AL-KO BMP 14001 Termisk Vandpumpe Brugermanual

1. Introduktion

This manual provides essential information for the safe and efficient use of your AL-KO BMP 14001 thermal water pump. Please read these instructions carefully before initial operation and keep them for future reference. The AL-KO BMP 14001 is a powerful gasoline engine pump designed for transferring large volumes of water, ideal for garden irrigation, emptying pools, or flood relief in areas without electrical power.

2. Sikkerhedsinstruktioner

Always prioritize safety when operating the pump. Failure to follow these instructions may result in injury or damage to the equipment.

• Brændstofhåndtering: Gasoline is highly flammable. Always refuel in a well-ventilated area with the engine off and cool. Avoid spilling fuel.
• Udstødningsgasser: The engine produces carbon monoxide, a colorless and odorless gas. Operate the pump only in open, well-ventilated areas. Never operate indoors.
• Vandtype: Pumpen er not suitable for drinking water. It is only suitable for clear water and chlorinated water (pool water) below 35°C (95°F).
• Prohibited Liquids: Do not use the pump with saltwater, aggressive chemicals, flammable liquids, or water containing sand or abrasive particles.
• Varme overflader: Motoren og udstødningssystemet bliver meget varme under drift. Undgå kontakt for at forhindre forbrændinger.
• Stabil placering: Always operate the pump on a stable, level surface to prevent tipping.
• Børn og tilskuere: Keep children and bystanders away from the operating pump.

3. Produktet er slutview

The AL-KO BMP 14001 is engineered for robust performance and portability.

Nøglefunktioner:

• Powerful thermal water pump for transferring large volumes of water.
• Easy-start 1.7 kW (2.3 HP) 4-stroke engine.
• Mobile and flexible, operable without an electrical connection, ideal for remote locations or flood situations.
• Maximum suction height of 6 meters and maximum delivery height of 36 meters.
• High flow rate of up to 12,000 liters per hour.
• Equipped with a sturdy handle for easy transport and wide support feet for enhanced stability.

Komponenter:

The pump includes the gasoline engine unit and connectors for suction and pressure hoses.

Figur 1: En detaljeret view of the AL-KO BMP 14001 thermal water pump, showcasing its red engine housing, black frame, and water inlet/outlet connections.

4. Opsætning

Korrekt opsætning er afgørende for sikker og effektiv drift.

1. Udpakning og inspektion: Carefully unpack the pump and check for any shipping damage or missing parts.
2. Placering: Position the pump on a firm, level, and stable surface. Ensure adequate ventilation around the engine.
3. Motorolie: Before first use, fill the engine with the recommended 4-stroke engine oil to the correct level. The oil filler opening is easily accessible on the pump body for convenient maintenance. Refer to the engine manual for specific oil type and capacity.
4. Tankning: Fill the fuel tank with unleaded gasoline. Ensure the engine is off and cool. Do not overfill. The fuel tank capacity is 1.6 liters.
5. Slangeforbindelser:
   • Connect the suction hose to the inlet port (typically larger diameter). Ensure a tight, airtight connection to prevent air leaks, which can affect priming and performance. The connection diameter for both suction and pressure sides is 33.3 mm.
   • Connect the pressure hose to the outlet port. Secure all connections with appropriate clamps.
6. Spædning af pumpen: To ensure a smooth start, the pump circuit must be filled with water. Use the easy-fill spout located on top of the pump to fill the pump housing with water before starting the engine.

5. Betjeningsvejledning

Follow these steps for safe and effective operation.

Start af motor:

1. Sørg for, at brændstofventilen er åben.
2. Set the choke lever (if applicable) to the 'START' or 'CHOKE' position for a cold engine.
3. Sæt motorkontakten på 'ON'.
4. Træk godt i startsnoren, indtil motoren starter.
5. Når motoren starter, skal du gradvist flytte chokerhåndtaget til 'RUN'-positionen.

Pumping Operation:

Once the engine is running, the pump will begin to draw and discharge water. Monitor the flow and ensure the suction hose remains submerged in the water source.

Figur 2: The AL-KO BMP 14001 thermal water pump positioned on the ground in a garden, actively pumping water through a hose to a person watering plants.

Figur 3: Et nærmere view of the AL-KO BMP 14001 thermal water pump operating in a garden, with a person in the background watering plants, demonstrating its use for irrigation.

Figur 4: The AL-KO BMP 14001 thermal water pump placed in a garden setting, adjacent to a greenhouse, illustrating its versatility for various outdoor watering tasks.

Stop af motoren:

1. Set the engine switch to 'OFF'.
2. Luk brændstofventilen.
3. Allow the engine to cool down before handling or storing.

6. Vedligeholdelse

Regelmæssig vedligeholdelse sikrer pumpens levetid og optimale ydeevne.

• Engine Oil Check: Regularly check the engine oil level and top up or change as recommended in the engine manual.
• Luftfilter: Inspect and clean the air filter periodically. Replace if damaged.
• Tændrør: Check and clean the spark plug. Replace if worn.
• Rensning: Keep the pump exterior clean. Remove any dirt or debris from the engine cooling fins.
• Opbevaring: For long-term storage, drain the fuel tank and carburetor to prevent fuel degradation. Store the pump in a dry, well-ventilated area, away from direct sunlight and extreme temperatures.

7. Fejlfinding

If your pump is not operating correctly, check the following common issues:

• Motoren starter ikke: Check fuel level, engine oil level, spark plug condition, and ensure the engine switch is 'ON' and fuel valve is open. Verify the choke setting for a cold engine.
• No Water Flow / Low Flow: Ensure the pump is properly primed (filled with water). Check for air leaks in the suction hose or connections. Verify the suction hose is fully submerged and not blocked. Check for blockages in the impeller or hoses.
• Overdreven vibration/støj: Ensure the pump is on a stable, level surface. Check for loose components or foreign objects in the pump housing.

If problems persist after checking these points, consult a qualified service technician.

8. Specifikationer

9. Garanti og support

AL-KO is committed to quality. For enhanced peace of mind, AL-KO offers a 2+2 års garantiforlængelse upon online registration of your product. This provides maximum security for your investment.

To register your product and learn more about the warranty extension, please visit: www.alko-garden.de

For technical support, spare parts, or service inquiries, please contact your authorized AL-KO dealer or visit the official AL-KO webhjemmeside for kontaktoplysninger i din region.
