OMMO Metaldetektor Model OM-C011 Brugsanvisning

1. Sikkerhedsoplysninger

Please read and understand all safety instructions before operating the OMMO Metal Detector. Failure to follow these instructions may result in injury or damage to the device.

Udskiftning af batteri: Change the battery immediately if the low battery indicator on the LCD illuminates.
Langtidsopbevaring: If the unit will not be used for a week or more, remove the batteries. Battery leakage can damage electronic components.
Anbefalede batterier: The included 9V Carbon Batteries have a shorter lifespan. For extended use, Alkaline or rechargeable 9V batteries are recommended.
Vandtæthed: The search coil is waterproof, allowing for underwater detection. However, the control box is ikke vandtæt and must be kept dry.

2. Pakkens indhold

Bekræft, at alle nedenstående varer er inkluderet i din pakke:

1 × OMMO Metal Detector Unit
1 × bæretaske
2 × 9V Batteries
1 × Shovel
1 × Headphone

OMMO Metal Detector and included accessories — Figure 2.1: All components of the OMMO Metal Detector package, including the main unit, carrying bag, batteries, shovel, and headphones.

3. Opsætning og montering

The OMMO Metal Detector requires minimal assembly. Follow these steps to prepare your device for use:

Tilslut kontrolboksen: Secure the control box to the upper stem. Ensure it is firmly attached using the provided fasteners.
Saml stilken: Connect the middle and lower rods to the upper rod. The stem is adjustable from 30 to 43 inches to suit different user heights.
Attach the Armrest: Secure the armrest to the upper part of the stem for comfortable operation.
Connect the Search Coil: Attach the 10-inch waterproof search coil to the lower end of the stem. Route the coil cable securely along the stem to prevent tangling.
Installer batterier: Open the battery compartment on the control box and insert the two 9V batteries, ensuring correct polarity. Close the compartment securely.

4. Driftstilstande

The OMMO Metal Detector features four distinct operating modes to optimize your metal detection experience:

DISCRIMINATION Mode: This mode allows you to exclude unwanted metal types. The unit automatically balances the ground in this mode.
TONE-tilstand: The upgraded OM-C011 can differentiate metal types by emitting distinct high or low tones.
PINPOINT-tilstand: Use this mode to accurately locate the exact position of a detected target by temporarily lowering the sensitivity.
ALL METAL-tilstand: This mode is designed to search for all types of metal objects without discrimination.

OMMO Metal Detector LCD display showing various icons for modes, sensitivity, and battery level. — Figure 4.1: The intuitive LCD display shows detection mode, sensitivity level, and battery status. The meter pointer swings right when metal is found.

Illustration of discrimination mode, showing desired metal objects being detected and unwanted objects being ignored. — Figure 4.2: Discrimination mode allows users to filter out specific metal types, such as iron, to focus on desired targets like coins or jewelry.

5. Justeringer

Følsomhedsjustering: Rotate the SENS knob from 0 to 10 to gradually increase the sensitivity. Higher sensitivity allows for deeper detection but may also pick up more interference.
Baggrundslys funktion: The LCD display includes a backlight for improved visibility in low-light conditions. The backlight is on by default. To turn it off, hold the MODE button for 2 seconds. Repeat the action to turn it back on.

OMMO Metal Detector control panel with backlight on and off, illustrating the backlight feature. — Figure 5.1: The backlight feature enhances screen visibility, especially in dim environments.

6. Vedligeholdelse

Proper maintenance ensures the longevity and optimal performance of your metal detector:

Rensning: Efter hver brug skal søgespolen og stilken tørres af med enamp cloth. Ensure the control box remains dry.
Opbevaring: Store the metal detector in a cool, dry place. If storing for an extended period, remove the batteries to prevent leakage.
Batteripleje: Always use fresh, high-quality batteries. Avoid mixing old and new batteries or different types of batteries.

7. Fejlfinding

If you encounter issues with your OMMO Metal Detector, refer to the following common solutions:

Ingen strøm: Check if the batteries are correctly installed and fully charged. Replace if necessary.
Uregelmæssige signaler: Reduce the sensitivity setting. Move away from sources of electromagnetic interference (e.g., power lines, other electronic devices). Ensure the search coil cable is tightly wound around the stem.
Ingen detektion: Ensure the detector is in the correct operating mode (e.g., ALL METAL). Check that the search coil is properly connected.

8. Specifikationer

Mærke	OMMO
Modelnummer	OM-C011
Vægt	6.23 pund
Justerbar stængelængde	30-43 tommer
Søgespolestørrelse	10 tommer diameter
Waterproof Coil	Yes (Control box not waterproof)
Sensitivity (Coin-size targets)	Up to 8 inches deep
Driftsfrekvens	7.69 KHz
Strømkilde	Battery Powered (2 x 9V DC batteries)
International Protection Rating	IP54

9. Garanti og support

Your OMMO Metal Detector comes with a warranty. Please refer to the included OMMO Warranty & Promo Card for details on warranty coverage and how to register your product.

For any problems or technical assistance, please contact OMMO customer support. Contact information can typically be found on the warranty card or the official OMMO webwebsted.
