Indledning
This manual provides comprehensive instructions for the installation, operation, and maintenance of your Amantii Symmetry Series Built-in Electric Fireplace with Logs and Black Semi-Flush Mount Surround (SYM-60-SYM-XS-60), 60-Inch. Please read all instructions carefully before installation and use to ensure safe and efficient operation.
The Symmetry series electric fireplace offers a contemporary aesthetic with versatile installation options, including fully recessed or semi-flush mount within a 2x4-inch wall. It features advanced LED technology for realistic flame effects, a powerful heater, and smart control capabilities.
Image: The Amantii Symmetry Series Electric Fireplace displaying its realistic flame effect with the included log set.
Sikkerhedsoplysninger
ADVARSEL: Dette produkt kan udsætte dig for kemikalier, herunder carbon black, som staten Californien ved er kræftfremkaldende. For mere information, gå til www.P65Warnings.ca.gov.
Always follow local and national electrical codes. Do not operate the fireplace if any part has been submerged in water. Do not insert foreign objects into any ventilation or exhaust opening. Ensure proper clearances are maintained as per installation instructions.
Installation og opsætning
The Amantii Symmetry Series fireplace is designed for both indoor and outdoor installation. It offers flexibility with fully recessed or semi-flush mount options. For semi-flush mounting, the included SYM-XS surround is required.
Monteringsmuligheder:
- Fully Recessed: The unit can be fully recessed into a wall for a seamless look.
- Semi-Flush Mount: Requires the SYM-XS surround and can be installed within a 2x4-inch wall, leaving 2 inches outside the wall with 4 inches mounted inside.
The fireplace is both thermostat and electrical hard-wire ready for convenient installation.
Image: An Amantii Symmetry Series fireplace installed in a living room, illustrating the semi-flush mount option and smart features.
Dimensioner:
Refer to the technical diagram for precise measurements required for installation.
Image: Detailed technical drawing showing the dimensions of the Amantii Symmetry Series Electric Fireplace for installation planning.
Overall Dimensions: 60.25 inches (W) x 5.5 inches (D) x 15.625 inches (H).
Betjeningsvejledning
Your Amantii Symmetry Series fireplace offers a variety of features for a customizable experience.
Flame and Ember Bed:
The unit utilizes advanced LED technology to produce stunning flame effects. You can combine yellow, orange, and red flame colors to create your desired ambiance. The canopy and ember bed lighting further enhance the visual presentation.
The fireplace includes a 10-piece birch log set, charcoal grey fire glass, and vermiculite to customize the firebox appearance.
Opvarmningsfunktion:
The integrated 5,000 BTU heater is capable of warming up to 500 square feet of space. Heat vents through a single slot located on the top of the unit, allowing heat to cascade in front of the glass. The heater can be operated independently of the flame effects, allowing for year-round use.
Kontrolelementer:
The included remote control allows for independent operation of the flame and heater functions. The fireplace also features WiFi enabled Smart technology, providing supreme flexibility to control the unit from your smartphone.
Image: A visual guide to the Symmetry Series features, detailing various flame patterns (Birch Logs, Ember Rocks), ambient canopy lighting options, and the touch pad controls.
Flame Style Patterns:
- Birch Logs with real flame stencil (Yellow flame with a little Orange, Ambient Canopy Lighting: On)
- Birch Logs without real flame stencil (Yellow flame with a little Orange, Ambient Canopy Lighting: On)
- Ember Rocks with Flame Mold (Yellow flame with a little Orange, Ambient Canopy Lighting: On)
- Ember Media without real flame stencil (Orange flame, Ambient Canopy Lighting: On)
Opretholdelse
Regular maintenance ensures the longevity and optimal performance of your electric fireplace. Always disconnect power before performing any maintenance.
Rensning:
- Glaspanel: Clean the glass panel with a soft, damp cloth. Do not use abrasive cleaners or spray directly onto the glass.
- Vents: Periodically check and clean the air intake and exhaust vents to ensure unobstructed airflow. Use a soft brush or vacuum cleaner to remove dust and debris.
- Udvendige overflader: Wipe exterior surfaces with a soft, dry cloth.
Log Set and Media:
The included log set, fire glass, and vermiculite can be removed and cleaned gently with a soft brush if they accumulate dust.
Fejlfinding
If you experience issues with your Amantii Symmetry Series fireplace, refer to the following common troubleshooting steps:
- Ingen strøm: Ensure the unit is properly plugged into a functioning outlet or hard-wired connection. Check the circuit breaker.
- Ingen flammeeffekt: Verify that the flame function is turned on via the remote or control panel. Check if any internal lights are burnt out (contact support if so).
- Ingen varme: Confirm the heater function is activated. Ensure vents are not obstructed. The heater may have an overheat protection sensor that has tripped; allow the unit to cool down.
- Fjernbetjeningen virker ikke: Check and replace batteries in the remote control. Ensure there are no obstructions between the remote and the fireplace's receiver.
For persistent issues or complex problems, please contact Amantii customer support.
Specifikationer
| Feature | Detalje |
|---|---|
| Mærke | kærlighed |
| Model | SYM-60-SYM-XS-60 |
| Strømkilde | Elektrisk med ledning |
| Produktdimensioner | 5.5" D x 60.25" B x 15.62" H |
| Materiale | Metal |
| Finish Type | Malet |
| Installationstype | Built In, Wall Mount |
| Varmeoutput | 4800 britiske termiske enheder (BTU) |
| Speciel funktion | Corded, WiFi Enabled Smart Technology |
| Stil | Nutidige |
| Farve | Sort |
| Værelsestype | Stue |
| Ventilationstype | Vent fri |
| Varmedækning | 500 kvadratmeter |
| Inkluderede komponenter | 10-piece Birch Log Set, Charcoal Grey Fire Glass, Vermiculite, Remote Control |
| Varens vægt | 85.8 pund |
| Kammerdybde | 5.5 tommer |
| Brænder type | Kvarts |
| Dato først tilgængelig | 14. maj 2020 |
Garanti og support
For warranty information and customer support, please refer to the documentation included with your product or visit the official Amantii webwebsted. Du kan også besøge Amantii Store on Amazon for yderligere ressourcer og kontaktoplysninger.
Amantii offers customer support to assist with any questions or issues you may encounter with your fireplace.
