpet boost feature, designed to effectively clean rugs and carpets.

6. Integration af stemmestyring

The 360 S9 is compatible with smart home assistants, allowing for convenient voice control:

• Amazon Alexa: Connect your 360Robot account to Alexa for voice commands.
• Google Assistant: Integrate with Google Home for hands-free control.

Opretholdelse

Regelmæssig vedligeholdelse sikrer optimal ydeevne og forlænger levetiden på din robotstøvsuger.

1. Skraldespand og filter

• Tøm skraldespand: Tøm skraldespanden efter hver rengøringscyklus.
• Rens filter: Tap the filter to remove loose dirt. Rinse the filter with water if necessary, ensuring it is completely dry before reinstallation. Replace the filter every 3-6 months depending on usage.

2. Børster

• Hovedbørste: Fjern hovedbørstens dæksel, og løft børsten ud. Brug det medfølgende rengøringsværktøj til at fjerne hår og snavs, der har viklet sig ind omkring børsten. Rengør ugentligt.
• Sidebørster: Check side brushes for damage or entanglement. Remove any hair or debris. Replace if worn or damaged. Clean monthly.

3. Water Tank and Mopping Pad

• Tøm vandtank: After mopping, empty any remaining water from the tank.
• Clean Mopping Pad: Remove and wash the mopping pad after each use. Allow it to air dry completely.

4. Sensorer og opladningskontakter

• Wipe all sensors (LiDAR, cliff, wall sensors) and charging contacts on both the robot and the charging dock with a clean, dry cloth. Clean monthly.

Fejlfinding

If you encounter issues with your 360 S9, refer to the following common problems and solutions:

• Robotten oplader ikke: Ensure the charging dock is powered on and the robot's charging contacts are aligned with the dock's contacts. Clean contacts if dirty.
• Robot sidder ofte fast: Clear obstacles from the cleaning path. Check for tangled wires or small objects. Ensure no-go zones are correctly set in the app for problematic areas.
• Problemer med app-forbindelse: Verify your Wi-Fi network is 2.4 GHz. Restart your router, robot, and smartphone. Re-pair the robot with the app if necessary.
• Dårlig rengøringsevne: Empty the dustbin and clean the filter. Check and clean the main brush and side brushes for tangled hair or debris. Ensure the water tank is filled for mopping.
• Usædvanlige lyde: Check brushes for foreign objects. Ensure all components are correctly installed.

For further assistance, please contact customer support through the 360Robot App.

Specifikationer

Garanti og support

The 360 S9 Robot Vacuum and Mop comes with a 12 måneders garanti fra købsdatoen.

For technical support, warranty claims, or any product-related inquiries, please contact 360 Smart Life customer support:

• Via 360Robot App: Access the support section within the application for direct assistance.
• Online support: Visit the official 360 Smart Life webhjemmeside med ofte stillede spørgsmål og kontaktmuligheder.
• Svartid: Customer support aims to respond within 24 hours.
• A local after-service center is available in California, US.
