Golden Lighting Florence pendel med 3 lys, brugsanvisning

Indledning

This manual provides detailed instructions for the safe installation, operation, and maintenance of your Golden Lighting Florence 3-Light Pendant. Please read this manual thoroughly before beginning installation and retain it for future reference. This fixture is designed for indoor use only and features a unique handwoven natural raphia rope shade with a matte black frame, blending modern and rustic aesthetics.

Figur 1: The Golden Lighting Florence 3-Light Pendant. This image showcases the fixture's distinctive handwoven natural raphia rope shade and matte black metal components, highlighting its design and texture.

Sikkerhedsoplysninger

• ADVARSEL: Risiko for elektrisk stød. Afbryd strømmen ved afbryderen eller sikringsboksen før installation eller service.
• Alle elektriske forbindelser skal være i overensstemmelse med lokale forskrifter, forordninger eller National Electric Code (NEC). Kontakt en kvalificeret elektriker, hvis du ikke er bekendt med installation af elektriske installationer.
• This fixture is intended for indoor use only. Do not expose to water or excessive moisture.
• Brug kun pærer af den angivne type og watttage. Refer to the "Specifications" section for bulb requirements.
• Do not install this fixture on a ceiling that is less than 8 feet (2.4 meters) high.
• Sørg for, at monteringsfladen kan bære armaturets vægt.
• Bær altid sikkerhedsbriller under installationen.
• Handle the natural raphia rope shade with care to avoid damage.

Pakkens indhold

Carefully unpack your fixture and identify all parts. Keep all packaging materials until installation is complete to prevent accidental disposal of small parts.

• Fixture Body with Raphia Rope Shade (1)
• Monteringsplade (1)
• Baldakin (1)
• Kæde (1)
• Trådnødder (3)
• Monteringsskruer (2)
• Jordskrue (1)
• Instruktionsmanual (1)

Note: Bulbs are not included and must be purchased separately.

Opsætning og installation

Before starting, ensure the power is turned off at the circuit breaker. This fixture requires assembly and professional installation is recommended.

1. Sluk for strømmen: Locate the circuit breaker that supplies power to the junction box where you will install the fixture. Turn the breaker to the OFF position.
2. Forbered monteringsplade: Attach the mounting plate to the junction box using the provided mounting screws. Ensure the plate is securely fastened.
3. Juster kædelængde: Determine the desired hanging height for your pendant. Adjust the chain length by removing links as necessary. Thread the fixture wires through the chain and canopy.
4. Foretag elektriske forbindelser:
   • Tilslut sort ledningen fra armaturet til sort (varm) ledning fra samledåsen ved hjælp af en trådmøtrik.
   • Tilslut hvid ledningen fra armaturet til hvid (neutral) ledningen fra samledåsen ved hjælp af en trådmøtrik.
   • Tilslut jord wire from the fixture (bare copper or green) to the jord wire from the junction box (bare copper or green) and to the ground screw on the mounting plate.

   Ensure all wire nuts are securely twisted and no bare wire is exposed.
5. Mount Canopy: Carefully push the wired canopy up to the ceiling, aligning the canopy screws with the holes in the mounting plate. Secure the canopy in place with the decorative nuts.
6. Installer pærer: Screw three E26 medium base bulbs (not included) into the sockets. Do not exceed the maximum wattage på 60 watt pr. pære.
7. Gendan strøm: Once installation is complete, turn the power back on at the circuit breaker. Test the fixture to ensure it functions correctly.

Figur 2: Dimensional diagram of the Florence 3-Light Pendant. This illustration provides approximate measurements for the fixture (18.5 x 18.5 x 25.13 inches) and suggests suitable hanging heights in relation to common furniture like dining tables, indicating a recommended clearance of 30 inches above a 30-inch high table.

Betjeningsvejledning

The Golden Lighting Florence 3-Light Pendant is operated via a standard wall switch (not included). Ensure the correct type of bulbs are installed for optimal performance.

• Tænd/sluk: Flip the wall switch connected to the fixture to turn the lights on or off.
• Dæmpbar funktion: This fixture is dimmable. If you wish to utilize the dimming function, ensure you use dimmable E26 LED or incandescent bulbs and connect the fixture to a compatible dimmer switch (sold separately).

Figur 3: The Florence 3-Light Pendant installed in a dining area. This image demonstrates the fixture's aesthetic integration into a living space, highlighting its natural fiber shade and the warm ambiance it provides.

Opretholdelse

Regelmæssig vedligeholdelse vil bidrage til at bevare din pendellampes udseende og funktionalitet.

• Rensning:
  • Afbryd altid strømmen før rengøring.
  • For the metal frame, wipe with a soft, dry cloth. Do not use abrasive cleaners or solvents, as they may damage the finish.
  • For the natural raphia rope shade, gently dust with a soft brush or a dry cloth. Avoid using wet cloths or liquid cleaners on the rope, as moisture can damage the natural fibers.
• Udskiftning af pære:
  • Ensure the fixture is cool and power is disconnected before replacing bulbs.
  • Unscrew the old bulb and screw in a new E26 medium base bulb, ensuring it does not exceed 60 watts.

Fejlfinding

Specifikationer

Garanti og support

Golden Lighting stands behind the quality of its products.

• Garanti: Dette produkt leveres med en 1 års garanti against structural defects and a 6 måneders garanti against finish defects from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from improper installation, accident, misuse, abuse, or normal wear and tear.
• Kundesupport: For technical assistance, missing parts, or warranty claims, please contact Golden Lighting customer service. Refer to the official Golden Lighting website for the most current contact information. When contacting support, please have your model number (6933-3P BLK-NR) and proof of purchase readily available.
