Brugermanual til Braeburn midlertidig byggetermostat

Indledning

The Braeburn Model 165 Temporary Construction Thermostat is designed to maintain a consistent heating temperature during construction phases. This non-programmable unit is engineered for durability and ease of use in demanding environments, protecting against common construction site elements like drywall dust, paint, and mud.

Its tamper-proof design ensures the temperature setting remains fixed at 65°F (18.3°C), preventing unauthorized adjustments and contributing to cost control by avoiding excessive heating. The thermostat can be reused across multiple job sites, offering a practical solution for temporary HVAC control.

Opsætning og installation

The Braeburn Model 165 is designed for straightforward installation in place of a standard thermostat during construction. It is a wall-mount unit requiring a 24-volt AC/DC power source.

Installationstrin:

1. Strømafbrydelse: Before beginning installation, ensure that power to the HVAC system is completely disconnected at the circuit breaker to prevent electrical shock.
2. Monteringssted: Select a suitable wall-mount location that is representative of the area's temperature and away from direct sunlight, drafts, or heat sources.
3. Ledningsføring: Connect the thermostat's two wires to the appropriate terminals of your 24-volt HVAC control system. Consult your HVAC system's wiring diagram for specific terminal connections. The thermostat utilizes BACnet MS/TP protocol for communication, though for its fixed function, direct wiring for heating control is primary.
4. Sikker montering: Secure the thermostat unit to the wall using appropriate fasteners. Ensure the enclosure is properly sealed to protect internal components from dust and debris.
5. Genopkobling af strøm: Once installation is complete and all connections are secure, restore power to the HVAC system.

An image showing the compact, white Braeburn Temporary Construction Thermostat unit with two black wires extending from one end, ready for installation.

Betjeningsvejledning

The Braeburn Model 165 is a non-programmable thermostat designed for a single, fixed function: maintaining a heating temperature set point of 65°F (18.3°C).

Vigtige operationelle funktioner:

• Fast temperaturindstilling: The thermostat is factory-set to maintain 65°F (18.3°C) for heating. This setting cannot be adjusted by the user.
• Tamper-Proof Design: The unit's design prevents unauthorized temperature adjustments, ensuring consistent heating and energy efficiency on the job site.
• Automatisk drift: Once properly installed and powered, the thermostat will automatically control the heating system to maintain the fixed temperature.
• No User Interface: This model does not feature a display or user-accessible buttons for temperature control, aligning with its tamper-proof and fixed-function design.

Opretholdelse

The Braeburn Model 165 Temporary Construction Thermostat is built for durability in harsh construction environments. Minimal maintenance is required to ensure its continued optimal performance.

Retningslinjer for vedligeholdelse:

• Rensning: Periodically wipe the exterior of the thermostat with a soft, dry cloth to remove any accumulated dust, paint, or mud. Do not use abrasive cleaners or solvents.
• Kabinetets integritet: Ensure the sturdy enclosure remains intact and free from cracks or damage. This enclosure is crucial for protecting the internal switch from construction debris.
• Luftstrøm: Ensure that the area around the thermostat is not obstructed, allowing for proper air circulation and accurate temperature sensing.
• Genanvendelighed: When moving the thermostat to a new job site, inspect the wiring and enclosure for any signs of wear or damage before reinstallation.

Fejlfinding

If the Braeburn Model 165 Temporary Construction Thermostat is not functioning as expected, consider the following common issues and solutions:

• Ingen opvarmning:
  • Tjek strøm: Verify that power to the HVAC system and the thermostat is on at the circuit breaker.
  • Ledningsføring: Ensure all wiring connections are secure and correctly terminated according to your HVAC system's diagram. Loose connections can prevent operation.
  • VVS-system: Confirm that the heating system itself (furnace, boiler, etc.) is operational and not experiencing any faults.
• Temperatur unøjagtighed:
  • Forhindringer: Ensure no objects are blocking the thermostat's sensor or airflow around the unit.
  • External Heat/Cold Sources: Verify the thermostat is not located near direct heat sources (e.g., vents, direct sunlight) or cold drafts, which can affect readings.
• Fysisk skade:
  • Inspect the thermostat's enclosure for any visible damage. If the enclosure is compromised, the internal components may be exposed to dust or moisture, affecting performance.

If issues persist after performing these checks, it is recommended to contact a qualified HVAC technician or Braeburn customer support for further assistance.

Specifikationer

Garanti og support

Specific warranty details for the Braeburn Model 165 Temporary Construction Thermostat are typically provided with the product packaging or can be obtained directly from Braeburn Systems LLC.

For technical support, troubleshooting assistance beyond this manual, or warranty claims, please contact Braeburn customer service. It is recommended to have your product model number (165) and purchase information ready when contacting support.

Du kan typisk finde kontaktoplysninger på producentens officielle website or within the product documentation.
